This example shows how to associate the Fabric Extender to an EtherChannel interface on the switch:
switch# configure terminal
Enter configuration commands, one per line.
switch(config)# interface port-channel 2
switch(config-if)# switchport mode fex-fabric
switch(config-if)# fex associate 100
switch(config-if)# exit
switch(config)# interface ethernet 1/19
switch(config-if)# switchport mode fex-fabric
switch(config-if)# fex associate 100
switch(config-if)# channel-group 2
switch(config-if)# exit
switch(config)# interface ethernet 1/20
switch(config-if)# switchport mode fex-fabric
switch(config-if)# fex associate 100
switch(config-if)# channel-group 2
switch(config-if)# exit
switch(config)# interface ethernet 1/21
switch(config-if)# switchport mode fex-fabric
switch(config-if)# fex associate 100
switch(config-if)# channel-group 2
switch(config-if)# exit
switch(config)# interface ethernet 1/22
switch(config-if)# switchport mode fex-fabric
switch(config-if)# fex associate 100
switch(config-if)# channel-group 2
switch(config-if)# exit
You have to associate each Ethernet interface that is a member of the EtherChannel as a fabric interface
Note
as shown in the above example.
This example shows how to display the association of the Fabric Extender and the switch:
switch# show interface port-channel 2 fex-intf
Fabric
Interface
---------------------------------------------------
Po2
Disassociating a Fabric Extender from an Interface
To disassociate the Fabric Extender from an interface, perform this task:
Command
switch(config-if)# no fex associate
FEX
Interfaces
Eth100/1/1 Eth100/1/2
Eth100/1/5 Eth100/1/6
Eth100/1/9 Eth100/1/10
Eth100/1/13 Eth100/1/14
Cisco Nexus B22 Fabric Extender for Dell Getting Started Guide
Configuring the Cisco Nexus B22 Fabric Extender for Dell
End with CNTL/Z.
Eth100/1/3 Eth100/1/4
Eth100/1/7 Eth100/1/8
Eth100/1/11 Eth100/1/12
Eth100/1/15 Eth100/1/16
Purpose
Disassociates the Fabric Extender unit attached to the
interface.
