- Page 1 COLOR TELEVISION VISION 9 37-9870 T VISION 9 42-9870 T VISION 9 47-9870 T...
-
Page 2: Table Of Contents
CONTENTS ------------------------------------------------------------------------------------------------ SET-UP AND SAFETY GENERAL INFORMATION Special features of your television Receiving digital stations What is Common Interface? CONNECTION/PREPARATION Connecting the antenna and the mains cable OVERVIEW Connections and controls on the television Inserting batteries in the remote control The remote control SETTINGS Searching for television stations... - Page 3 CONTENTS ------------------------------------------------------------------------------------------------ USING EXTERNAL DEVICES DVD player, DVD recorder, video recorder or set-top box High definition – HD ready Connecting a DVD player, DVD recorder, video recorder or set-top box Subwoofer Headphones Decoder or satellite receiver Camcorder Hi-fi system/AV receiver PC MONITOR MODE Connecting a PC OPERATION WITH COMMON INTERFACE...
-
Page 4: Set-Up And Safety
SET-UP AND SAFETY ------------------------------------------------------------ Please note the following information when setting up your television set. This television set is designed to receive and display video and audio signals. Any other use is expressly prohibited. External light falling on the screen impairs picture quality. To assure sufficient ventilation make sure there is enough space around it in the wall unit. - Page 5 SET-UP AND SAFETY ------------------------------------------------------------ The screen of your LCD television meets the highest quality standards and has been checked for pixel faults. Despite the great care taken in manufacturing, technological reasons make it impossible to completely discount the possibility that some pixels may be faulty.
-
Page 6: General Information
GENERAL INFORMATION ---------------------------------------- Special features of your television This television can receive and process all analogue and all unencrypted digital stations. This television set has an integrated digital and analogue receiver. The digital receiver unit converts the signals from digital stations to provide outstanding audio and picture quality. -
Page 7: Connection/Preparation
CONNECTION/PREPARATION ---------------------- Connecting the antenna and the mains cable Plug the cable of the rooftop or indoor antenna (passive or active indoor antenna with its own power supply for digital tele- vision stations) into the antenna socket »TUNER« on the tele vision set;... -
Page 8: Overview
OVERVIEW ---------------------------------------------------------------------------------------------- Connections and controls on the television... - Page 9 OVERVIEW ---------------------------------------------------------------------------------------------- Power switch, switches the device to standby mode and off again. AC IN Socket for the mains cable. TUNER Antenna socket. USB socket for service applications only. PC AUDIO IN Audio signal input for PC. Common Interface slot. PC-IN VGA VGA socket, video signal input for PC.
- Page 10 OVERVIEW ---------------------------------------------------------------------------------------------- HDMI4 HDMI socket, audio/video signal input (HDMI). HDMI3 HDMI socket, audio/video signal input (HDMI). Head phone connection (3.5 mm jack plug). S-VHS Video signal input for S-Video camcorder. VIDEO Video signal input for camcorder. Audio signal input for camcorder.
-
Page 11: Inserting Batteries In The Remote Control
OVERVIEW ---------------------------------------------------------------------------------------------- Inserting batteries in the remote control Open the battery compartment by removing the lid. Insert the batteries (3 x 1.5 V micro for example R03 or AAA). Observe the polarity (marked on the base of the battery com- partment). -
Page 12: The Remote Control
OVERVIEW ---------------------------------------------------------------------------------------------- The remote control Switches off the television set (stand-by). 1...0 Switches the television on from standby mode Selects channels directly. Opens the pre-selection for AV channels. Then select with » « or » «. Λ Displays information about the remote control. reveals answers in teletext mode. - Page 13 You can change this programming: Press and hold down »M« and press three number buttons to enter the code: »1«, »2«, »3« for a GRUNDIG DVD player. »4«, »5«, »6« for a GRUNDIG DVD recorder. »1«, »4«, »7« for a GRUNDIG digital receiver (remote control level 1).
-
Page 14: Settings
SETTINGS ---------------------------------------------------------------------------------------------------- Searching for television stations The television has an automatic tuning function, which first searches for digital TV channels and then analogue ones. You start the search and can then sort the television stations into your order of preference. There are 1000 presets for digital channels and 99 for analogue channels, to which you can assign TV stations from the antenna or from the cable connection (analogue channels). -
Page 15: Changing Stored Channels For Digital Stations
SETTINGS ---------------------------------------------------------------------------------------------------- Changing stored channels for digital stations You can change the order of the channels found as required, delete channels you do not need and block access to certain presets (parental control). Press » « (blue) to switch between »Program Management – All«, »Program Management –... -
Page 16: Deleting Channels
SETTINGS ---------------------------------------------------------------------------------------------------- Deleting channels In the »PROGRAM MANAGEMENT« menu, press » «, PROGRAM MANAGEMENT » «, »S« or »P«to select the channel to be deleted and Service Type: DTV Network Λ Program Type CA FAV1 FAV2 FAV3 FAV4 Lock press » «... - Page 17 SETTINGS ---------------------------------------------------------------------------------------------------- Creating a list of favourites You can select your favourite channels and save them in up to four lists (FAV1 to FAV4). In the »PROGRAM MANAGEMENT« menu, select the tel- PROGRAM MANAGEMENT evision channel with » «, » «, »S«...
