Summary of Contents for GoVideo Sonic Blue DVP1100
-
Page 2: Insert Batteries
Unpack Your DVD player • DVP1100 player (1) • Remote control (1) • 1.5V AAA alkaline batteries (2) • Audio/Video cable (1) • User’s guide (1) • Warranty registration card (1) Insert Batteries Remove battery cover. Insert two 1.5V AAA batteries, paying attention to the correct polarities (+/-). -
Page 3: Table Of Contents
1 - Getting Started Welcome ...1 • Features...1 • Compatible Discs...1 Player Overview...2 • Remote Control ...2 • Front Panel Controls...4 • Front Panel Display ...5 • Rear Panel...6 2 - Connections Connecting the Player ...7 • Step 1 - Connect Video...7 •... - Page 4 • Angle ...22 • Subtitle...22 • Audio ...22 • Enhance ...22 • Memory ...23 • PS/IS ...23 • Vol/Channel...23 Play Mode...24 • Program Playback...24 • Repeat ...24 • PBC Control ...24 MP3 Playback ...25 Photo CD Playback ...25 Karaoke Playback...26 6 - Help Customer Service Information...27 Troubleshooting...27...
-
Page 5: Getting Started
:: Welcome Congratulations on your purchase of the DVP1100 DVD player! In case warranty service is required, please take a moment to attach your receipt to this manual and write down your Serial Number, located on the back panel of the DVD player: __________________________________. -
Page 6: Player Overview
:: Player Overview Remote Control POWER When the front panel POWER button is pressed in and the red Power LED is lit, press this button to switch the player between On and Standby modes. If the red power LED is not lit, this button will have no effect. - Page 7 23 SETUP While the disc is stopped, press to display the Setup menu for the DVD player. 24 DISPLAY Press to display disc information during playback. 25 PLAY MODE Press to set special play functions, including Repeat, Program Play and PBC (Playback Control for VCD discs).
-
Page 8: Front Panel Controls
Front Panel Controls POWER Press to power the player on and off. When this button is pressed in, the player is connected to the wall outlet and the red LED will light. When this button is released, the player is effectively disconnected from the wall outlet and the red LED will turn off . -
Page 9: Front Panel Display
Front Panel Display P B C M P 3 10 11 DVD Indicator Lights if a DVD disc is loaded. Play Status Indicator Rotates during disc playback. PBC Indicator Lights if a VCD disc is loaded with PBC (Playback Control). Track Indicator Shows current track number. -
Page 10: Rear Panel
Digital Audio Out (Optical) Connect to the optical digital audio input on your amplifier. 5.1 Channel Audio Outputs Connect to the analog audio inputs on your 5.1 channel amplifier. • Please continue with Chapter 2 to connect your DVD player. LISTED E216622 82LN... -
Page 11: Connections
Chapter 2 :: Connecting the Player Follow these steps to connect the DVD player to your TV and audio system. It is recommended that you turn off power on all com- ponents while you are connecting the player. Step 1 - Connect Video... -
Page 12: Step 2 - Connect Audio
Set your TV to the audio/video input to which you connected the DVD player. Set your audio system (TV, stereo or amplifier) to the audio input to which you connected the DVD player. The SONICblue DVD background image will appear. -
Page 13: Setup
Press to view the submenus under each heading. Also use to view menu options and confirm menu settings. Press to move up or down the list of submenus and to return to the main menu. • The DVD player must be in Stop mode to view the Setup menu. Setup... -
Page 14: Language Setup
:: Language Setup The Language menu allows you to set your language preferences for on-screen displays (OSD), DVD subtitles, DVD audio soundtracks and DVD disc menus. OSD Menu Language To select your preferred language for the player’s on-screen display and setup menu: From Stop mode, press SETUP. -
Page 15: Audio Language
Audio Language To select your preferred language for DVD audio soundtracks: From Stop mode, press SETUP. Select Language and press ENTER. Select Audio and press ENTER. Set the desired Audio Language to English (default), French or Spanish and press ENTER. Press SETUP to save and exit. -
Page 16: Video Setup
Select Video Out and press ENTER. Select the desired Video Out and press ENTER: S-Video (default) Select if you connected the DVD player to your TV using the S-Video output. Component Select if you connected the DVD player to your TV using the Component Video output. -
Page 17: Audio Setup
:: Audio Setup The Audio menu allows you to set the analog and digital audio outputs to correspond with the external components you have con- nected to the player. For example, if you connected the player to a TV using the Stereo Audio jacks, you should set Dolby Digital and DTS settings to 2 channel to enjoy downmixed stereo audio. -
