  • Page 1: Table Of Contents

    6BXA TABLE OF CONTENTS 1. INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES....................1-1 1.3. PERFORMANCE LIST ..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium II Processor & AGP..........1-4 1.6. What is AGP ....................1-5 2. SPECIFICATION 2.1. HARDWARE .....................2-1 2.2. SOFTWARE......................2-2 2.3. ENVIRONMENT....................2-2 3.
  • Page 2 Table of Contents 3.11. PERIPHERAL DEVICE INSTALLATION ............3-9 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-9 4. BIOS CONFIGURATION 4.1. ENTERING SETUP ..................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu ....................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu......4-2 4.4.

  • Page 3: Introduction

    1. INTRODUCTION 1.1. PREFACE Welcome to use the 6BXA motherboard. It is a Pentium II / Celeron Processor based PC / AT compatible system with AGP/ PCI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want.

  • Page 4: Performance List

    Introduction 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor...

  • Page 5: Block Diagram

    6BXA 1.4. BLOCK DIAGRAM 66MHz SLOT 1 3.3V EDO/SDRAM DIMM Sockets Host Bus PIIX 4 CHIPSET Slot DRAM Bus 33MHz 66MHz 33MHz Clock 14.318MHz 66MHz 24MHz Generator 14.318MHz PCI Bus 33MHz 82443BX 48MHz CHIPSET USB Ports IDE Bus 14.318MHz USB Bus...

  • Page 6: Introduce The Pentium Ii Processor & Agp

    Introduction 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor...

  • Page 7: What Is Agp

    6BXA Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support 1.6 What is AGP...
  • Page 8 Introduction The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32- bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing.

  • Page 9: Specification

    6BXA SPECIFICATION 2.1. HARDWARE Pentium II / Celeron processor 233 – 633 MHz. 242 pins 66 MHz slot1 on board. 66/100 MHz system speed. SPEED 66 MHz AGP bus speed. (2X mode 133MHz) 33 MHz PCI-Bus speed. 8 MHz AT bus speed.

  • Page 10: Software

    Specification Supports 2 16550 COM ports. I/O PORTS Supports 1 LPT port. Supports 1 Floppy port. Supports 2 USB ports. Supports 1 PS/2 Mouse. Supports 1 PS/2 Keyboard. Suspend mode support. GREEN FUNCTION Green switch & Green LED support. IDE & Display power down support. Monitor all IRQ / DMA / Display / I/O events.

  • Page 11: Hardware Installation

    6BXA HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6BXA mainboard. The Retention Mechanism & Attach Mount USER'S MANUAL for mainboard. Cable set for IDE, Floppy devices. CD or diskette for Mainboard ¡ B S ound and VGA Utility.

  • Page 12: Mainboard Layout

    Hardware Installation 3.2. MAINBOARD LAYOUT COM A COM B CN 6 GAME&AUDIO USB PS/2 JP11 JP20 SOLO-1 SLOT1 INTEL 443BX PIIX4 BANK 2 BANK 1 BAT1 BANK 0 IDE 2 ATX POWER BIOS JP12 IDE 1 FLOPPY ×Figure 3.1Ø 3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS I/O Ports Connector USB port.
  • Page 13 6BXA JP4 : System Acceleration Pin No Function 1-2 short For 100MHz Turbo and other frequencies 2-3 short For 100MHz Normal J3:CPU FAN (CPU cooling FAN Power Connector) Pin No. Function GND. +12V Signal JP10 : Wake on Lan Pin No.
  • Page 14 Hardware Installation JP13 : Clear CMOS Pin No. Function 1-2 Short Clear CMOS. 2-3 Short NORMAL. JP18 / JP19 : Onboard Sound Function Selection Pin No. Function 1-2 Close Onboard Sound Function Enabled. 2-3 Close Onboard Sound function Disabled. JP17 : Onboard Sound Function Selection Pin No.
  • Page 15 6BXA JP16: PCI Bus Freq.Select (133MHz only) Pin No. Function Open 133MHz PCI 33MHz Close 133MHz PCI 44MHz JP20 : TEL:The Connector is for Modem with internal Voice connector Pin No. Function Signal Signal SB-LINK : For PCI Audio / Sound Card use only (Optional) Pin No.
  • Page 16 Hardware Installation JP5 : For 2X11 PINs Jumper P+P P S P K PW: Soft Power Connector Open: Normal Operation Short: Power On/Off RES: Reset Switch Open: Normal Operation Short: For Hardware Reset System P+P P : Power LED PIN 1 : anode (+) PIN 2 : cathode ( ) PIN 3 : cathode ( ) SPK: Speaker Connector...

  • Page 17: Dram Installation

    6BXA GD: Green LED PIN 1 : LED anode (+) PIN 2 : LED cathode ( ) 3.4. DRAM INSTALLATION The mainboard can be installed with 16 / 32 / 64 / 128 / 256 MB 168 pins DIMM module DRAM, and the DRAM speed must be 50 or 60 ns for EDO &...

  • Page 18: Cmos Rtc & Isa Cfg Cmos Sram

    Hardware Installation SW2: CLK RATIO X3.5 X4.5 X5.5 X6.5 The CPU is a sensitive electric component and it can be easily damaged by static electricity, so users must keep it away from metal surface when the CPU is installed onto mainboard. Note: We don’t recommend you to setup your system speed to 75, 83, 112 or 133MHz because these frequencies are not the standard specifications for CPU, Chipset and most of the peripherals.

  • Page 19: Hardware Reset Switch Connector Installation

    6BXA 3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION The RESET switch on panel provides users with HARDWARE RESET function. The system will do a cold start after the RESET switch is press and released by user. The RESET switch is a 2 PINS connector and should be installed to RES on mainboard.