-
Page 18: Picture Settings
SETTINGS ---------------------------------------------------------------------------------------------------- Picture settings Open the menu with »i«. PICTURE – The »PICTURE« menu is displayed. Brightness Contrast Activate the »PICTURE« menu by pressing »G«. Sharpness Colour Select »Brightness«, »Contrast«, »Sharpness«, »Colour«, »Noise Noise Reduction Reduction« or »Colour Temp.« with » «... -
Page 19: The 3-D Sound Projector
SETTINGS ---------------------------------------------------------------------------------------------------- The 3-D sound projector The integrated 3-D sound projector with 16 powerful loudspeakers creates a surround sound which can usually only be replicated by 5.1 systems. The surround sound is provided by sophisticated technology which activates the individual speakers with minimal delay. This generates bundles of sound waves and directs them to different points through- out the room, where they reflect off... -
Page 20: Automatic Installation Of The 3-D Sound Projector
SETTINGS ---------------------------------------------------------------------------------------------------- Automatic installation of the 3-D sound projector The sound of the 3-D sound projector needs to be directed towards your listening position. This setting is made automatically with the microphone supplied. Setting up the microphone Set up the stand as shown in the figure below. - Page 21 SETTINGS ---------------------------------------------------------------------------------------------------- Connecting the microphone Plug the microphone supplied into the microphone socket on the television. Set up the stand with the microphone in the listening position. SOUND Volume Sound Type Stereo Sound Art Mode Surround Starting automatic installation Tone Control Subwoofer Open the menu with »i«.
-
Page 22: Manual Installation Of The 3-D Sound Projector
SETTINGS ---------------------------------------------------------------------------------------------------- Manual installation of the 3-D sound projector To achieve an optimal sound, you can fine-tune the parameters for sound projection. Channel volume To get the same volume in all the channels, adjust the volume for each channel. SOUND Open the menu with »i«. - Page 23 SETTINGS ---------------------------------------------------------------------------------------------------- Projecting the sound Select »Beam Direct« with » « or » «. Λ – Switch the sound projection on and off with » « or » «. – If you select »On« for the sound projection, the »Angle« and »Focus«...
- Page 24 SETTINGS ---------------------------------------------------------------------------------------------------- Angle You can select the horizontal sound projection angle for sound. SOUNDART MANUAL SETUP Select Beam Left Front Beam Direct Select »Angle« with » « or » «. Λ Focus 1.5m Angle – Press » « to move the sound projection to the left or press » «...
-
Page 25: Sound Projector Settings
SETTINGS ---------------------------------------------------------------------------------------------------- Sound projector settings Open the menu with »i«. SOUND – The »PICTURE« menu is displayed. Volume Sound Type Stereo Select the »SOUND« menu with » « or » « and press »G« to Λ Sound Art Mode Surround confirm. - Page 26 SETTINGS ---------------------------------------------------------------------------------------------------- Stadium sound type mode This setting enables sound from the front left channel (FL), centre (C) and front right channel (FR). This provides excellent surround sound and is especially suitable when the listening position is very near the rear wall.
-
Page 27: Sound Control
SETTINGS ---------------------------------------------------------------------------------------------------- Night sound type mode This setting projects the sound to the centre. This is especially suit- able for low volume playback. SOUND Volume Sound Type Stereo Select the »Sound Art Mode« with » « or » «. Λ Sound Art Mode Night Tone Control... - Page 28 SETTINGS ---------------------------------------------------------------------------------------------------- Equaliser The equaliser offers you four preset sound settings (Music, Sport, Film and Speech) and one which you can create yourself (User). (Only available if the »Stereo« or »Night« settings are selected in the »Sound Art Mode« menu item.) Select »Equalizer«...
