Enterasys RoamAbout Installation And User Manual
Wireless ethernet adapter
Hide thumbs
Also See for RoamAbout:
- Installations and specifications (13 pages) ,
- Site preparation and installation manual (58 pages)
Related Manuals for Enterasys RoamAbout
Summary of Contents for Enterasys RoamAbout
- Page 1 ™ E N J O Y T H E F R E E D O M O F W I R E L E S S N E T W O R K I N G Wireless Ethernet Adapter Installation and User’s Guide E N T E R A S Y S .
- Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
- Page 4 Notice FCC Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 5 Notice RoamAbout PC Card Restrictions for EU/EFTA Countries to R&TTE Directive M ember states in EU with restrictive use for this product are crossed out ! Les états membres de l'Union Européenne avec une utilisation restrictive de ce produit sont rayés ! M itgliedsstaaten der EU mit eingeschränkten...
- Page 6 N'EST PAS autorisée sur le domaine public. De plus, le lien sans-fil NE DOIT PAS traverser une rue ou le domaine public). 3.Notre produit RoamAbout ne peut pas être configuré pour les canaux n°1 à 9 (2412 – 2446 MHz) pour une utilisation intérieure ou extérieure, à cause des conditions de l'ART concernant les limitations de puissance émise pour ces canaux.
- Page 7 Europe – EU Declaration of Conformity Hereby ENTERASYS Networks declares that this RoamAbout IEEE 802.11 PC Card is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC, Directive 89/336/EEC, and Directive 73/23/EEC. ENTERASYS Networks vakuuttaa täten että RoamAbout IEEE 802.11 PC Card tyyppinen laite on direktiivin 1999/5/EY, direktiivin 89/336/EEC ja direktiivin 73/23/EEC oleellisten vaatimusten ja sitä...
-
Page 9: Table Of Contents
Contents Preface Purpose of this Document ........... . xi Intended Audience . - Page 10 Table of Contents 4 Ethernet Adapter Manager Installation Installation ............. . . 4-1 Uninstall .
- Page 11 Table of Contents A Terminal Configurator Establishing a Direct Serial Connection ........A-2 Windows Procedure .
-
Page 13: Installation Procedure
This document describes how to install and set up the RoamAbout Wireless Ethernet Adapter. Intended Audience This document is intended for use by personnel who will install and set up the RoamAbout Wireless Ethernet Adapter. Organization of this Document This document is organized as follows:... -
Page 14: Associated Documents
Ethernet Adapter as a network serial port and as a serial telnet client. Appendix C Contains problem solving information. Associated Documents The following table lists the RoamAbout products and where to find additional information. Check the RoamAbout Wireless web site regularly for product upgrades and documentation. http://www.enterasys.com/wireless... -
Page 15: Getting Help
Preface Getting Help For additional support related to this device or document, contact Enterasys Networks using one of the following methods: World Wide Web http://www.enterasys.com/wireless Phone: North America: (603) 332-9400 Europe: 353 61 701 910 Asia: +800 8827-2878 Internet mail support@enterasys.com... -
Page 17: Site Requirements
Select the location to install the Ethernet Adapter. • Unpack the Ethernet Adapter, and check the contents of the shipment. NOTE: AP refers to the Access Point 2000 and the RoamAbout R2 Wireless NOTE Access Platform unless otherwise specified in this document. - Page 18 120 mA (excluding radio card) Temperature 0° C to 55° C Relative Humidity 0% to 90% (non-condensing) Radio Interface RoamAbout 802.11 PC Card Ethernet Interface RJ45 10BaseT (swapped to allow the use of a straight through cable when connected to a computer) •...
