TABLE OF CONTENTS
1.
1.1. PREFACE.............................................................................................................1-1
1.2. KEY FEATURES ..................................................................................................1-1
1.3. PERFORMANCE LIST.........................................................................................1-2
1.4. BLOCK DIAGRAM ...............................................................................................1-3
1.6. What is AGP .......................................................................................................1-6
2.
2.1. HARDWARE ........................................................................................................2-1
2.2. SOFTWARE.........................................................................................................2-2
2.3. ENVIRONMENT...................................................................................................2-2
3.
3.1. UNPACKING ........................................................................................................3-1
3.2. MAINBOARD LAYOUT ........................................................................................3-1
3.3. QUICK REFERENCE FOR JUMPERS & CONNECTORS ................................3-2
3.4. DRAM INSTALLATION........................................................................................3-5
3.5. CPU SPEED SETUP ...........................................................................................3-6
3.6. CMOS RTC & ISA CFG CMOS SRAM................................................................3-7
3.7. SPEAKER CONNECTOR INSTALLATION ........................................................3-7
3.8. HARDWARE RESET SWITCH CONNECTOR INSTALLATION.......................3-7
3.9. POWER LED CONNECTOR INSTALLATION ...................................................3-7
II Processor ..........................................................1-4
1
Table of Contents
Advertisement
Table of Contents
Related Manuals for Gigabyte 6BXU
Summary of Contents for Gigabyte 6BXU
-
Page 1: Table Of Contents
Table of Contents TABLE OF CONTENTS INTRODUCTION 1.1. PREFACE......................1-1 1.2. KEY FEATURES ....................1-1 1.3. PERFORMANCE LIST..................1-2 1.4. BLOCK DIAGRAM ....................1-3 1.5. INTRODUCE THE Pentium II Processor ............1-4 1.6. What is AGP .......................1-6 SPECIFICATION 2.1. HARDWARE ......................2-1 2.2. SOFTWARE......................2-2 2.3. ENVIRONMENT....................2-2 HARDWARE INSTALLATION 3.1. - Page 2 6BXU 3.10. IDE & ATAPI DEVICE INSTALLATION.............3-7 3.11. PERIPHERAL DEVICE INSTALLATION............3-7 3.12. KEYBOARD & PS/2 MOUSE INSTALLATION..........3-8 3.13. SCSI DEVICE INSTALLATION .................3-8 BIOS CONFIGURATION 4.1. ENTERING SETUP .....................4-1 4.2. CONTROL KEYS ....................4-1 4.3. GETTING HELP....................4-2 4.3.1. Main Menu....................4-2 4.3.2. Status Page Setup Menu / Option Page Setup Menu.......4-2 4.4.
-
Page 3: Introduction
Introduction INTRODUCTION 1.1. PREFACE Welcome to use the 6BXU motherboard. It is a Pentium II Processor based PC / AT compatible system with AGP / PCI / SCSI / ISA Bus, and has been designed to be the fastest PC / AT system. There are some new features allow you to operate the system with just the performance you want. -
Page 4: Performance List
6BXU 1.3. PERFORMANCE LIST The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) -
Page 5: Block Diagram
Introduction 1.4. BLOCK DIAGRAM 14.318MHz SLOT1 3.3V EDO/SDRAM DIMM Sockets Host Bus INTEL 66/100 82443BX AGP Bus 66/100 CHIPSET 66MHz DRAM Bus Clock Gen Buffer 66/100MHz Clock Gen Ultra DMA/33 IDE Ports PCI Bus 66 / 100 PIIX4 48MHz 82371EB 14.318MHz USB Ports IDE Bus... -
Page 6: Introduce The Pentium Ii Processor
6BXU 1.5. INTRODUCE THE Pentium II Processor & AGP Figure 1:Retention Mechanism & attach Mount Figure 2:OEM Pentium II Processor... - Page 7 Introduction Figure 3:Heatsink / FAN & Heat sink support for OEM Pentium II Processor Figure 4:Boxed Pentium II Processor & Heat sink support...
