dbx 131s Graphic EQ Specifications

131s Graphic EQ
Single 31-Band Equalizer
Exceptional sound and rugged reliability
When the pros need an EQ, they turn to dbx. With a proven track record that spans four decades, dbx® EQ's are the
industry standard for touring, studios, and audio installations. With the dbx heritage of revered pro EQs, the 131s meets
the needs of the most demanding sound reinforcement environments, while offering the simplicity of straightforward
controls.
The dbx 131s includes a single 31-band channel of 1/3-octave equalization, ±12 dB input gain, switchable ±6 dB or ±12 dB
boost/cut range, 20mm nonconductive sliders, an intuitive user interface, and output level metering. From its extended 10Hz
to 50kHz frequency response and 110 dB dynamic range to the quality componentry and meticulous attention to detail, the
131s offers exceptional sound and rugged reliability that guarantees you will always sound your best.
Sure to find a home in the studio, on tour and with installed sound venues, the dbx 131s is destined to take its rightful
place in the lineage of great dbx signal processors that are the professional's choice in signal processing. With such
affordable quality, there's no longer any excuse for compromising your sound.
Features
Single 31-band, 1/3-octave Constant Q
<
frequency bands
Switchable boost/cut ranges of
<
±6 or ±12 dB
Who uses this product:
dbx Professional 8760 S. Sandy Pkwy.
Products Sandy, Utah 84070
C o m p l e t e L o u d s p e a k e r M a n a g e m e n t Sy s t e m
Front panel bypass switch
<
±12 dB input gain range
<
4-segment LED ladders for monitoring
<
output levels
BANDS DJs
1.801.568.7660
PHON E
1.801.568.7662
FAX
XLR and TRS Inputs and Outputs
<
Frequency Response of <10 Hz to >50kHz
<
Dynamic range of greater than 108dB
<
