Summary of Contents for Electrolux EWF 10679 W
- Page 1 User Manual Washing Machine EWF 10679 W...
- Page 3 Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable. You find some examples on the cover in this manual.
-
Page 4: Table Of Contents
4 contents electrolux Contents Safety information......5 Product description ......7 Control panel ........8 Use............9 Washing hints ........17 International wash code symbol ..20 Washing programme ....21-23 Programme information ....24-25 Care and cleaning ......26 Something not working....29 Techincal data .........33 Consumption values ......34 Installation ........36... -
Page 5: Safety Information
5 ● Safety Information Wash small items such as socks, laces, washable belts etc in a washing bag or pillow case as it is possible for such items to slip down between the tub and the inner drum. - Page 6 6 safety information electrolux ● ● If the appliance is installed in a Never use the washing machine if location subject to frost, please read the power supply cable, the control the “dangers of freezing”chapter. panel, the working surface or the base are damaged so that the inside ●...
-
Page 7: Product Description
7 Product description Your new appliance meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. The ECO valve system allows total use of detergent and reduces water consumption so saving energy. -
Page 8: Control Panel
8 electrolux control panel Control panel Programme selector dial Temperature button Spin reduction button Easy Iron button Extra rinse button Delay button Display Start/Pause button Time manger buttons... -
Page 9: Use
9 Child safety lock This device permits you to leave the First Use appliance not supervised without having the worry that children might be injured by or cause damage to the appliance. Ensure that the electrical and water ●... -
Page 10: Daily Use
10 electrolux use Daily Use If required, pour fabric softener into the compartment marked (the amount used must not exceed the “MAX” mark in the drawer). Close the drawer gently. Load the laundry Open the door by carefully pulling the door handle outwards. - Page 11 11 The selector dial is divided into following Select the temperature sections: Press this button repeatedly to increase or decrease the temperature, if you want your laundry to be washed at a temperature different from the one proposed by the washing machine.
- Page 12 12 electrolux use locked to indicate that the water must No spin option eliminates all the be emptied out. spin phases and increases the number To empty out the water, please of rinses for cottons, synthetics, deli- read the previous option steps.
- Page 13 13 Select the Delay start Cancelling the delayed start • Depress Start/Pause button. • Depress Start/Pause button, 0’ symbol is displayed. • Depress Start/Pause button again. The Delay Start cannot be selected with Drain programme. Before you start the programme, if...
- Page 14 14 electrolux use After you have pressed the Start/Pause Alarm codes button and the machine has started, the In the event of operating problems, Door icon is lighted-on and only the some alarm codes can be displayed, for phase running icon stays on. When the...
- Page 15 15 electrolux columns and margins use electrolux 15 Select the Start/Pause Select the “Time Manager” option To start the selected programme, press This function allows you to modify the the Start/Pause button; the green pilot washing time, automatically proposed light stops flashing.
- Page 16 16 electrolux use Cancelling a programme Fabric Soil Level Turn the selector dial to O to cancel a Cottons programme which is running. Now you can select a new programme. 95°C 60°C Opening the door after the 50°C programme has started 40°C...
-
Page 17: Washing Hints
17 Washing hints Rub particularly soiled areas with a special detergent or detergent paste. Treat curtains with special care. Remove hooks or tie them up in a bag or net. Sorting the laundry Maximum loads Follow the wash code symbols on each Recommended loads are indicated in garment label and the manufacturer’s... - Page 18 18 electrolux washing hints Oil based paint: moisten with benzine Detergents and additives stain remover, lay the garment on a soft Good washing results also depend on cloth and dab the stain; treat several the choice of detergent and use of the times.
- Page 19 19 Follow the product manufacturer’s recommendations on quantities to use and do not exceed the «MAX» mark in the detergent dispenser drawer. Quantity of detergent to be used The type and quantity of detergent will depend on the type of fabric, load size, degree of soiling and hardness of the water used.
-
Page 20: International Wash Code Symbol
20 electrolux International wash code symbol International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature... -
Page 21: Washing Programme
21 Washing programmes Programme/ Description of Type of laundry Options Temperature programme White and coloured Main wash from 95°C Cottons cotton: e.g. sheets, (cold) Spin Red. tablecloths, household Normal 3 rinses linen, shirts, blouses, 95°- Long spin underwear. -
Page 22: Washing Programmes
22 electrolux washing programmes Washing programmes Programme/ Description of Type of laundry Options Temperature programme Main wash from 40° Delicates Delicate fabrics, (cold) Spin Red. +Prewash heavy soiled fabrics. 3 rinses 40°-30°- Short spin Main wash from 40° Delicate fabrics, for (cold) Spin Red. - Page 23 23 Washing programmes Programme/ Description of Type of laundry Options Temperature programme Separate rinse cycle 3 rinses Spin Red. Rinse for cotton hand Long spin washed items. For emptying out the last rinse water in programmes with the...
