PS Engineering PMA7000M-S-CAP Installation And Operation Manual

Pma7000-series audio isolation amplifier and audio selector
Hide thumbs
Table of Contents

Advertisement

Quick Links

Audio Control Panel, Marker Beacon Receiver and
PMA7000M-S-CAP
S o u n d Q u a l i t y . S o u n d E n g i n e e r i n g
Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of
PS Engineering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering,
Inc., 9800 Martel Road, Lenoir City, TN 37772. Phone (865) 988-9800
Stereo Intercom System
Installation
and
Operation Manual
FAA-Approved TSO C50c, C35d
Manufactured with pride by:
PS Engineering, Inc. 2000 ©
Copyright Notice
Document P/N 200-072-0004
Revision 4, Sept. 2000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PMA7000M-S-CAP and is the answer not in the manual?

Questions and answers

Related Manuals for PS Engineering PMA7000M-S-CAP

Summary of Contents for PS Engineering PMA7000M-S-CAP

  • Page 1 Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS Engineering, Inc. is strictly prohibited. For further information contact the Publications Manager at PS Engineering, Inc., 9800 Martel Road, Lenoir City, TN 37772. Phone (865) 988-9800...

  • Page 2: Table Of Contents

    Table of Contents 1 SECTION I GENERAL INFORMATION ................. 1-1 INTRODUCTION......................1-1 SCOPE ..........................1-1 EQUIPMENT DESCRIPTION ..................1-1 APPROVAL BASIS - FAA ....................1-2 SPECIFICATIONS......................1-3 EQUIPMENT SUPPLIED .....................1-4 EQUIPMENT REQUIRED BUT NOT SUPPLIED............1-4 LICENSE REQUIREMENTS ..................1-4 2 SECTION II - INSTALLATION ..................2-1 GENERAL INFORMATION ..................2-1 2.1.1 SCOPE........................2-1...
  • Page 3 PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual )...................3-1 UDIO ELECTOR LL MODELS 3.2.1 ....................3-2 PEAKER MPLIFIER )..............3-2 OWER WITCH PERATION ....................3-2 ICROPHONE ELECTOR ........................3-3 PLIT 3.5.1 ICS ......................3-3 PLIT 3.5.2...

  • Page 4: Section I General Information

    Off (Fail-safe) position. A six-station voice activated (VOX) intercom is included in the PMA7000-Series. This system has PS Engineering’s exclusive IntelliVox® circuitry that eliminates manual ad- 200-072-0004 Page 1-1 Rev.

  • Page 5: Approval Basis - Faa

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual justments. The system contains six separate VOX mic circuits, and only opens the micro- phone channel in use. The intercom system incorporates pilot isolate and crew modes, two stereo music inputs with "Soft Mute,"...

  • Page 6: Specifications

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual SPECIFICATIONS TSO COMPLIANCE Marker Beacon: C35d, Class A Audio Selector/Intercom: C50c, Class A APPLICABLE DOCUMENTS: RTCA/DO-214 RTCA/DO-143 RTCA/DO-160C RTCA/DO-178B Level D ENVIRONMENTAL Qualifications:...

  • Page 7: Equipment Supplied

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual Intercom Specifications Intercom Positions: 6 places (with individual IntelliVox® circuits) Music Inputs: 2 (Stereo) Music Muting: >-30 dB "Soft Mute" when Com or intercom active.

  • Page 8: Section Ii - Installation

    PS Engineering to arrange for a replacement. Under no circumstances attempt to install a damaged unit in an aircraft. Equipment re- turned to PS Engineering for any other reason should be shipped in the original PS Engi- neering packaging, or other UPS approved packaging.

  • Page 9: Mounting Rack Installation

    Refer to FAA Advisory Circular 43.13-2A for more information. Failure to use correct techniques may result in improper operation, electrical noise or unit failure. Damage caused by improper installation will void the PS Engineering warranty. 2.5.1 Noise Due to the variety and the high power of radio equipment often found in today's general aviation aircraft, there is a potential for both radiated and conducted noise interference.

  • Page 10: Existing Kma-24 Installation

    Adding a high-performance audio control system, particularly in conjunction with high- performance active noise canceling headsets, cannot improve on older avionics that were designed for cabin-speaker use. PS Engineering makes no claim that the audio panel will provide a noise-free audio quality under all installation conditions, particularly with older avionics.

  • Page 11: Power

    PTT switches to be used. Modify external PTT as required (See Appendix A). Additional capability can be added to the PMA7000MS for observer or additional trans- mit stations. Contact PS Engineering for information 2.5.6 Transmit Interlock Some communications transceivers use a transmit-interlock system. To fully utilize the Split Mode feature, this function must be disabled.

  • Page 12: Backlighting

    MIL-spec cable as shown. Connect the shields at the audio panel end only, and tie to the audio low inputs as shown. NOTE: The top connector harness can be custom made by PS Engineering, Inc. Simply call the factory and obtain a wire harness work-sheet. The harness will be made to your specifications and fully functionally tested.

  • Page 13: Com 3 Audio

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual Two stereo entertainment devices (CD player, cassette player, etc.) can be connected to the unit. Install two -inch stereo jacks in a convenient location so that the pilot can plug in the entertainment devices into the system.

  • Page 14: Pa Mute (J1, Pin 18)

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual 2.5.12 PA Mute (J1, Pin 18) Pin 18 of J1 is TTL logic output that is pulled low during PTT operation. This serves as an input to external public address system to prevent feedback during transmissions.