-
Page 19: Unpacking And Inspecting
Unpacking and Inspecting Unpacking and Inspecting Physically inspect all cartons for shipping damage. Report any damage to your shipping carrier. Also verify that you have received the correct basic components and options as listed on the following pages. Report any discrepancies to your Enterasys Sales Representative. -
Page 20: Ethernet Adapter
Unpacking and Inspecting Ethernet Adapter Verify that the following components shipped with your RoamAbout Ethernet Adapter: Description RoamAbout Ethernet Adapter 5.2V Universal AC to DC power adapter DC Power Cable AC Power Cord RS-232 serial cable • CD-ROM containing the RoamAbout Ethernet Adapter Manager software and the RoamAbout Wireless Ethernet Adapter Installation and User’s Guide in PDF. -
Page 21: Wireless Ad-Hoc Networks
The RoamAbout Wireless Ethernet Adapter transforms wired devices (for example., desktop computers and printers) into wireless devices. The RoamAbout Wireless Ethernet Adapter is easily integrated into your existing wireless network. The RoamAbout Wireless Ethernet Adapter can be used in the following wireless topologies: •... - Page 22 Wireless Infrastructure Network Figure 2-1: Infrastructure Network Example The re-association capabilities of the IEEE 802.11 standard enable clients to move throughout the wireless LAN area and roam between APs. Re-association can occur as long as the Ethernet Adapter has the same network name as the AP to which it is trying to make a connection.
- Page 23 Wireless Ad-Hoc Networks Wireless Ad-Hoc Networks Wireless ad-hoc networks, also known as peer-to-peer or independent networks, do not include APs. Instead, the ad-hoc network is a loose association, or workgroup, of computers that can communicate with each other using the PC Card in Ad-Hoc Mode. Figure 2-2 shows a network in which three Ethernet Adapter units are used to provide wireless connectivity between Ethernet devices.
-
Page 25: Installation
Chapter 3 Installation This section describes how to install the RoamAbout Wireless Ethernet Adapter. It also includes the installation of the PC (PCMCIA) wireless LAN card into the Ethernet Adapter. NOTE: The Ethernet Adapter does NOT include a RoamAbout 802.11 DS NOTE PC card. - Page 26 Installation Procedure 3) If you are planning to mount the Ethernet Adapter (optional), remove the bottom mounting plate as shown in Figure 3-2. Figure 3-2: Removing the Bottom Mounting Plate 4) Remove the small combs from the end cap. NOTE: The combs are generally not needed. The combs, when cut to an NOTE appropriate size, are for use only when the Ethernet Adapter is in an environment with extreme vibrations.
- Page 27 Installation Procedure 5) Gently insert PC card (face up) into the designated slot as shown in Figure 3-3. Figure 3-3: Inserting the PC Card 6) Replace the cap on the Ethernet Adapter that you removed in step 3 by snapping the cap straight down on the body. 7) If you are mounting the Ethernet Adapter, install the bottom mounting plate where desired as shown in Figure...
-
Page 28: Ethernet Adapter Led Indicators
13) Verify the Ethernet Link LED is illuminated (Table 3-1), indicating a valid Ethernet connection to your PC. 14) The RoamAbout Ethernet Adapter hardware is now ready for configuration using the RoamAbout Ethernet Adapter Manager. Proceed to Chapter 4 install the Ethernet Adapter Manager. -
Page 29: Installation
Ethernet Adapter Manager Installation This chapter describes how to install and configure the Ethernet Adapter Manager. The RoamAbout Ethernet Adapter Manager is used to configure the Ethernet Adapter. You can install it on a PC or workstation running Windows 95/98/NT/Me/2000. The Ethernet Adapter Manager allows you to graphically and remotely: •... -
Page 30: Uninstall
Uninstall 3) Click YES if you agree to the terms presented and allow the continuation of installation. Click NO if you do not agree, and terminate the installation. The Choose Destination window appears. 4) Choose the default path and location. Or, enter a selected path. 5) Click NEXT. -
Page 31: Using The Ethernet Adapter Manager
Ethernet Adapter units currently detected. All Ethernet Adapter units are controlled from this main window. Figure 4-1: RoamAbout Ethernet Adapter Unit List The RoamAbout Ethernet Adapter Unit List window buttons are: • SCAN Allows you to search for active Ethernet Adapter units. After a scan is executed, any previously displayed Ethernet Adapter units that are no longer found are removed from the list and found units are displayed. -
Page 32: Configuring The Ethernet Adapter
2) Click on the Configure button, or double-click on the desired Ethernet Adapter listing. The Configuration window (Figure 4-2) appears displaying information about the RoamAbout Ethernet Adapter Manager and the selected unit. Figure 4-2: Configuration Window NOTE: The versions listed in the Configuration window may not match your NOTE actual versions. - Page 33 Using the Ethernet Adapter Manager The Configuration window File menu pull-down options allow you to: • Save or load a configuration • Reset the Ethernet Adapter to factory defaults • Set a new password or clear it • Access a view of the log files •...
