  • Page 1 USB Host CF Card CFU2 User’s Guide Jan. 2007 Rev. 1.0...

  • Page 2: Table Of Contents

    2-2. Connecting the PDA to the PC with ActiveSync ....6 2-3. CFU2 Host Driver Set Up ............. 7 2-4. CFU2 HID Driver Set Up ............8 2-5. CFU2 Mass Storage Driver Set Up ........9 3. Uninstallation ............10 4. Registration and Tech-Support ........ 11...

  • Page 3: Introduction

    1.Introduction The CFU2 is a USB1.1 Host CF card for use in CF Type II card enabled PDA. This User’s Guide describes how to install, use the CFU2. The information in the README file in the CD-ROM may include newer information. For the latest information, go to our home page.

  • Page 4: Package Confirmation

    1-2. Package Confirmation Check Package Contents: • CFU2 CF card • Cable • Software CD-ROM • Pull-out sticker • Quick Install Guide • Software Lisence Agreement NOTE If any of these items are missing, contact the supplier immediately. 1-3. System Requirements and Restrictions •...

  • Page 5: Usb Device Support

    2. To use the CFU2 on the PDA, PCMCIA Card or CF Type II slot is required. For a PCMCA Card slot, a CF Type II PCMCIA adapter is needed.

  • Page 6: Before Installation

    1-5. Before installation In order to pull CF Cards easily from the CF Card Slot, a pull-out sticker comes with the CFU2 package. If there is not an eject button for the CF card, use the sticker as follows. Serial # sticker...

  • Page 7: Installation

    1. Confirming a folder structure in the software CD-ROM (See 2-1). 2. Connecting the PDA to the PC system with ActiveSync (See 2-2). 3. Installing the CFU2 Host Driver (See 2-3). 4. Installing the HID Driver, if the USB device is an HID(Human Interface Device) such as a USB keyboard, USB bar code reader, etc (See 2-4).

  • Page 8: Confirming A Folder Structure

    2-1. Confirming a folder structure Folder structure in the software CD-ROM is as follows: Manual HostDriver hx2410 MassStorageDriver hx4700 HidDriver Japanese English 2-2. Connecting the PDA to the PC with ActiveSync For driver installation, ActiveSync is needed. The ActiveSync should come with the PDA.

  • Page 9: Cfu2 Host Driver Set Up

    2-3. CFU2 Host Driver Set Up Install the CFU1U Host Driver first. Insert the software CD-ROM into a CD-ROM drive. execute setup.exe in the [HostDriver] folder. Following window will appear. Click [Yes] to install the driver. When the installation is completed, the following window will appear.

  • Page 10: Cfu2 Hid Driver Set Up

    2-4. CFU2 HID Driver Set Up In order to connect a HID (Human Interface Device) such as an USB keyboard, USB bar code reader, install the HID driver. Insert the software CD-ROM into a CD-ROM drive. Execute setup.exe in [HidDriver\English] folder. Following window will appear.

  • Page 11: Cfu2 Mass Storage Driver Set Up

    2-5. CFU2 Mass Storage Driver Set Up In order to connect a mass storage device such as a USB Flash Disk, a USB MO, install the Mass Storage driver. Insert the software CD-ROM into a CD- ROM drive. Execute setup.exe in [MassStorageDriver] folder. Following win- dow will appear.

  • Page 12: Uninstallation

    3. Uninstallation Follow the instructions below to uninstall drivers. 1. Take the CFU2 card from the CF slot. 2. On the PDA, go to [settings]-[System]- [Remove Programs]. (Windows Mobile 5) 3. Select the driver to uninstall and click Remove button.

  • Page 13: Registration And Tech-Support

    3-3. Technical Support You can get a Tech support from RATOC at the following: Open 9:30AM-5:00PM(PST) Mon-Fri(except holidays) RATOC Systems International, Inc. Tech support Address: 2000 Wyatt Drive Suite 9 Santa Clara, CA 95054, United States Phone : (408)986-9040 Fax : (408)986-9042 E-mail : http://www.ratocsystems.com/english/contact/support.html...

  • Page 14: Specifications

    5. Specifications CFU2 USB1.1 Host CF Card Bus Interface : CF+ and CompactFlash Specifications Rev1.4 USB Interface: USB 1.1 Host Port(12Mbps/1.5Mbps) Connector: USB1.1 series A(Female) x 1 Max Bus Power: 100mA Power Consumption : 3.3V/5V 34mA at 3.3V(without any device connected) 27mA at 5V(without any device connected) Operating Requirements: Temperature 32 to 131°F(0 to 55°C)
  • Page 15 Appendix Trademarks -Windows is a registered trademark of Microsoft Corporation. -Other brand and product names may be registered trademarks or trademarks of their respective holders. Regulatory Agency Notice FCC Compliance Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
