  • Page 1 WASHING MACHINE USER MANUAL...
  • Page 2: Table Of Contents

    THE CONTENTS SECTION 1:BEFORE USE Safety warnings Recommendations SECTION 2:INSTALLATION Removal of transportation screws Foot adjustment Electrical connection Water supply connection Drain connection SECTION 3:TECHNICAL SPECIFICATIONS SECTION 4:CONTROL PANEL Start/Pause button Function indicator lights Function buttons Spin speed selector Program knob Washing Programs SECTION 5:WASHING YOUR LAUNDRY Before washing...
  • Page 3: Section 1:Before Use

    Keep the packing materials from your machine away from children to avoid hazards. Do not let your children play with the washing machine. Keep pets away from your machine. Your machine should only be used by adults, and in accordance with the information written in this manual.
  • Page 4: Section 2:Installation

    If you plan not to use your machine for a long time, unplug it, shut off the water supply, and leave the door open in order to keep the inside of the machine dry and to prevent unpleasant odours in the drum. As a result of our quality control procedures, a certain amount of water may remain in your machine from testing.
  • Page 5: Electrical Connection

    Your washing machine requires a 50Hz supply of 220-240Volts. A special earthed plug has been attached to the supply cord of your washing machine. This plug must be fitted to an earthed socket. The fuse value fitted to this plug should be 13 amps. If you have any doubts about your electrical supply, consult a qualified electrician.
  • Page 6: Drain Connection

    After connection is complete, check for leakage by turning on your tap completely. Make sure that water inlet hoses can not become folded, damaged, stretched or crushed when the washing machine is in its final position. Mount the water inlet hose to a ¾” threaded water tap.
  • Page 7: Section 3:Technical Specifications

    SECTION 3:TECHNICAL SPECIFICATIONS WK1200Y WK1400Y Maximum dry laundry capacity (kg) Recommended loading (kg) Height (cm) Width (cm) 59,6 59,6 Depth (cm) Maximum spin 1200 1400 cycle ( rpm ) (*) Maximum spin cycles depend on the model you’ve chosen...
  • Page 8: Section 4:Control Panel

    SECTION 4:CONTROL PANEL WK1400Y 1-Detergent drawer 6-Program knob 2-Start/pause light 7-Start/pause button 3-Function indicator lights 8-Function buttons 4-Spin speed selector 9-Program end light 5-Program ready light WK1200Y 1-Detergent drawer 6-Program knob 2-Start/pause light 7-Start/pause button 3-Function indicator lights 8-Function buttons 4-Spin speed selector 9-Program end light 5-Program ready light...
  • Page 9: Start/Pause Button

    START/PAUSE BUTTON Used to start a selected program or pause during running. WARNING! The program knob must be brought to O(off) position before selecting the program or changing an existing program. FUNCTION INDICATOR LIGHTS When the start/pause button or any function button is pressed,the corresponding light turns on.The light turns off when the function button or start/pause button is re-pressed, or when the process or selected function is completed.
  • Page 10: Spin Speed Selector

    WARNING! Functions vary depending on the model you have chosen.If you forgot to use additional function and your machine starts to wash push the additional function button if the indicator light is on. Additional function will be activated.If the indicator light is not on,additional function will not be activated.
  • Page 11: Program Knob

    PROGRAM KNOB With the program knob, you can select the program with which you wish to wash your clothes. You can adjust the program selection process by turning the program knob in both directions. You must be careful that the adjustment sign of the program knob is exactly on the program you want to select.
  • Page 12: Washing Programs

    Washing Programs MAX DRY LOAD CAPACITY (kg) DETERGENT PROGRAM TYPE OF LAUNDRY EXPLANATIONS COMPART. WK1200Y WK1400Y Dirty, boil, cotton and linen 1-COTTON 90 textile 2-COTTON 60 Very dirty, cotton, coloured (PREWASH) and linen textile Dirty, cotton, coloured and **3-COTTON 60 linen textile Slightly dirty, paint to get 4-COTTON 40...
  • Page 13 MAX DRY LOAD CAPACITY (kg) DETERGENT PROGRAM TYPE OF LAUNDRY EXPLANATIONS COMPART. WK1200Y WK1400Y 13-SPORT All sports clothes Sport clothes CLOTHES and jeans Slightly dirty, synthetic or 14-SYNTHETIC synthetic mixture sensitive Nylon socks, blouse COLD laundry.Washed without heating the tap water. 15-CURTAIN Tulle and curtain as Tulle, curtain, diolen,...
  • Page 14: Section 5:Washing Your Laundry

