Declaration of conformity to type
Dichiarazione di conformità
I hereby declare that the product
Qui di seguito si dichiarache il prodotto
7208E - 7218E
(Name of product, type or model, batch or serial number)
(nome del prodotto o modello, categoria o numero di serie)
Is conform to all relevant essential requirements of the R&TTE-directive 1995/5/EC, issued
March 9,1999. According to Annex IV of the R&TTE directive. The following standards and
essential radio test suites published in the "Official Journal" of the European Communities,
have been used to demonstrate the conformity of the product:
Product in class 1 frequency identification
Electrical safety:
Radio and spectrum engineering parameters:
Electromagnetic Compatibility EMC:
Certificate of conformity:
Expert Opinion:
Soddisfa tutti i requisiti applicabili alla tipologia del prodotto e richiesti dalla regolamentazione
delle telecomunicazioni secondo direttiva R&TTE5/9 allegato IV tramite l'utilizzo delle norme
pubblicate nella gazzetta ufficiale della Comunità Europea:
Prodotto in frequenza identificata come classe 1
Sicurezza elettrica:
Radio e parametri di trasmissione:
Compatibilià elettromagnetica EMC:
Certificato di conformità:
Certificato dell'esperto:
The product can be used in the following European Countries:
Il prodotto può essere immesso nei seguenti Stati Europei:
Company responsible for placing on the market:
Società responsabile per l'immissione nel mercato:
Address:
Via Luigi Galvani 12 - 21020 BODIO LOMNAGO (VA) - ITALY
Indirizzo:
Point of contact:
Andrea Rossi - Tel. +39 0332943211 - e-mail: a.rossi@gemini-alarm.com
Persona di contatto:
Bodio Lomnago - 19/09/2003
(Place, date) - (Luogo, data)
En 60950-2000
En 300220-1/1997
ETS 300683 : 1997
E811117M-CC
E811117M-EO
En 60950-2000
En 300220-1 /1997
ETS 300683 : 1997
E811117M-CC
E811117M-EO
A, B, D, DK, F, FR, GR,
IR, I, L , NL, P,SP, S, UK
GEMINI TRADING S.R.L.
(Signature) - (Firma)
7503
7502
7501
For all EU countries
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Gemini 7501
Summary of Contents for Gemini 7501
- Page 1 Address: Via Luigi Galvani 12 - 21020 BODIO LOMNAGO (VA) - ITALY Indirizzo: Point of contact: Andrea Rossi - Tel. +39 0332943211 - e-mail: a.rossi@gemini-alarm.com Persona di contatto: Bodio Lomnago - 19/09/2003 For all EU countries (Place, date) - (Luogo, data)
- Page 2 Wiring diagram art.7503 Push-button 2 Push-button 1 ALARMSYSTEMS 7503 MadeinItaly ALARMSYSTEMS Electronic key 7059 MadeinItaly 5123 AERIAL Do not tamper! Green/Black Brown Pink Black Green YELLOW-BLUE Brown RED-BLUE YELLOW-GREY BLACK marked R RED-GREY YELLOW-BROWN Battery 12 Volt RED-BROWN See locks diagrams BLACK marked M BLACK marked VM EARTH...
- Page 3 CCESSORY FUNCTIONS PROGRAMMABLE BY REMOTE INTRODUCTION GEMINI 7503. UNCTION ROGRAMMED AT FACTORY The 7503 system is a self-powered alarm control unit with built-in sensors and can be installed on cars OUND SIGNALS NABLED having a 12-volt battery with the negative pole earthed.
-
Page 4: Activating The Alarm System
ACTIVATING THE ALARM SYSTEM. Attempt to open boot. Attempt to open engine bonnet. The alarm can be activated by pressing key1 on the remote or by inserting the electronic key into the Intrusion detected by internal ultrasound volume sensor and optional external modules (even by appropriate socket. - Page 5 the protection system, key 1 on the remote is pressed accidentally and the alarm system is turned CCESSORY UNCTIONS off by mistake. EMORY OF LAST ALARM TRIGGERED The automatic activation of the alarm is evidenced by the regular visual signals described above. Indications regarding the last alarm condition detected (ALARM MEMORY) are provided by the The anti-distraction function activates the centralized door-locking control.
- Page 6 2) While the status LED is ON, press key 1 on the remote, the LED will turn off at once, reflecting EACTIVATING THE ALARM the activation of the GARAGE function. In this situation it is necessary for the user to get into the car to cause an alarm condition. At the To deactivate the GARAGE function, it is sufficient to connect the alarm system with the remote.
-
Page 7: Technical Data And Characteristics
The warranty is valid exclusively at centres authorized by Gemini Trading S.r.l. The manufacturer declines all liability for any anomalies/failures of the unit and/or the vehicle's electrical system caused by improper installation, tampering or improper use. The... -
Page 8: Instructions For Installation
DESCRIPTION OF HYPERFREQUENCY MODULE. GEMINI 7059. The 7059 sensor protects the car by detecting intrusions into the passenger compartment through the emission of a hyperfrequency electromagnetic field (f = 2.45 Ghz). The sensor operates according to the principle of reflection of high-frequency electromagnetic waves by means of conductors (metals, human bodies, etc.). - Page 9 Self-learning the code The magnetic sensor code is self-learned by the Gemini alarm system of the 7500 series or higher in the same way as the remote controls (instead of pressing the button, simply open the door or the window).
- Page 10 Diagram 2 Diagram 4 ALARMSYSTEMS 0,5 SECONDS ALARMSYSTEMS MadeinItaly 0,5 SECONDS MadeinItaly YELLOW-GREY RED-GREY RED-BROWN YELLOW-BLUE Common, Comun, Je nuch Z.V. RED-BLUE RED-BLUE YELLOW-BROWN YELLOW-GREY Open,Apre,Ouvre,Auf,Apertura,Abre YELLOW-BLUE RED-GREY Vehicles original Close,Chiude,Ferme,Zu,Cierre,Fecha door lock switch YELLOW-BROWN Do not connect, No conectar, Nicht verbinden Close RED-BROWN Do not connect, No conectar, Nicht verbinden...
- Page 11 Diagram 6 Diagram 8 6 SECONDS J1-J2-J3 POS.BC ALARMSYSTEMS MadeinItaly ALARMSYSTEMS 0,5 SECONDS MadeinItaly YELLOW-GREY 2355 RED-GREY Slave motor PINK PINK BROWN ref. 2306T YELLOW-BROWN YELLOW-GREY RED-BLUE WHITE-BLACK Original switch RED-GREY RED-BROWN Open Close Common WHITE-BLACK YELLOW-BROWN YELLOW-BLUE BLACK RED-BROWN COMFORT WHITE BROWN...
- Page 12 Diagram 10 Diagram 23 0,5 SECONDS OPEN = 0,5 SECONDS ALARMSYSTEMS MadeinItaly COMFORT = 25 SECONDS ALARMSYSTEMS MadeinItaly RED-GREY Negative RED-BLUE YELLOW-BLUE Common, Comun, YELLOW-BROWN Je nuch Z.V. RED-BLUE YELLOW-GREY Not connected, No conectar, Nicht verbinden YELLOW-GREY Open, Auf, Abre RED-BROWN RED-GREY YELLOW-BLUE...
- Page 13 Diagram 37 NOTE : Use : No.1 module 2343GE and No.1 module 2354GE OPEN = 0,5 SECONDS ALARMSYSTEMS MadeinItaly COMFORT = 25 SECONDS To PINK wire of RED 0,75 mmq. 2343 Gemini alarm Power YELLOW-BLUE window Negative motor RED-BLUE GREEN GREY...
