Zenoah EXZ2610DL Owner's Manual

Zenoah EXZ2610DL Owner's Manual

Convertible edger attachment
Hide thumbs Also See for EXZ2610DL:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual
EXZ2610DL (HE-EX)
115 37 52-10 (004)
OWNER'S MANUAL
CONVERTIBLE
EDGER ATTACHMENT
EXZ2610DL
( HE-EX )
GB-1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EXZ2610DL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zenoah EXZ2610DL

Summary of Contents for Zenoah EXZ2610DL

  • Page 1 EXZ2610DL (HE-EX) 115 37 52-10 (004) OWNER’S MANUAL CONVERTIBLE EDGER ATTACHMENT EXZ2610DL ( HE-EX ) GB-1...

  • Page 2: Table Of Contents

    EXZ2610DL (HE-EX) SAFETY FIRST Contents Instructions contained in warnings within this manual marked with a symbol concern critical points which must be taken 1. Parts location ..........2 into consideration to prevent possible serious bodily injury, and for this reason you are requested to read all such instructions 2.

  • Page 3: Specifications

    Max. output ..........1.2 Hp (0.9 kW) at 7500/min-1 (rpm) Idle speed ................3000 ±200/min-1 (rpm) Fuel ................Mixture (Gasoline 50 : Oil 1) (when using ZENOAH genuine oil) Carburetor ................ Walbro Diaphragm type Spark plug ..................NGK CMR7H Fuel tank capacity ....................0.65 L...

  • Page 4: Warning Labels On The Machine

    EXZ2610DL (HE-EX) 3. Warning labels on the machine (1) Read owner’s manual before operating this machine. (2) Wear head, eye and ear protection. (3) Wear foot protection. (4) Wear gloves. (5) Beware of thrown objects. (6) Warning / Attention (7) Keep all children, bystanders and helpers 15 meters away from the machine.

  • Page 5: For Safe Operation

    EXZ2610DL (HE-EX) 5. For safe operation 1. Read this manual carefully until b. At night, at times of heavy fog, you completely understand and or at any other times when follow all safety and operating your field of vision might be instructions.
  • Page 6 ZENOAH 2. Check the condition of working servicing dealer for repair. area to avoid any accident by hit-...
  • Page 7 5. For safe operation • IF SOMEONE COMES HANDLING FUEL 1. Guard against hazardous situa- 1. The engine of the ZENOAH prod- tions at all times. Warn adults to uct is designed to run on a mixed keep pets and children away from fuel, which contains highly flam- the area.

  • Page 8: Set Up

    EXZ2610DL (HE-EX) 6. Set up MOUNTING ENGINE JOINT ATTACHMENT Knob bolt 1. Push the shaft tube toward the clutch housing and • Insert the attachment to the main shaft. rotate it by hand to check that the drive shaft is en- •...

  • Page 9: Fuel And Chain Oil

    • The Zenoah engines are lubricated by oil specially formulated for air-cooled 2-cycle gasoline engine use. If Zenoah oil is not available, use an anti-oxidant added WARNING quality oil expressly labeled for air-cooled 2-cycle en- gine use (JASO FC GRADE OIL or ISO EGC GRADE).

  • Page 10: Operation

    8. Operation STARTING ENGINE 4. Move the choke lever to the closed position. The ZENOAH stick edger is designed for edging lawn in gardens, parks, roadsides and so on. Before starting the engine, take the operating position and adjust the handle position and the wheel height as necessary.
  • Page 11 EXZ2610DL (HE-EX) 8. Operation IMPORTANT ADJUSTING THROTTLE CABLE • The normal play is 1 or 2 mm when measured at the • Avoid pulling the rope to its end or returning it by re- carburetor side end. Readjust with the cable adjuster leasing the knob.
  • Page 12 3. When starting to edge, run the engine at full throttle, and slowly have the blade cut into the edge groove. BLADE ROTATION NOTE • Do not use the HE-EX to make a new groove into the ground. Such usage will not be covered by ZENOAH Warranty. GB-12...

  • Page 13: Maintenance

    EXZ2610DL (HE-EX) 9. Maintenance Every Every Every Before System/components Procedure Note hours hours hours after after after ✔ fuel leaks, fuel spillage wipe out ✔ ✔ fuel tank, air filter, fuel filter inspect/clean replace, if necessary see adjusting replace carburetor ✔...

  • Page 14: Storage

    EXZ2610DL (HE-EX) 9. Maintenance ■ PERIODICAL SERVICE POINTS MUFFLER 1. CYLINDER FINS WARNING Periodically check and clean the cylinder fins in the re- pair specialty store. • Inspect periodically, the muffler for loose fasten- ers, any damage or corrosion. If any sign of ex-...

  • Page 15: Troubleshooting Guide

    → clogged with dust → consult with the repair specialty store When your unit seems to need further service, please consult with our ZENOAH service shop in your area. Limited warranty Should any failure occur on the product under normal oper-...
  • Page 16 PRINTED IN JAPAN...