    Wash small clothes like socks and handkerchiefs in a washing bag. Wash up to 90 C Wash up to 60 C Wash up to 30 C Not washable in washing machine Placing clothes into the machine Open the door of your machine.
  • Page 15: Running The Machine

    For excessively dirty clothes, select a program with pre-washing, fill ¼ portion of the detergent you will put in compartment 1 in the detergent drawer and the remaining portion in compartment 2. Only use detergents developed especially for automatic washing machines.
  • Page 16: Section 6:Maintenance And Cleaning

    Cancellation of the Program If you desire to end a running program early: Press the start/pause button. Turn the program knob to O(off) status. Turn the program knob to “Draining” or “Spinning” programs. The program ready light will be on. Run the program you have selected by pressing the start/pause button.
  • Page 17: Pump Filter

    Remove the water inlet hose. Remove the filter found on the water inlet valve using pliers and wash thoroughly with a brush. Clean the filters of the water inlet hoses located on the tap side by removing manually together with the washer. After you clean the filters, you can fit them the same way as you have removed them.
  • Page 18: Detergent Drawer

    WARNING! Danger of being scalded! Since the water inside the pump maybe hot, wait for it to cool. DETERGENT DRAWER Detergents may form a sediment in your detergent drawer or in the housing of the detergent drawer over time. To clean this sediment, you must remove the detergent drawer.To pull out the detergentdrawer: Pull the detergent drawer to the end.(DIAGRAM-1) Press the blue siphon plug in the drawer, and continue to pull the drawer...
  • Page 19: Siphon Plug

    SIPHON PLUG Pull out the detergent drawer. Remove the siphon plug and clean the residues of the softener thoroughly. Fit the cleaned siphon plug in its location. Check it is fitted properly. Siphon plug THE CABINET Clean the exterior surface of the cabinet of your machine with lukewarm water and a cleaning substance that will not damage the cabinet.
  • Page 20: Section 7:Practical Information

    SECTION 7:PRACTICAL INFORMATION Alcoholic beverages: The stain point, should first be washed with cold water, than should be wiped with glycerine and water and be rinsed with water mixed with vinegar. Shoe Polish: The stain should be slightly scratched without ruining the cloth, rubbed with detergent and rinsed.
  • Page 21: Section 8:Avoiding Minor Faults

    Mould: Mould stains should be cleaned as soon as possible. The stain should be washed with detergent, and if it does not disappear, it should be wiped with oxygenated water (in proportion of 3%). Ink: Hold the stained area under cold water and wait until the inky water completely runs off.
  • Page 22 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION Insert the plug into the It is unplugged. socket. Your fuse is defective. Change your fuse. The electric power is Check the electric off. power. Start/pause button has Press the start/pause Your machine does not not been pressed.
  • Page 23 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION There is a small It does not prevent amount of clothes in operation of the the device. machine. Do not exceed the Excessive amount of Your machine is recommended quantity clothes are filled in the vibrating.
  • Page 24 METHODS OF FAILURE PROBABLE CAUSE ELIMINATION Clothes exceeding the Put the clothes in your maximum capacity machine in a manner has been filled in your not to exceed its machine. maximum capacity. Use the amount of The washing result is Your water may be detergent according to not good.
  • Page 25: Section 9:Automatic Failure Detection System

    METHODS OF FAILURE PROBABLE CAUSE ELIMINATION The unbalanced load control system will try to distribute your clothes in a homogenous manner. No failure. The The spinning process After your clothes are unbalanced load is not done or starts distributed, passage to control works in that with delay .
  • Page 26 FAILURE FAILURE PROBABLE THE PROCESS CODE INDICATOR FAILURE TO BE DONE Turn on the tap to the end.Water may be cut, check it.If the problem is still The water level continuing,your in your machine machine will The program is below heater. automatically Err 02 ready light...
  • Page 27 FAILURE FAILURE PROBABLE THE PROCESS CODE INDICATOR FAILURE TO BE DONE Shut down your The heater of your machine and The start/pause machine or the unplug. Turn off Err 05 light and program heat sensor has your tap and apply end light blink.
  • Page 28: Section 10:International Washing Symbols

    SECTION 10: INTERNATIONAL WASHING SYMBOLS Washing Do not wash Lukewarm iron. Medium hot iron. temperature. (hand wash) Do not tumble Hot iron. Do not iron. Hang to dry. dry. Drip dry. Dry flat. Do not bleach. Handy to bleach. All of these are dry cleaning symbols. The letters are to instruct the cleaner what type of solvent to be used.
  • Page 29 52026176...
