Vauxhall MY14.5 CASCADA Quick Start Manual

Infotainment Controls:
Want to take a call safely, or
need to find your way home?
Infotainment has everything in
one clear location to help. 1 2

ROOF

BASIC OPERATION:
The sky is the limit with the Cascada's automatic folding roof. Ability to operate from inside vehicle or externally
using the key remote gives you total control.
TO OPEN OR CLOSE:
Operable with ignition switch on, the soft top can be opened and closed while driving up to a speed of 31 mph.
To open soft top: To close soft top:
Pull switch until the soft top is completely Push switch until the soft top and the soft top lid are
opened and the soft top lid is closed. All completely closed. When the windows start to move up
windows will be opened during this operation. release switch, the windows will close automatically. All
To close all windows pull switch , windows will be opened at first during this operation.
Operation with remote control: Operation with remote control:
Press button until the soft top is opened Press button until the soft top, the soft top lid and the
completely and the soft top lid is closed. All windows are completely closed. All windows will be
windows will be opened during this operation opened at first during this operation
Confirmation of operation: Confirmation of operation:
Complete opening or closing of the soft top with Complete opening or closing of the soft top with the
the remote control is confirmed by the hazard switch in the centre console is confirmed by the sound of
warning flashers. an acoustic signal.
3 4 5 6 7 8
ROOF
ROOF OPERATION REQUIREMENTS:
• Load
compartment
partition is folded
out, pass-through
flap is closed. See
owners manual for
further details.
• Vehicle is
stationary or driving
with a speed up to 31 mph.
• Soft top lid is engaged in closed position.
• Boot lid is completely closed.
• Outside temperature is not lower than -7 °C for opening
and -10 °C for closing.
• Vehicle battery voltage is sufficient.
• The system is not overloaded by repeated operation
(max. 5 complete cycles in succession).
ATTENTION:
If any of these requirements are not
fulfilled, a warning chime sounds
and a message appears in the Driver
Information Centre when the switch is
actuated and the soft top will not open or
close. There must be no objects in front of
the rear window or in the pivot area of the
soft top and the soft top lid.

SEATING

Air Vents
1
Have a seat and make yourself comfortable. For maximum control and satisfaction, both seats and steering are
Infotainment Display
adjustable. All adjustments are within easy reach of your seat to easily find your perfect driving position.
2
Using the seat controls shown below, you can adjust the seat to your liking.
Radio Controls
3
Climate Controls
4
Indicator Controls
5
Display Dials
6
Cruise Controls
7
Steering Wheel Controls
8
RADIO BLUETOOTH
DIGITAL AUDIO BROADCASTING

MOBILE DEVICE - ACTIVATING BLUETOOTH:

Your Cascada's DAB(Digital Audio broadcasting)
Let's get your mobile device and car communicating.
radio gives you access to the latest digital
TO CONNECT YOUR MOBILE DEVICE:
broadcasts so you can enjoy crystal clear
ACTIVATE: BLUETOOTH® on your
interference free sound.
mobile device.
INFORMATION ON DAB:
PRESS: CONFIG button and select the
• Stations are indicated by programme name
Phone Settings menu item and then Bluetooth®.
instead of broadcasting frequency.
• As well as high-quality digital audio services, SELECT: YES on Pair Device screen
The mobile device will now appear in the
DAB is also able to transmit programme-
device list and can be operated via the Phone portal.
associated data and a multitude of other data
services including travel and traffic information.
Operate many of the functions on your mobile device via
• The receiver can pick up signals from
the Infotainment system including: making and receiving
broadcasting stations and, even if the signal is
calls, accessing messages, and accessing your contacts.
very weak, sound reproduction is ensured.
You can also manage your Bluetooth
• There is no fading (weakening of the sound)
through the Instrument Cluster. Please refer to the user
that is typical of AM or FM reception. The DAB
manual.
signal is reproduced at a constant volume.
Note: Not every mobile device supports all functions of
• Interference caused by stations that are on
the Phone portal. Deviations from the range of functions
nearby frequencies does not occur with DAB.
described with these specific telephones are possible.
If the DAB signal is too weak to be received, the
system switches over to the same programme

USB PORT:

on another DAB or FM station.
An MP3 player, USB device, iPod or Smartphone can
• If the DAB signal is reflected by natural
be connected to the USB port. The Infotainment system
obstacles or buildings, the reception quality of
can play music files contained in auxiliary devices. When
DAB is improved not impaired like traditional
connected to the USB port, the devices mentioned
AM/FM frequencies.
above can be operated via the controls and menus of the
• When reception is enabled, the FM tuner of
Infotainment system.
the Infotainment system remains active and
continually searches for receivable FM stations.
s
• Lift release lever and fold backrest forwards,
then slide seat forwards to the stop.
• To restore slide the seat backwards to the
stop. Lift backrest to upright position without
operating any lever.
• Ensure backrest engages. When fully engaged
the seat will be in original position again.
*Do not operate backrest inclination level while
backrest is folded forward. Certain seat controls
are model specific.
& USB LIGHTING
®
9

EXTERIOR LIGHTING:

Be seen, be safe. Equipped as standard on
Cascada, daytime running lights increase visibility
of the vehicle during daylight and are activated
automatically when ignition is on.
® connection
LIGHT SWITCH BASIC OPERATION:
= Activation or deactivation of automatic
light control. (switch returns to AUTO)
= Sidelights
= Low beam or high beam
PRESS BUTTON:
= Front fog lights
= Rear fog light
TURN THUMB WHEEL:
= Headlight range adjustment
= Instrument panel illumination
* Automatic light control is model specific.