Page 18: Dts Setting
DTS Setting Follow these steps to set the analog and digital audio formats of out- going DTS (Digital Theater Sound) soundtracks: From Stop mode, press SETUP. Select Audio and press ENTER. Select DTS and press ENTER. Set Analog Out to: 6 Channel (default) To output DTS 5.1 channel audio from the 5.1 channel analog audio outputs;... -
Page 19: Cd/Vcd Setting
CD/VCD Setting Follow these steps to set the outgoing analog and digital audio for- mat of CD and VCD tracks: From Stop mode, press SETUP. Select Audio and press ENTER. Select CD/VCD and press ENTER. Set Analog Out to: 2 Channel (default) To output 2 channel stereo audio from the stereo audio outputs;... -
Page 20: More Audio Setup
The More Audio menu includes Pro Logic and Subwoofer settings. Pro Logic Setting The DVD player has a built-in Dolby Pro Logic decoder to provide virtual surround sound for PCM (stereo) source material from the 5.1 channel analog audio outputs. -
Page 21: Rating Setup
The Rating menu allows you to block playback of DVDs based on their ratings. You can also restore all menu defaults. Setting the Password & Rating Level The DVD player allows you to block playback of inappropriate content with a password-protected Rating system (not all discs are rated). -
Page 22: Restore Defaults
Restore Defaults You can restore all menu items to their original factory settings. From Stop mode, press SETUP. Select Rating and press ENTER. Select Restore Default and press ENTER. Select the desired setting and press ENTER: (default) Leaves all menu items as they are. Restores all menu items to their original factory settings. -
Page 23: Basic Operations
Follow these steps to play a DVD, CD or VCD disc: Turn on the TV. Set the TV to the AV input connected to the DVD player. Turn down the volume on your amplifier and then power it on. Set the amplifier to the AV input connected to the DVD player. -
Page 24: Disc Menu Navigation
Disc Menu Navigation DVD disc menus allow you to select chapters for playback, change the disc’s default playback settings (such as Audio format and Subtitle language) and access any special features on the disc. Use the following keys to navigate DVD disc menus. MENU Press to bring up the disc menu for the currently loaded disc. -
Page 25: Advanced Features
Chapter 5 :: Special Playback Features Search To jump to a specific time, title/chapter, or track on your disc: Press SEARCH during DVD/CD playback. Use the arrow keys to select Time, Title/Chapter or Track. Use the 0-9 keys to enter the desired time (counter position in hours, minutes and seconds), title/chapter or track. -
Page 26: Angle
Continue to press ZOOM to select among 3 levels of mag- nification. Press ZOOM a fourth time to turn off this fea- ture. Angle Some DVDs contain scenes filmed from multiple angles. The Angle icon appears during playback if addi- tional angles are available. -
Page 27: Memory
• The bookmark will be cleared. PS/IS If you connected the DVD player to your TV using the Component Video Output, you can use the PS/IS button to switch to Progressive Scan for superior video quality. While playback is stopped, press PS/IS twice to switch to Progressive Scan mode. -
Page 28: Play Mode
:: Play Mode Play Mode allows you to set Program Playback, Repeat and PBC (Playback Control) options. Program Playback Program Playback allows you to play DVD titles/chapters (or CD tracks) in a custom order. You can program up to 12 titles/ chapters or tracks. -
Page 29: Mp3 Playback
MP3 is a popular music format which allows you to compress music tracks up to 1/10 of their original size while retaining near CD quality sound. Your DVD player can playback MP3 files burned onto a CD-R or CD-RW disc. -
Page 30: Karaoke Playback
• To advance to the next or previous image manually, use the | • To advance to a particular image number, use the 0-9 keys and then press ENTER. To manipulate images during the slideshow: • To rotate a picture clockwise, press the right arrow key. •... -
Page 31: Help
Chapter 6 :: Customer Service Information The FAQs below will help you solve common issues with your DVD player. If you don’t find the answers you need here, you can contact our Customer Service Department as follows: Phone (800) 736-7679 E-Mail customersupport@sonicblue.com... - Page 32 No sound. • Securely connect all audio cables. • Repair or replace any damaged audio or speaker cables. • Make sure the volume is turned up in VOL/CH setup. • Make sure the Audio Output settings are correctly matched to your TV and audio system. •...
