5. AUDIO CONNECTIONS

Although there are various ways to integrate the UCA200 into your studio or live set-up, the audio
connections to be made will basically be the same in all cases:

5.1 Wiring

Please use standard cinch cables to connect the UCA200 to other audio equipment. It exists to
connect also the possibility a mono adapter cable.
Fig. 5.1: Wiring standard cinch cables
Fig. 5.2: Mono adapter cable
