13. Press the Left Accessory Tray (99) and the
Right Accessory Tray (106) into the Console
Base (91).
14. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of clear
plastic on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the tread-
mill. Note: Extra hardware may be included. Keep the included hex keys in a secure place; the large hex key
is used to adjust the walking belt (see pages 27 and 28).
If you purchase the optional chest pulse sensor (see page 24), follow the steps below to install the re-
ceiver included with the chest pulse sensor.
1. Make sure that the power cord is unplugged.
Remove the indicated #8 x 3/4" Screw (1) and
the Access Door (87) from the Console Base
(91).
2. Connect the wire on the receiver (A) to the indi-
cated wire extending from the Console Base
(91). Hold the receiver so the small cylinder
is oriented as shown and is facing the
Console Base. Attach the receiver to the plastic
posts on the Access Door (87) with the two in-
cluded small screws.
3. Make sure that no wires are pinched.
Reattach the Access Door (87) with the #8 x
3/4" Screws (1). Discard the other wires in-
cluded with the receiver.
13
91
91
87
1
11
99
106
Wire
Small
Screws
A
Small
Cylinder
