Summary of Contents for Bowens ESPRIT digital DX1000
- Page 1 ESPRIT DIGITAL INSTRUCTIONS BWL-0324/1 11-1-02 BOWENS INTERNATIONAL LIMITED 355 OLD ROAD OPERATING INSTRUCTIONS CLACTON-ON-SEA ESSEX CO15 3RH UNITED KINGDOM FOR THE 1000DX ( 117V ) Tel: +44 ( 0 ) 1255 422807 +44 ( 0 ) 1255 436342 Fax: www.bowensinternational.com...
-
Page 2: Specification
W=170mm H =125mm Weight 4.4Kg Due to our policy of constant product improvement Bowens International Limited reserve the right to change equipment specifications without notice. ACCESSORIES For details of all related products please contact your local distributor. Function Display Controls... -
Page 3: Safety Notes
If the unit appears to have developed a fault, first establish that it is a genuine internal fault and Welcome to the world-wide family of Bowens flash equipment users, and congratulations on not a case of normal operation such as overheat. Carry out the following checks to eliminate any selecting the Esprit Digital. -
Page 4: Flash Tube Replacement
Esprit Digital Operating Instructions QUICK START GUIDE FLASH TUBE REPLACEMENT The Esprit Digital is very simple to operate once the user has become familiar with the controls. Ensure that the unit is switched off and disconnected from the supply before replacing the flash Detailed operating instructions are given after this Quick Start Guide. -
Page 5: Fitting The Modelling Lamp
Digital 1000DX is fitted with a cooling fan and will cool faster if left switched on. cable supplied by your Bowens dealer to connect to the AC supply. A 3-wire, earthed (grounded), supply system must be used to ensure safe and reliable operation of the unit. - Page 6 Esprit Digital Operating Instructions FLASH DUMP Option MAIN CONTROLS & DISPLAY The preferred mode for the ‘AUTO-DUMP’ function can be selected from the ‘OPTIONS’ sub- menu as follows: Refer to Fig.2. The ‘FUNCTION’ button, the ‘UP’ , ’DOWN’ buttons and the three-digit display provide a simple means of setting and displaying the main functions.
- Page 7 Esprit Digital Operating Instructions If a transmitter set to a different channel number is activated within range of the unit with the IR UP & DOWN Buttons Remote enabled then the channel number of that unit will be briefly displayed. This allows a quick Select the required ‘FUNCTION’...
-
Page 8: Auxiliary Functions
Esprit Digital Operating Instructions ‘L’ - LAMP Display Mode The default factory setting is ‘Fd.0’. In this mode the unit resistively dumps excess energy whenever the flash setting is reduced. This is a relatively slow method and can take several When the ‘LAMP FUNCTION’...