-
Page 8: What Is Agp
6BXU 1.6 What is AGP The Accelerated Graphics Port (AGP) is a new port on the Host-To-PCI bridge device that supports an AGP port. The main purpose of the AGP port is to provide fast access to system memory. The AGP port can be used either as fast PCI port (32-bits at 66MHz vs. 32-bits at 33MHz) or as an AGP port which supports 2x data-rate, a read queue, and side band addressing. -
Page 9: Specification
Specification SPECIFICATION 2.1. HARDWARE Pentium II processor 200 – 633 MHz. 242 pins 66/100MHz slot1 on board. Speaker Alarm when detect "CPU FAN Failure" or PROTECTION “ CPU Overheat” . Automatically slow down CPU speed when "CPU Overheat". Intel LDCM supported. -
Page 10: Software
6BXU Support Mode 3,4 IDE & ATAPI CD – ROM. Supports 1 Ultra Wide SCSI port. SCSI PORTS Supports 1 Ultra SCSI port. Supports 2 Ultra II SCSI port. Supports 2 16550 COM ports. I/O PORTS Supports 1 EPP/ECP LPT port. - Page 11 Specification Electricity 4.9 V to 5.2 V. (Max. 20A current at 5V.)
-
Page 13: Hardware Installation
Hardware Installation HARDWARE INSTALLATION 3.1. UNPACKING The mainboard package should contain the following: The 6BXU mainboard. The Retention Mechanism & Attach Mount USER'S MANUALS for mainboard & SCSI device. Cable set for IDE, Floppy, SCSI & I/O devices. Diskettes and CD for Mainboard Utility. -
Page 14: Quick Reference For Jumpers & Connectors
6BXU PS/2 COMA COMB ISA 3 ISA 2 ISA 1 BIOS PCI 4 PCI 3 PCI 2 PCI 1 Slot 1 INTEL -LINK 443BX DIMM 1 BANK 0 PIIX4 DIMM 2 BANK 1 DIMM 3 BANK 2 BANK 3 DIMM 4... - Page 15 Hardware Installation IR Data Output IR Data Input Signal POWER (+) CPU FAN : CPU cooling FAN Power Connector Pin No. Function GND. +12V SENSE PWR FAN : Power FAN Connector Pin No. Function GND. +12V SENSE Panel FAN : Panel FAN Connector Pin No.
- Page 16 6BXU Signal Signal Signal JP8 : Wake on LAN Pin No. Function +5V SB Signal J14 : Case Open(Please remove shunted jumper before use.) Pin No. Function Signal JP10 : 2*11 PIN Jumper PW P+P-P- H JP10 SPKR PW: Soft Power Connector...
-
Page 17: Dram Installation
Hardware Installation PIN 2 : cathode ( ) PIN 3 : cathode ( ) SPKR : Speaker Connector PIN 1 : VCC PIN 2 : NC PIN 3 : NC PIN 4 : Data H H : IDE Hard Disk Active LED PIN 1: LED anode (+) PIN 2: LED cathode ( ) GN: Green Function Switch... -
Page 18: Cmos Rtc & Isa Cfg Cmos Sram
6BXU The system bus speed can be set to 66MHz or 100MHz form the jumper (JP5). The user can change the DIP SWITCH (SW) selection to set up the CPU speed for different processors. The CPU speed must match with the frequency RATIO and Front Side Bus (FSB) speed. -
Page 19: Speaker Connector Installation
Hardware Installation There're RTC & CMOS SRAM on board; they have a power supply from external battery to keep the DATA inviolate & effective. The RTC is a REAL- TIME CLOCK device, which provides the DATE & TIME to system. The CMOS SRAM is used for keeping the information of system configuration, so the system can automatically boot OS every time. -
Page 20: Scsi Device Installation
6BXU The main board supports PS/2 Mouse (J1). The BIOS will auto detect whether the PS/2 Mouse is installed or not & assign IRQ12 for PS/2 Mouse port if it is installed. After installing the peripheral device, the user should check everything again, and prepare to power-on the system. - Page 21 Hardware Installation System has EXT. SCSI port but has not INT. SCSI device EXT. 50pin SCSI port To boot from EXT.SCSI device, 8 bit SCSI Terminator please press <Ctrl> <A> for SCSISelect Utility and set the Advanced configuration option/ Support Removable Mainboard Disks Under BIOS as Fixed EXT.