-
Page 29: Television Operation
TELEVISION OPERATION ------------------------------------------ Basic functions Switching on and off Press » «, »1…0« or » « or » « to switch on the device from Λ standby mode. Press the » « button to switch the television to standby mode. Selecting channels Use »1…0«... -
Page 30: Sound Settings
TELEVISION OPERATION ------------------------------------------ Displaying the time and information You can only open information about television channels in the di- gital television mode. ¥ Display information by pressing » «. Press » « to switch to the next programme, press » «... -
Page 31: Zap Function
TELEVISION OPERATION ------------------------------------------ Zap function This function allows you to save the television channel which you are currently watching and switch to other channels (zapping). Select the channel you want to save in the zap memory with »1…0« or » «... -
Page 32: Changing The Picture Format
TELEVISION OPERATION ------------------------------------------ Changing the picture format The television automatically switches to the 16:9 format if this format is detected via the Euro-AV socket. Select the picture format with » «. The selected picture format, for example »16:9«, appears on the screen. –... -
Page 33: Teletext Mode
TELETEXT MODE ---------------------------------------------------------------------------- TOP text or FLOF text mode Press »TXT« to switch to teletext mode. You can directly select teletext pages with »1...0«. To return to page 100, press »i«. Note: At the bottom of the screen, you will see an information line con- sisting of a red, green and, depending on the station, yellow and blue text field. - Page 34 TELETEXT MODE ---------------------------------------------------------------------------- Page stop A multiple page may contain several sub-pages, which are auto- matically scrolled by the transmitting station. Stop the sub-pages with »P«. Press »P« to quit the function. Calling up a sub-page directly If the selected teletext page contains further pages, the number of the current sub-page as well as the total number of pages is displayed.
-
Page 35: Convenience Functions
CONVENIENCE FUNCTIONS ------------------------------ Time settings Open the menu by pressing »i«. FEATURES – The »PICTURE« menu appears. Time Settings Timer Select the »FEATURES« menu with » « or » « and press »G« to Λ Menu Language confirm. Parental Control Menu Transparency Note: Software Update... -
Page 36: Timer Functions
CONVENIENCE FUNCTIONS ------------------------------ Timer functions Open the menu by pressing »i«. FEATURES – The »PICTURE« menu appears. Time Settings Timer Select the »FEATURES« menu with » « or » « and press »G« to Λ Menu Language confirm. Parental Control Menu Transparency Select »Timer«... -
Page 37: Changing The Menu Language
CONVENIENCE FUNCTIONS ------------------------------ Switch-off timer In the »OFF Time« menu you can enter a time for the television to switch off. After this time has elapsed, the television switches to standby mode. Select »OFF Time« with » « or » «. -
Page 38: Parental Control
CONVENIENCE FUNCTIONS ------------------------------ Parental control Open the menu by pressing »i«. FEATURES – The »PICTURE« menu appears. Time Settings Timer Select the »FEATURES« menu with » « or » « and press »G« to Λ Menu Language confirm. Parental Control Menu Transparency Select »Parental Control«... -
Page 39: Selecting The Transparency Of The Osd
CONVENIENCE FUNCTIONS ------------------------------ Changing the PIN code You can also enter a personal code instead of the default code »0000«. PARENTAL CONTROL Please take note of your own code. Parental Lock Parental Rating Select »Change PIN« with » « or » «... -
Page 40: Digital Functions
CONVENIENCE FUNCTIONS ------------------------------ Digital functions Open the menu by pressing »i«. FEATURES – The »PICTURE« menu appears. Time Settings Timer Select the »FEATURES« menu with » « or » « and press »G« to Λ Menu Language confirm. Parental Control Menu Transparency Select »Digital Features«... -
Page 41: Using External Devices
USING EXTERNAL DEVICES ---------------------------------- DVD player, DVD recorder, video recorder or set-top box Note: Which television socket(s) you connect your external devices to depends on the sockets the external device is equipped with and the signals which are available. Note that with many external devices the resolution of the video signal must be adapted to the input sockets on the television (check the external device’s instruction manual). - Page 42 USING EXTERNAL DEVICES ---------------------------------- With an analogue video signal (progressive) Video signal: YUV; resolution: standard 576p; HDTV 720p, 1080i, 1080p. Audio signal: stereo, analogue. Channel position »YPbPr«. Connect the »COMPONENT INPUT Y Pb Pr« sockets on the television and the corresponding sockets on the external device using cinch cables (video signal).
- Page 43 USING EXTERNAL DEVICES ---------------------------------- With an analog TV signal Video signal: FBAS. Audio signal: stereo, analogue. Channel position »CVBS«. Connect the »VIDEO« cinch socket on the television and the corresponding socket on the external device using cinch cables (video signal). Connect the »L R«...