  • Page 15: Communications Antenna Installation Notes

    After wiring is complete, verify power is ONLY on pin 20 of the J1 (bottom connector) (dim power may also be at Pin D and F), and airframe ground on bottom connector pin Z. Failure to do so will cause serious internal damage and void PS Engineering's warranty. 2.10 Unit Installation To install the PMA7000M-S, gently slide the unit into the mounting rack until the hold- down screw is engaged.

  • Page 16: Operational Checkout

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Civil Air Patrol Version Installation and Operator’s Manual Warning: Do not over-tighten the lock down screw while installing the unit in tray. Internal damage will result. 2.10.1 Operational Checkout 1. Apply power to the aircraft and avionics.

  • Page 17: Receiver Sensitivity

    Complete log book entry, FAA Form 337, weight and balance computation and other documentation as required. Sample text for FAA Form 337, and instructions for continu- ing airworthiness can be found in Appendix F. Return completed warranty registration application to PS Engineering. 200-072-0004 Page 2-10...

  • Page 18: Section Iii Operation

    GENERAL INFORMATION SCOPE This section provides detailed operating instructions for the PS Engineering PMA7000M- S, and PMA7000S Audio Selector Panel/Intercom Systems, CAP versions. Please read it carefully before using the equipment so that you can take full advantage of its capabili- ties.

  • Page 19: Speaker Amplifier

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol pressed, it will stay in the "in" position. Press the switch again and it be in the "out" posi- tion and remove that receiver from the audio.

  • Page 20: Split Mode

    Split mode, particularly on adjacent frequencies. PS Engineering makes no warranty about the suitability of Split Mode in all aircraft conditions. Note: Split Mode does not turn off other (Nav, ADF, etc.) selected audio to pilot. However, the copilot will only hear the selected communications receiver.

  • Page 21: Intercom

    Moving your head through a vent air stream may cause the IntelliVox®to open mo- mentarily. This is normal. For optimum microphone performance, PS Engineering, Inc. recommends installation of a Microphone Muff Kit from Oregon Aero (1-800-888-6910). This will not only optimize VOX performance, but will improve the overall clarity of all your communications.

  • Page 22: Volume Control

    All passenger headsets are connected in parallel. Therefore, if a monaural headset is plugged in to a PMA7000M-S Stereo installation, one channel will be shorted. Although no damage to the unit will occur, all passengers will lose one channel. PS Engineering modifies headsets to add stereo capability, using high-fidelity speakers. Contact factory for details.
  • Page 23 PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol 3.6.3.1 Entertainment Input The audio selector panel has provisions for two separate entertainment input devices. They operate independently in the PMA7000M-S. The volume control does not affect music level.

  • Page 24: P-T-T Intercom Mode

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol Table 3-3 Intercom Modes Mode Pilot Hears Copilot Hears Passengers Hear Comments Isolate A/C Radios Copilot and passenger Passenger and Copilot This mode allows the...

  • Page 25: Section Iv- Warranty And Service

    During this one-year war- ranty period, PS Engineering, Inc., at its option, will send a replacement unit at our ex- pense if the unit should be determined to be defective after consultation with a factory technician.

  • Page 26: Appendix A External Ptt Hook Up

    PTT switch is depressed. A simple modification can be performed to allow proper intercom operation. NOTE: This mod does not alter normal operation. Below are some examples of typical modifications. Contact PS Engineering or the PTT manufacturer for more details if necessary.

  • Page 27: Appendix B Installation Drawing

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol Appendix B Installation Drawing 1.62 in Cutout size for front mount installation (41.15 mm) 6.31in (160.3 mm) 6.65 in (167 mm) Side View 0.60 in (15.25 mm)

  • Page 28: Appendix C Bottom Connector Interconnect

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol Appendix C Bottom Connector Interconnect Bottom Connector, J1 Com 1 Audio Hi Communications Notes: Com 1 Lo Transceiver #1 Com 1 Mic Audio Hi 1.

  • Page 29: Appendix D Top Connector Interconnect

    PS Engineering PMA7000M-S Series Audio Selector Panel and Intercom System Installation and Operator’s Manual for Civil Air Patrol Appendix D Top Connector Interconnect PMA7000M-S J2 TOP CONNECTOR (CAP) Pilot Phones (L) -see bottom connector. Copilot Phones (L) Copilot Phones (R) Copilot Phones Lo Pass.

  • Page 30: Appendix E- Instructions For Faa Form 337 And Continuing Airworthiness

    Aircraft equipment list, weights and balance amended. Compass compensation checked. A copy of the op- eration instructions, contained in PS Engineering document 200-072-( ), revision ( ), dated ( ), is placed in the aircraft records. All work accomplished listed on Work Order 9.2 Instructions for Continuing Airworthiness, Audio Panels...

  • Page 31: Appendix F Rtca Do160C Environmental Qualification Form

    Appendix F RTCA DO160C Environmental Qualification Form Audio Selector Panel/Intercom/Maker Beacon Receiver Part Number: 7000; 7000M; 7000S; 7000M-S FAA TSO Number: C50c, C35b Class A Manufacturer: PS Engineering Incorporated 9900 Martel Road Lenoir City TN 37772 Conditions Section Conducted Tests Temperature and Altitude Equipment tested to CAT A1 &...