-
Page 33: Technical Specifications
:: Technical Specifications General Power Requirements 120 VAC, 60Hz Power Consumption <25 W Video Standard NTSC Unit Weight (approx.) 5.5 lbs (2.5 kg) Unit Dimensions (approx.) 17” x 11.6” x 2.2” (432 x 295 x 56 mm) (w/h/d) Video Video Out 1.0Vp-p 75Ω, sync, negative polarity, RCA pin jack x 1 S-Video Out (separate Y and C signal output connector) -
Page 34: Warranty
Who Provides the Limited Warranty During the warranty period, the Go-Video Warranty Administrator will honor DVD player service for 90 days labor, 1 year parts from the original date of consumer purchase. See below for Commercial, Industrial or Educational use coverage. The DVD player remote control is warranted for 90 days from the date of purchase. -
Page 35: Safety
Go-Video Warranty Administrator SONICblue Corp. 7835 East McClain Drive Scottsdale, Arizona 85260-1732 (480) 922-0896 customerservice@sonicblue.com :: Safety Important Safety Instructions Read Instructions All the safety and operating instructions should be read before the product is operated. Retain Instructions The safety and operating instructions should be retained for future reference. Heed Warnings All warnings on the product and in the operating instructions should be adhered to. - Page 36 10 Power Sources This product should be operated only from the type of power source indicated on the marking label. If you are not sure of the type of power supply to your home, consult your product dealer or local power company. For products intended to operate from battery power, or other sources, refer to the operating instructions.
- Page 37 • When the power-supply cord or plug is damaged, • If liquid has been spilled, or objects have fallen into the product, • If the product has been exposed to rain or water, • If the product does not operate normally by following the operating instructions. Adjust only those controls that are covered by the operating instructions as an improper adjustment of other controls may result in damage and will often require exten- sive work by a qualified technician to restore the product to its normal operation, •...
-
Page 38: Safety/Regulatory Information
Safety/Regulatory Information Caution To prevent fire, shock hazard, or annoying interference, use only the recom- mended accessories. To prevent electric shock, do not use this (polarized) plug with an extension cord, recep- tacle, or other outlet unless the blades can be fully inserted to prevent blade exposure. To reduce the risk of electric shock, do not remove the unit cover or back. -
Page 39: Notes About Discs
DVD player. Dentro del DVD player no hay partes que requieren servicio. Diríjase solamente a personal calificado cuando requiera servicio. Attention Pour éviter les incendis, risque de chocs, ou interférences fâcheuses, employer seulement les accessoires recom- mandés. -
Page 41: Index
CLEAR 2, 20 Coaxial Digital Audio Out 13, 14, 15 2 Channel Compatible Discs 5.1 Channel Analog Audio Component 5.1 Channel Audio Outputs Component Video 13, 14, 15 6 Channel Component Video Output Composite Video Composite Video Output 3, 21 Connect Audio 3, 22 ANGLE... - Page 42 2, 20 PAUSE/STEP Program Playback Progressive Scan 3, 7, 23 PBC Indicator PS/IS 13, 14, 15 Photo CD Playback Rating Level 2, 4, 19, 20 PLAY Rating Setup Play Rear Panel Play Indicator Region 1 3, 24 PLAY MODE Remote Control Play Status Indicator Repeat Playing...
-
Page 43: Setup Menu Tree
:: Setup Menu Tree...