-
Page 44: Subwoofer
USING EXTERNAL DEVICES ---------------------------------- Subwoofer Connecting the subwoofer Connect the »SUBWOOFER PRE OUT« socket on the television to the corresponding socket on the subwoofer using a RCA cable. Selecting audio settings for the subwoofer Open the menu with »i«. – The »PICTURE« menu is displayed. Select the »AUDIO«... -
Page 45: Decoder Or Satellite Receiver
USING EXTERNAL DEVICES ---------------------------------- Decoder or satellite receiver In order for the television to receive encoded programs from a privately operated station, a decoder is needed. Connecting a decoder or satellite receiver Decoder Connect the »AV1« socket on the television set and the appro- priate socket on the decoder using a EURO-AV cable. -
Page 46: Camcorder
USING EXTERNAL DEVICES ---------------------------------- Camcorder Connecting the camcorder Connect the yellow socket »VIDEO« on the television and the corresponding socket on the camcorder (VHS, Video 8) with a cinch cable (picture signal); connect the »S-VHS« socket (picture signal) on the television and the corresponding socket on the camcorder (S-VHS, Hi 8) with a S-Video cable. -
Page 47: Pc Monitor Mode
PC MONITOR MODE ---------------------------------------------------------- Connecting a PC Connect the socket »PC-IN VGA« on the television to the corre- sponding socket on the PC using a VGA cable. Connect the socket »PC AUDIO-IN« on the television to the corresponding socket on the PC using a cinch cable (audio signal). -
Page 48: Operation With Common Interface
OPERATION WITH COMMON INTERFACE Inserting the Common Interface module Note: Switch off the appliance before inserting the CI module in the »CI« slot. Insert the smart card into the CI module. Insert the CI module with the smart card into the »CI« slot on the television. -
Page 49: Special Settings
SPECIAL SETTINGS ------------------------------------------------------------------ Tuning digital television stations This search deletes all television stations included in the channel list! Tuning all digital television stations using the search Open the menu with »i«. SETUP – The »PICTURE« menu appears. Auto tuning Manual tuning Select the »SETUP«... -
Page 50: Tuning Analogue Television Stations
SPECIAL SETTINGS ------------------------------------------------------------------ Tuning the digital television stations by entering the channel numbers Open the menu with »i«. – The »PICTURE« menu appears. MANUAL TUNING Select the »SETUP« menu with » « or » « and confirm with » «. Λ... -
Page 51: Select »Store« With
SPECIAL SETTINGS ------------------------------------------------------------------ Tuning the analogue television channels by entering the channel numbers Open the menu with »i«. MANUAL TUNING – The »PICTURE« menu appears. Program no Select the »SETUP« menu with » « or » « and confirm with » «. -
Page 52: Changing Stored Channels For Analogue Stations
SPECIAL SETTINGS ------------------------------------------------------------------ Changing stored channels for analogue stations If channels were stored with the automatic channel search during the tuning of the television channels, you can delete them. You can also store stations in a different preset, change or enter the name of a stations as well as skip channels. - Page 53 SPECIAL SETTINGS ------------------------------------------------------------------ Locking television channels You can lock channels which are unsuitable for children using your personal PIN code. In the »PROGRAM MANAGEMENT« menu, select the television channel with » «, » «, »S« or »P«. Λ Press » «...
- Page 54 SPECIAL SETTINGS ------------------------------------------------------------------ Creating a list of favourites You can select your favourite channels and save them in up to four lists (FAV1 to FAV4). In the »PROGRAM MANAGEMENT« menu, select the television – channel with » «, » «, » «...
-
Page 55: Information
INFORMATION ------------------------------------------------------------------------------ Displaying signal information (only for digital television channels) Open the menu with »i«. – The »PICTURE« menu appears. Select the menu »SETUP« with » « or » « and press »G« to con- Λ firm. Select the menu »Digital Features« with » «... -
Page 56: Dismantling The Stand Of The Unit
INFORMATION ------------------------------------------------------------------------------ Dismantling the stand of the unit If you want to attach your television to the wall with a wall bracket, you need to dismantle the stand. Place the television carefully front down on a table on top of a suitable base, such as foam. -
Page 57: Technical Data
INFORMATION ------------------------------------------------------------------------------ Technical data Operating voltage: 220V-240V ~ 50-60Hz Power consumption: in operation 200 W (Vision 9 37), in operation 210 W (Vision 9 42), in operation 260 W (Vision 9 47), in standby < 1 W Sound output: max. 120 W Front 32 W sine wave Subwoofer 20 W sine wave Reception ranges:... -
Page 58: Troubleshooting
INFORMATION ------------------------------------------------------------------------------ Troubleshooting If the remedies given below do not work, please consult an autho- rised GRUNDIG dealer. Please bear in mind that malfunctions can also be caused by external devices such as video recorders or satel- lite receivers. Fault... -
Page 59: Additional Information For Units Sold In The Uk
INFORMATION ------------------------------------------------------------------------------ Additional Information for units sold in the UK. Units sold in the UK are suitable for operation from a 240V ac, 50Hz mains supply. The range of multi-system receivers is built to work in most European countries. However, the mains plug and socket system for the UK differs from many European countries. - Page 60 Grundig Multimedia B.V. Atrium, Strawinskylaan 3105 • NL-1077 ZX Amsterdam • http://www.grundig.com...