-
Page 24: Programme Information
24 electrolux programme information Programme information Washing programme for machine washable wool Wool and well as for hand washable woollens and delicate fabrics Handwash with the “hand washing” care symbol Delicate washing programme suitable for silk and mixed synthetics items. Washing temperature is 30°C. -
Page 25: Programme Information
25 Programme information This programme can be selected for slightly or normally soiled cotton and synthetic items. The temperature will decrease and the washing time will be extended. This allows to obtain a good washing efficiency by saving energy. -
Page 26: Care And Cleaning
26 electrolux care and cleaning Care and cleaning Cleaning the dispenser drawer The washing powder and additive dispenser drawer should be cleaned regularly. Remove the drawer by pressing the You must DISCONNECT the appliance catch downwards and by pulling it out. - Page 27 27 • Remove any objects from the pump Cleaning the pump impeller by rotating it. The pump should be inspected if • the machine does not empty and/or spin • the machine makes an unusual noise during draining due to objects such as safety pins, coins etc.
- Page 28 28 electrolux care and cleaning Never remove the pump cover during a • When you intend to start the machine wash cycle, always wait until the up again, make sure that the room appliance has finished the cycle, and is temperature is above 0°C.
-
Page 29: Something Not Working
29 Something not working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Centre, please carry out the checks listed below. - Page 30 30 electrolux something not working Malfunction Possible cause Solution The machine fills then The end of the drain hose is Refer to relevant paragraph ● ● empties immediately: too low. in “water drainage” section. The machine does not The drain hose is squashed Check the drain hose ●...
- Page 31 31 Malfunction Possible cause Solution The door will not open: The programme is still Wait the end of washing ● ● running. cycle. Wait for the Door icon The door lock has not been ● ●...
- Page 32 32 electrolux something not working Malfunction Possible cause Solution The machine makes an The machine is fitted with a ● unusual noise type of motor which makes an unusual noise compared with other traditional motors. This new motor ensures a softer start and...
-
Page 33: Techincal Data
33 Technical data Dimensions Width 60 cm Height 85 cm Depth 63 cm Electrical connection Voltage Information on the electrical connection is given on - Overall power - Fuse the rating plate on the inner edge of the appliance... -
Page 34: Consumption Values
34 electrolux consumption value Consumption values Programme Water Energy Programme consumption consumption duration (in litres) (in kWh) (in minutes) Cottons Normal 95° 1.02 Cottons Eco 60° (*) Cottons + Prewash Cottons Eco + Prewash Synthetics 60° 0.85 Synthetics + Prewash... - Page 35 35 The consumption data shown on this (*) The programme “Cottons Eco ” chart is to be considered purely with 6 kg at 60°C is the reference indicative, as it may vary depending on programme for the data entered in...
-
Page 36: Installation
36 Installation Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the 4. Unscrew and remove the two large... - Page 37 37 electrolux installation 6. Open the porthole, take out the inlet Accurate levelling prevents vibration, hose from the drum and remove the noise and displacement of the machine polystyrene block fitted with the during operation.Never place cardboard, adhesive tape on the door seal.
- Page 38 38 3. Set the hose correctly by loosening In a sink drain pipe branch. This the ring nut. branch must be above the trap so that the bend is at least 60 cm above the After positioning the inlet hose, be ground.
-
Page 39: Environment Concerns
39 electrolux environment concerns Environment concerns Ecological hints Packaging materials To save water, energy and to help protect the environment, we recommend that you follow these tips: The materials marked with the symbol • Normally soiled laundry may be are recyclable. -
Page 40: Guarantee Conditions
40 European guarantee This appliance is guaranteed by Electrolux, in each of the countries listed in the following page, for the period specified in the appliance guarantee or otherwise by law. If you move from one of these countries to another of these... -
Page 41: Customer Service Centres
Slovensko +421 2 43 33 43 22 Suomi www.electrolux.fi Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm Türkiye +90 21 22 93 10 25 Tarlabași caddesi no : 35 Taksim Istanbul Россия +7 095 937 7837... - Page 43 ANC number: 192 999 820-00-122007...