-
Page 34: Saving A Configuration
4-2). 3) Click on the File menu and select Save Configuration. 4) Browse to the directory where you would like to save the current configuration. The default path is the RoamAbout program directory. 5) Click Open. Loading a Configuration The Ethernet Adapter Manager allows you to reload a saved configuration file to a selected Ethernet Adapter. -
Page 35: Setting And Removing Passwords
Setting a password prevents unauthorized users from accessing or changing the settings on your Ethernet Adapter. You will need to enter this password each time you want to reconfigure the Ethernet Adapter. Enterasys Networks recommends that you set a password for each Ethernet Adapter. -
Page 36: Upgrading The Ethernet Adapter Firmware
Upgrading the Ethernet Adapter Firmware To update the firmware on your Ethernet Adapter, perform the following steps: 1) Download the latest version of firmware from the RoamAbout Wireless web site, www.enterasys.com/wireless, to the computer that is currently running the Ethernet Adapter Manager. The firmware file will have the extension “.rmu”. -
Page 37: Resetting To Factory Defaults
Using the Ethernet Adapter Manager Resetting to Factory Defaults This feature allows you to restore the Ethernet Adapter back to its original settings. 1) Go to the Ethernet Manager Configuration window (Figure 4-2) 2) Click on the File menu and select Reset to Default. All of the parameters are immediately restored to the factory default values. -
Page 38: Using The Log Viewer
Using the Ethernet Adapter Manager Using the Log Viewer The Log Viewer is used to: • display the different logs and tables stored on the Ethernet Adapter. • display status and error messages from the Ethernet Adapter Manager. To open the Log Viewer, perform the following steps: 1) Go back to the Configuration window (Figure 4-2) - Page 39 Using the Ethernet Adapter Manager Roaming Log The Roaming Log records association and disassociation events. Each association event is recorded with a timestamp and, if available, the AP MAC address. Each disassociation event contains only a timestamp. The timestamp indicates the number of 10 millisecond periods since the unit was turned on or reset.
-
Page 40: Pc Card Configuration
PC Card Configuration PC Card Configuration This section describes how to add the Ethernet Adapter to your wireless network. When the Ethernet Adapter has joined your wireless network, the PC card association LED is green. To configure the PC card settings, perform the following steps: Basic Tab Page 1) Open the configuration window for the desired Ethernet Adapter, as described in... - Page 41 PC Card Configuration 3) Enter the Network Name. The Network Name must match the AP, or match the name to which you will use to establish a Ad-Hoc network. The Network Name is case sensitive. The Network Name is used to specify a unique IEEE 802.11 wireless network.
-
Page 42: Advanced Tab Page
This feature sets the MAC address used by the wireless LAN interface, however it will release the MAC address upon disconnection. Check to ensure that the unit is set to DYNAMIC. Enterasys Networks recommends setting this option to DYNAMIC, unless you are performing an advanced configuration. -
Page 43: Encryption Tab Page
PC Card Configuration Built-in - Uses the radio MAC Address. Manual - you enter a MAC Address. 2) Select the AP Density. 3) Select the Transmit Rate from the drop-down menu. 4) Click on the Update and Reset Unit button. Encryption Tab Page The Encryption tab (Figure... - Page 44 PC Card Configuration To use encryption, perform the following steps: 1) Click on the Enable Encryption box. 2) Select the Transmit Key. NOTE: If you are using Ad-Hoc mode, you can only use Key 1. NOTE 3) Enter up to four encryption key values. If you are using Ad-Hoc mode, you can only use Key 1.
