- Page 1 61502G Gas hob Operating Instructions...
-
Page 2: Important Safety Information
Important Safety Information You MUST read these warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 350350 Installation This appliance must be installed and serviced by a competent person as stated in the Gas Safety ( Installation and Use) Regulations Current Editions and the IEE Wiring Regulations. - Page 3 Do not use this hob if it is in contact with water. Do not operate the hob with wet hands. Ensure the control knobs are in the ‘OFF’ position when not in use. When using other electrical appliances, ensure the cable does not come into contact with the hot surfaces of the cooking appliance.
-
Page 4: Table Of Contents
Contents Important Safety Information ................... 2 Instructions for the User ....................5 Description of the Hob ......................5 Operation ........................... 6 Maintenance and Cleaning ....................8 The Hob Top ......................8 Pan Supports ......................8 The Burners ......................8 The Ignition Electrode ....................8 Something Not Working? .................... -
Page 5: Instructions For The User
Description of the Hob 1. Hob Top 2. Rapid Burner 3. Semi-rapid Burners 4. Auxiliary Burner 5. Control knob for back right burner (semi-rapid) 6. Control knob for back left burner (semi-rapid) 7. Control knob for front left burner (rapid) 8. -
Page 6: Operation
Operation Hob burners control knobs The symbols on the knobs mean that : there is no gas supply there is maximum gas supply there is minimum gas supply Lighting the burners For easier lighting, proceed before putting a pan on the pan support. To light a burner: turn the relevant knob anticlockwise to maximum position (... - Page 7 Burner minimum maximum diameter diameter Large (rapid) 160 mm 240 mm Medium (semi-rapid) 120 mm 220 mm Small (auxiliary) 80 mm 160 mm As soon as a liquid starts boiling, turn down the flame so that it will barely keep the liquid simmering.
-
Page 8: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. The Hob Top Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little wasing up liquid has been added. -
Page 9: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. SYMPTOM SOLUTION There is no spark when lighting the Check that the unit is plugged in and the electrical supply is switched on Check that the RCCB has not tripped (if fitted) -
Page 10: Service And Spare Parts
Customer Care For general enquiries concerning your AEG-Electrolux appliance and for further information on AEG-Electrolux products, contact our Customer Care Department by letter or telephone at the address below or visit our website at www.aeg.co.uk For Customer Services in the Republic of... -
Page 11: Guarantee Conditions
Standard guarantee conditions We, AEG-Electrolux, undertake that if within 12 months of the date of the purchase this AEG-Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our discretion repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: •... -
Page 12: Instructions For The Installer
Instructions for the Installer Engineer technical data OVERALL DIMENSIONS Width: 580 mm Depth: 500 mm CUT OUT DIMENSIONS Width: 550 mm Depth: 470 mm SUPPLY CONNECTIONS Gas: R 1/2 inch (1/2 inch male) Rear right hand corner Electric: 230 V 50 Hz supply, 3 core flexible cable with non rewireable plug fitted with a 3 amp cartridge fuse. - Page 13 BURNER RAPID SEMI-RAPID AUXILIARY (large) (medium) (small) TYPE OF GAS POSITION M A X M A X M A X NOMINAL THERMAL POWER 0.65 0.45 0.33 NATURAL GAS 20 mbar NOMINAL FLOW VALUE = RATE 0.286 0.057 0.190 0.038 0.095 0.028 37.78 MJ/m NOZZLE...
-