- Page 22 6BXU State 2. LVD (Ultra II)SCSI Devices connecting to LVD Channel : CASE 1: Single Ended Termination : Both LVD Terminator Control : Enabled SCSI DEVICE SCSI DEVICE Mainboard Terminator ON Terminator ON To boot from EXT.SCSI device, EXT LVD SCSI Port please press <Ctrl>...
- Page 23 Hardware Installation EXT LVD SCSI Port LVD SCSI Terminator SCSI DEVICE SCSI DEVICE EXT. Mainboard LVD SCSI DEVICE Terminator ON LVD Terminator Disable State 3. Ultra or Ultra wide Device connecting to SE port LVD (Ultra II) device connecting to LVD port CASE 1: Single Ended Termination : Both LVD Terminator Control : Enabled SCSI DEVICE...
- Page 24 6BXU SCSI DEVICE SCSI DEVICE Mainboard LVD Terminator ON LVD Terminator ON System has only 8 bit SCSI device 8 bit 8 bit SCSI DEVICE SCSI DEVICE Mainboard Terminator ON Terminator OFF Terminator ON SCSI DEVICE SCSI DEVICE Mainboard LVD Terminator ON LVD Terminator ON System has EXT.
- Page 25 Hardware Installation System has EXT. SCSI port but has not INT. SCSI device EXT. LVD SCSI To boot from EXT.SCSI device, EXT. LVD SCSI port Terminator please press <Ctrl> <A> for SCSISelect Utility and set the Advanced configuration option/ Support Removable Disks Under BIOS as Fixed Mainboard EXT.
- Page 26 6BXU SCSI DEVICE SCSI DEVICE Mainboard LVD Terminator ON Terminator ON System has 16 bit & 8 bit SCSI device 16 bit 16 bit 8 bit 8 bit SCSI DEVICE SCSI DEVICE SCSI DEVICE SCSI DEVICE Mainboard Terminator ON Terminator OFF...
- Page 27 Hardware Installation System has EXT. SCSI port but has not INT. SCSI device To boot from EXT.SCSI device, EXT. LVD SCSI port please press <Ctrl> <A> for EXT. LVD SCSISelect Utility and set the SCSI Terminator Advanced configuration option/ Support Removable Disks Under BIOS as Fixed Mainboard Disks to “...
- Page 28 6BXU SCSI DEVICE SCSI DEVICE SCSI DEVICE SCSI DEVICE Mainboard LVD Terminator ON LVD Terminator ON LVD Terminator Disable System has only 8 bit SCSI device 8 bit 8 bit SCSI DEVICE SCSI DEVICE Mainboard Terminator ON Terminator OFF Terminator ON...
- Page 29 Hardware Installation EXT LVD SCSI Port LVD SCSI Terminator SCSI DEVICE SCSI DEVICE EXT. Mainboard LVD SCSI DEVICE Terminator ON LVD Terminator Disable System has EXT. SCSI port but has not INT. SCSI device To boot from EXT.SCSI device, please press <Ctrl> <A> for EXT.
- Page 30 6BXU SCSI DEVICE SCSI DEVICE SCSI DEVICE SCSI DEVICE Mainboard LVD Terminator ON LVD Terminator ON LVD Terminator Disable System has 8 bit EXT. SCSI port & 16 bit INT. SCSI device EXT. 50pin SCSI port 16 bit 16 bit...
- Page 31 Hardware Installation Adaptec 78xx Family Driver Installation for Windows NT CDROM Boot Installing Windows NT V4.0 The following instructions explain how to install the Adaptec 7800 Family Manager, while installing Windows NT V4.0 from CDROM Boot. 1. Start your system with the Windows NT Boot CD in the CDROM drive.