-
Page 45: Configuring The Ethernet Adapter To Connect To A Wired Ethernet Device
Configuring the Ethernet Adapter to Connect to a Wired Ethernet Device Configuring the Ethernet Adapter to Connect to a Wired Ethernet Device You can configure the Ethernet Adapter as a wireless device to connect to a wired unit, such as a computer or Ethernet printer, to your wireless network. The Ethernet Adapter can act as a wireless device, in addition to performing any one of the serial port applications discussed in the following chapters. - Page 46 Network Configuration 5) Enter the Netmask. This is a value that defines the range of IP addresses available within your local network. Figure 4-8: Network - Basic Tab Page 6) Enter the IP address of the gateway if your network uses a gateway (router or firewall).
-
Page 47: General Serial Configuration
Chapter 5 General Serial Configuration This chapter describes the general serial settings that are required for all serial port applications. For proper operation, the settings of the Ethernet Adapter always match the settings of the device to which it is connected via the RS-232 port. There are two groups of parameters that need to be configured to accomplish this task: the UART Settings and the Flow Control Settings. - Page 48 Configuration Flowchart Figure 5-1: Configuration Flowchart...
-
Page 49: Uart Settings
UART Settings UART Settings UART (Universal Asynchronous Receiver/Transmitter) is the fundamental hardware for serial communication. It controls the speed and method of data transfer of the serial port. To configure the UART settings, perform the following steps: 1) Clicking on the Serial tab. 2) Click on the UART tab. -
Page 50: Flow Control
Flow Control 4) Check the Data Bits setting of the device you are connecting to the Ethernet Adapter. Choose the Data Bits setting that matches the Data Bits setting of the device you are connecting to the Ethernet Adapter. Data Bits determine the number of bits used to transmit data. -
Page 51: Software Flow Control
Flow Control Software Flow Control Software flow control uses two special characters, called “Xon” and “Xoff”, which are embedded in the data to turn on or off the transmission of data from the source to receiver. In the incoming direction, flow control prevents the Ethernet Adapter from sending data when the computer is not ready to accept it. -
Page 52: Serial Packets
Flow Control Figure 5-3: Flow Control Tab Page Serial Packets The parameters on this tab page control the serial to network packet conversion process. Most users will not need to change the Serial Packet Parameters. These parameters control the way that data received on the serial port is divided into Ethernet packets. -
Page 53: Wireless Printing To A Serial Printer
Chapter 6 Wireless Printing to a Serial Printer This chapter describes how to configure the Ethernet Adapter to enable wireless printing to a serial printer. If you have an Ethernet printer this section does not apply. To connect to an Ethernet printer, follow the instructions to configure the Ethernet Adapter to a wired device in Chapter The LPD protocol requires an operating system, such as Windows NT, Me, 2000 or XP,... - Page 54 Configuring the Ethernet Adapter to Enable Wireless Printing 6) Click on the Flow Control tab. Verify that the Flow control settings of your Ethernet Adapter match those of your printer. NOTE: If the Flow Control settings do not match, there will likely be errors NOTE when printing.
-
Page 55: A Terminal Configurator
Appendix A Terminal Configurator This appendix describes how to use the Terminal Configurator to configure the Ethernet Adapter. The Terminal Configurator is an alternate method used to configure your Ethernet Adapter. The Terminal Configurator is a text-based configuration method. You can access the Terminal Configurator by one of the following methods: •... -
Page 56: Establishing A Direct Serial Connection
Establishing a Direct Serial Connection Establishing a Direct Serial Connection This method of configuring and managing an Ethernet Adapter uses a serial cable connected from the Ethernet Adapter to a computer running terminal emulation software. To configure the Ethernet Adapter using the Hyperterminal program, perform the following steps. -
Page 57: Accessing Console Management
Establishing a Direct Serial Connection 8) Choose None for the Flow control option. NOTE: The serial port settings needed for use by the Terminal Configurator NOTE will always be exactly as described here, regardless of the General Serial Settings (Chapter 9) Click OK after all of the COM settings have been chosen. -
Page 58: Establishing A Telnet Connection
Establishing a Telnet Connection Establishing a Telnet Connection This method opens a Telnet connection to the Terminal Configurator on port 23. Port 23 is the default for most Telnet programs. This only works after the Ethernet Adapter is assigned a TCP/IP address. If you need to assign the Ethernet Adapter an IP address you need to use the Ethernet Adapter Manager or the Terminal Configurator using a direct serial connection. -
Page 59: Main Menu Overview
It will then display all configuration settings and give the option to disable capture mode. This option can be used to keep a record of the settings made for a particular Ethernet Adapter unit, or to generate a file for Enterasys RoamAbout Technical Support if you have any difficulties. -
Page 60: The Editor
Using the Terminal Configurator Edit Configuration Menu The Edit Configuration menu contains three selections/Config files to edit. Return to Main Menu Goes back to the previous menu selections. System Brings up the editor screen with the configuration file for options that are not communication dependent. -
Page 61: Configuration File Format
Using the Terminal Configurator Configuration File Format The configuration file format is broken down into sections that define a particular grouping of options. Each section contains at the top a section header which is a string of text surrounded by square brackets: [ ] (the section title). After each section header, there is a list of entries containing equal signs. - Page 62 Using the Terminal Configurator [bridge] Bridge provides variables that are common to all radios. Bridge affects the behavior of radios. AP refresh period. Periodically an Ethernet Adapter pings an AP. The AP Refresh Period is the time, in units of seconds, between pings. The default for this value is 60 (which should be left at this default).
