Page 1: User Guide
proHarmony.3 Slimline Bluetooth Hifi Headset for Music and Call Streaming with Bluetooth 3.5mm Audio Adapter User Guide ... - Page 2 Introduction Thank you for purchasing Promate proHarmony.3 Slimline Bluetooth Hifi Headset for Music and Call streaming with Bluetooth 3.5mm Audio Adapter. This Hifi Bluetooth Headset and adapter has been created with multiple functions, perfect sound quality, ultra-high reliability and uniquely fined outlook.
- Page 3 1 Product Overview Introduction proHarmony.3 is a Slimline Bluetooth Hifi Headset for Music and Call streaming with Bluetooth 3.5mm Audio Adapter. The Bluetooth 3.5mm audio adapter is a Bluetooth transmitter and receiver. When it is used as a Bluetooth transmitter, it can be connected to your walkman or PC to wirelessly transmit the music to your Bluetooth stereo receiver (Such as Bluetooth stereo headset, Bluetooth stereo speaker and so on).
- Page 4 Right loudspeaker Left loudspeaker Microphone Micro USB — Charging jack VOL+ — Volume up VOL- — Volume down Bluetooth 3.5mm Audio Adapter Multi-function button (MFB): Switching on/off, 3.5mm audio jack pairing Charging jack TX/RX switch LED indicator 3.5mm to 3.5mm audio cable 1.1 Charging the Headset The headset comes with a built-in rechargeable battery, prior to using it, it is recommendable to charge the battery fully for the first time.
- Page 5 Bluetooth 3.5mm audio adapter comes with a built-in rechargeable battery, prior to using it, it is recommended to charge the battery fully for the first time. When Bluetooth 3.5mm audio adapter is low power, red LED flashes. Please recharge the battery.
- Page 6 According to the indication, enter password or PIN No:”0000” and press ” Yes” or “confirm”; After successful pairing, select “proHarmony.3” in the Bluetooth device list, and press “connect”. After successful connecting, blue LED flashes twice or three times quickly every 4 seconds.
- Page 7 other Bluetooth audio player. Before pairing, please make sure your Bluetooth stereo receiver supports Bluetooth A2DP profile. The pairing steps are as follows: Under TX Mode Make sure the transmitter is off, otherwise switch it off; Keep the transmitter and your Bluetooth stereo receiver within 1 meter; Switch on your Bluetooth stereo receiver and make it enter pairing mode;...
- Page 8 Automatic connecting Every time the headset is turned on, it will connect to last connected device automatically. Manual connecting to last connected HFP device When the headset is in standby mode and doesn’t connect to any HFP devices, short press MFB button twice, it will connect to last connected HFP device automatically. Manual connecting to last connected A2DP device When the headset is in standby mode and doesn’t connect to any A2DP devices, short press...
-
Page 9: Wearing The Headset
3 Wearing the headset The headband of the headset is folding and retractable, please adjust according to the actual use. Logo “L” of the headset represents left ear, Logo “R” of the headset represents right ear. Please wear the headset according to the indication of the Logo. 4 Making a call with the headset Function Status of Headset... - Page 10 You have to select “transmit the sound via Bluetooth” in the settings menu and then choose “proHarmony.3” as speaker device. The music will be transmitted to the headset. Please refer to your cell phone’s user’s manual for further information.
- Page 11 6.2 When the headset is connected to a Bluetooth device LED indicator Status of Headset LED flashes red and blue alternately Pairing mode Blue LED flashes once every 2 seconds Standby mode (not connected to a Bluetooth device) Set up HFP or A2DP connection Blue LED flashes twice quickly every 4 seconds Blue LED flashes three times quickly every 4 seconds Set up HFP and A2DP connection...
- Page 12 the pairing mode. Make sure the headset is under the pairing mode and in the effective working range, and then the headset can be paired and connected. Why can’t hear the voice from the headset? Make sure the headset is turned on; Ensure the volume of the headset is not too low or mute;...
