Arrowhead SP850 Features And Specifications

Features
• 6 EOLR supervised zones
• Entry/exit timers can be assigned to separate zones
• Real time clock
• Last event alarm memory
• 2 on board programmable outputs plus bell output
• Up to eight user codes with opening/closing by user
• Automatic Test Timer for initiating a self test or a call for
downloading
• Two methods of programming:
1. Program locally from the keypad;
2. Download from ScanPro software
• Answering machine Bypass and Built-in Ring Count circuitry
allows unattended uploading/downloading
DOB Data Output Board
The optional DOB board provides eight additional open
collector outputs to the basic control panel. Programmable
outputs are:
• Remote Buzzer
• Door Strike
• Strobe light output
• Courtesy
• Arm/Alarm
• Ready/Trouble
• Smoke Power
• Fire/Burg Bell
KP600F Keypad
SP850 Security System
Description
The Arrowhead SP850 is a six zone, control panel/digital
communicator security system. The SP850 may be keypad
programmed or remotely downloaded from IBM-compatible
computers using ScanPro Downloader software. The ScanPro
software provides remote panel operation and system status
information. The SP850 comes in a steel enclosure and is
compatible with the optional KP600F LED or KP600L LCD/
alphanumeric keypad.
Two programmable open collector outputs are included for
Remote Buzzer, Door Strike, Strobe Light, Courtesy, Arm/
Alarm Status, Ready/Trouble Status, Smoke Power, Fire/
Burglary Bell or Single Bell assignments.
The SP850 readily converts from Keypad to Key Switch
configuration.
"Defeat Auto Lockout" feature for arming with E/E or
Follower zones violated.
Built-in Digital Communicator
The communicator reports all standard pulse reporting
formats, Silent Knight 4 + 2, Ademco Highspeed, and Arrow-
head ScanPro.
KP600L Keypad
UL Household Burglary/Fire