- Page 63 Using the Terminal Configurator [software] The [software] section is used to control the receiving and sending of bytes over the serial port. Proper setting of these values can significantly enhance the efficiency of data transmission because the radio is “packet based” and the UART is “stream based.” Stream based data means that the data is transmitted and received one byte at a time, without any mechanism to separate chunks of data from other chunks of data.
- Page 64 Using the Terminal Configurator • input timeout. The Input timeout is how long the Ethernet Adapter will wait after some data has been received on the UART before giving up on waiting for more. Once a character has been received the timer starts with this time- out.
- Page 65 Using the Terminal Configurator [flow control] The Ethernet Adapter supports the following six flow control options: Recognize RTS, Generate CTS, Recognize DTR, Generate DSR, Recognize XON/XOFF, and Generate XON/XOFF. It also supports the original RS-232 specification for flow control where CTS is generated only when RTS is asserted.
- Page 66 Using the Terminal Configurator immediately; otherwise, all of the data thereafter would be lost.) The host computer, however, would have to ask permission from the modem to send data. The host would do this by asserting the RTS line. The modem would see this, and check to see if it were ready to accept data.
- Page 67 Using the Terminal Configurator CTS and DSR are output lines. When set to “negate” or “assert,” they will output a continuous digital value. The value “negate” outputs a logic 1, or “mark” which is electrically negative. This is also the state seen on an RS-232 connector when the cable is unplugged.
- Page 68 Using the Terminal Configurator [telnet] The following section specifies the operating parameters for the Telnet protocol. • connect. This entry dictates what kind of prompt is seen on the serial port output. The two choices available are: wait for keystroke and command prompt.
-
Page 69: Network Bindings
Using the Terminal Configurator Network Bindings This section describes the meaning behind each of the entries that describe network binding. [rmpbind] This binding can be used for both the port protocol and for the I/O control socket setting. • protocol. This example uses the RMP protocol so the value of this entry is “rmp.”... - Page 70 Using the Terminal Configurator • transmit retry interval. When attempting additional transmit attempts as specified with “transmit try count” above, it can be useful to additionally specify how long to wait between attempts. This setting determines the time period for retransmission attempts. The value is specified in 1/100ths of a second, so that 100 means 1 second.
-
Page 71: Bridged Ethernet (Lan0
Using the Terminal Configurator • serial connect data. The format is the same as in socket connect data. This causes data to be written to the UART once a connection is successful. • serial disconnect data. This causes data to be written to the UART when the network connection has been closed. - Page 72 If using AP firmware V5.01 or later, make sure that the Station Firmware of the RoamAbout PC Card in each client is V4.52 or later. Otherwise, you cannot use Key 2, 3, or 4 as the transmit key. Refer to the RoamAbout Wireless Networking Guide for the procedure to check firmware versions.
- Page 73 Using the Terminal Configurator decrypting data on the radio. — encryption key 2. This value is one of the keys to use for encrypting and decrypting data on the radio. — encryption key 3. This value is one of the keys to use for encrypting and decrypting data on the radio.
