Infinity Alpha ™ Series
The Infinity Alpha Series of loudspeakers continues Infinity's
long-standing commitment to accurate sound reproduction. Our
patented Ceramic Metal Matrix Diaphragm
precision dividing networks and rigid, heavily braced enclosures
combine to deliver uncompromised performance in any stereo or
multichannel home theater system.The Infinity Alpha 25
perfect loudspeaker to complete any home theater system.
Unpacking the Speaker
If you suspect damage from transit, report it immediately to
your dealer. Keep the shipping carton and packing materials
for future use.
P
LANNING
Choosing Proper Placement and Setup
The Infinity Alpha 25 surround speaker can be used in side or
ES
rear channel applications. Please refer to the placement and
setup method for your application.The first step is to determine
the application for which your Infinity Alpha 25
speaker will be used.
If you are using the Infinity Alpha 25
a 5-channel home theater system or for side channels in a 6- or
7-channel home theater system (Application 1), please follow the
directions below.
If you are using the Infinity Alpha 25
6- or 7-channel home theater system (Application 2), please
follow the directions on page 3.
Placement (Application 1)
When using the Infinity Alpha 25
5-channel home theater system or for side channels in a 6-
or 7-channel home theater system, refer to Figures 1 and 2.
The speakers should be placed perpendicular to or slightly
behind the primary listening location, as shown.
Infinity Alpha 25
2
ES
™ (C.M.M.D. ™ ) drivers,
is the
ES
Y S
OUR YSTEM
surround
ES
for surround channels in
ES
as a rear speaker in a
ES
for surround channels in a
ES
F 1
– This overhead view shows a typical
IGURE
home theater plan.
Left
Center
Front
Channel
Channel
Couch
Left
Surround
Channel
F 2
IGURE
Left
Center
Front
Channel
Channel
Left
Surround
Channel Couch
Infinity
Right
Subwoofer
Front
(optional)
Channel
Right
Surround
Channel
Infinity
Subwoofer
(optional)
Right
Front
Channel
Right
Surround
Channel
