- Page 1 In Car Video IVTV-01 Bedienungs- und Einbauanleitung Operating and installation instructions Notice d’emploi et de montage Istruzioni d’uso e di installazione Gebruiksaanwijzing en inbouwhandleiding Bruks- och monteringsanvisning Instrucciones de manejo e instalación Instruções de serviço e de montagem Betjenings- og monteringsvejledning...
-
Page 2: Table Of Contents
CONTENTS Safety notices ......15 Notes on installation and operation ........ 16 Tuner connection ......16 Remote control ......18 Functions ....... 19 Switching on the TV tuner ..... 19 Switching off the TV tuner ..... 19 Selecting TV/CATV/AV1/ AV2 mode ........19 Programming the TV/CATV channel ...... -
Page 3: Safety Notices
SAFETY NOTICES Thank you for choosing a Blaupunkt Safety notices product. We hope you enjoy using this Please observe the following safety new piece of equipment. notices during installation and whilst Please read these operating instruc- making the connections. tions before using the equipment for - Disconnect the negative and positi- the first time. -
Page 4: Notes On Installation And Operation
NOTES ON INSTALLATION AND OPERATION Notes on installation and operation Tuner connection - The tuner must first be installed in a suitable location. You must make sure that the device is fixed securely in place and that it is not subjected to moisture or dirt. - Page 5 NOTES ON INSTALLATION AND OPERATION Tuner connection Video output Audio output (R) Audio output (L) To the SAFETY CIRCUIT (refer to the notes on correct and safe system operation, VIDEO R SAFETY page 24) AV OUT 4 cables: 1. Ground/GND 2.
-
Page 6: Remote Control
NOTES ON INSTALLATION AND OPERATION Remote control MUTE Pressing this button switches off the sound of the monitor system. MENU MENU MUTE MON ON/OFF MON ON/OFF For switching on the monitor. UP/DOWN For selecting items in the TV ON/OFF OSD menu. TV ON/OFF ADJUST For switching on the... -
Page 7: Functions
FUNCTIONS Functions Selecting TV/CATV/AV1/AV2 mode The supplied remote control is suitable for operating the TV tuner IVTV-01 as You can use the TV/AV button to switch well as the ceiling mounted monitor between the channel/input options TV, IVMR-7001. CATV, AV1 and AV2. -
Page 8: Programming The Tv/Catv Channel
FUNCTIONS Programming the TV/CATV Channel selection channel You can select the channel you require using the two CHANNEL but- You can use the PROG button to store tons. If the channels were stored using the channels that you want for CATV or the automatic programming feature, you for the VHF/UHF range. -
Page 9: Av Output
FUNCTIONS AV output This connection option is used for send- ing the audio signal directly to the car sound system. In order to use this op- tion, the car sound system must be equipped with an AUX input. The video output is used to connect additional video screens and it only outputs the video signal. -
Page 10: Installation
INSTALLATION Installation Diversity antenna system The Diversity antenna system that is integrated in the tuner has been specially developed for mobile applications and ensures optimum signal reception. a. Installation Remove the protective covering from the antenna foot and secure the adhe- sive foot to the required position (the surface to which it is stuck must be free from dust and grease). - Page 11 INSTALLATION - Installation on the side window - Antenna attachment The supplied adhesive strips for the antenna achieve optimum adhesion after approx. 24 hours. You must not re-use adhesive strips once you remove them from the window. If you want to re-in- stall the antenna, you can use the supplied replacement adhesive strip, which can be cut to size with...
-
Page 12: Safety Circuit
INSTALLATION Safety circuit The tuner module has been fitted with a safety circuit to ensure safe TV operation. The supplied accessory components include a special safety cable. If the safety system is installed correctly, you can only activate TV operating mode if the vehicle handbrake is on. -
Page 13: Accessories
ACCESSORIES AND SPECIFICATIONS Accessories IR cable AV cable Electrical cable Safety cable Remote control with battery Operating instructions Specifications AV input 2 x AV RCA AV output 1 x AV RCA TV channels see page 19 Dimensions (W x H x D) 182 x 27.4 x 134 mm Weight 640 g... - Page 14 01-333 9575 01-324 8756 Poland (PL) 0800-118922 022-8771260 Turkey (TR) 0212-3350677 0212-3460040 (USA) 800-2662528 708-6817188 Brasil (Mercosur) (BR) +55-19 3745 2769 +55-19 3745 2773 Malaysia (Asia Pacific) (MAL) +604-6382 474 +604-6413 640 Blaupunkt GmbH 05/03 CM/PSS 8 622 403 179...