-
Page 75: B Serial Line Configuration
Appendix B Serial Line Configuration This appendix describes how to perform wireless serial line replacement, configure your Ethernet Adapter as a network serial port, and configure your Ethernet Adapter as a serial telnet client. Serial Line Replacement Two Ethernet Adapter’s are required to perform wireless serial line replacement. Serial line replacement can operate with the radio in either Infrastructure or Ad-hoc mode. - Page 76 Serial Line Replacement To configure for the RMP Pipe protocol, perform the following steps: 1) Complete the Basic Radio Configuration instructions described in Chapter NOTE: If you are replacing a serial line or serial network with two or more NOTE Ethernet Adapter units without using an AP, ensure that your radio is using Ad-hoc mode.
- Page 77 Serial Line Replacement • Destination Address. This address tells the Ethernet Adapter where to send data received on the serial port. You may enter the RMP address of another Ethernet Adapter for direct serial line replacement. Other possible values are “dynamic” or “broadcast”.
-
Page 78: Tcp Pipe
Serial Line Replacement TCP Pipe TCP Pipe, like RMP Pipe, makes no changes to the serial data stream. TCP Pipe differs from RMP Pipe in that it creates two independent network connections for transmitted and received data. Using two connections allows each Ethernet Adapter to detect conditions when it has lost radio contact with the opposite unit, as can occur in environments with poor radio communication. -
Page 79: Network Serial Port
Network Serial Port Network Serial Port This section describes how to configure your Ethernet Adapter as a network serial port. Connection to a network serial port is accomplished over a TCP/IP socket connection. Any program that uses standard TCP/IP network sockets may be used to communicate with the serial port of the Ethernet Adapter. -
Page 80: Tcp Listen Port Configuration
Network Serial Port TCP Listen Port Configuration Complete the configuration described in Network Serial Port Configuration, steps 1–4, and then perform the following steps: 1) Click on TCP Listen Port in the Protocol list. 2) Click on the Listen Port tab. 3) Type in the port number on which the Ethernet Adapter will listen for a connection. -
Page 81: Serial Telnet Client
Serial Telnet Client Serial Telnet Client This section describes how to configure your Ethernet Adapter as a serial telnet client. Telnet is a method to connect and remotely log-in to a host computer or network device. The host computer or device must be running a telnet server for this service to be available. Once the telnet session is established from the Ethernet Adapter, any data received by the serial port of the Ethernet Adapter is sent to the host. -
Page 82: Command Prompt Connection Configuration
Serial Telnet Client 4) Leave the Reconnect After Shutdown box checked to allow a new session after closing an active one. 5) Click on the Update and Reset Unit button. Command Prompt Connection Configuration This section describes the command prompt connection method for a serial telnet client. The command prompt connection method provides a “telnet prompt”... -
Page 83: Problem Solving
Appendix C Problem Solving This appendix contains problem solving information for the RoamAbout Ethernet Adapter. If your Ethernet Adapter is not operating properly, please make sure the Ethernet Adapter is running the latest firmware, and use this guide before contacting Technical Support. If you receive an error message in your log file, save the error in the SAVE CONFIGURATION file. - Page 84 Table C-1: Problem Diagnosis Situation Problem Steps to take The power light is off The Ethernet Adapter is Verify that all physical connec- or the power light is not receiving power tions are securely in place. blinking. properly. Contact Technical Support if the problem persists.
- Page 85 Table C-2: Event Log Error Table All entries in the event log are preceded by a number. This number is a timestamp used by Technical Support, but is not relevant to looking up items in this table. Error Code Problem Steps to take Configuration Errors •...
- Page 86 Error Code Problem Steps to take • Check the entry in the xxxx: [yyyy]: “zzzz”: entry Entry zzzz in sec- configuration for zzzz. is invalid tion yyyy of file • If you cannot find zzzz in the xxxx contains an Ethernet Adapter Manager invalid value.
- Page 87 Error Code Problem Steps to take Hardware Errors FLASH failure. Unable to FLASH may be Contact Technical Support. read or write configuration. damaged. Configuration can- not be accessed or saved. Initialization of interface Radio could not be Try each of these steps in order. If “lan0”...
