AZAMERICA S809 Owner's Manual

Digital satellite receiver
Hide thumbs
Table of Contents

Advertisement

Quick Links

User´s Guide
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S809 and is the answer not in the manual?

Questions and answers

Related Manuals for AZAMERICA S809

Summary of Contents for AZAMERICA S809

  • Page 1 User´s Guide...
  • Page 2 English...

  • Page 3: Table Of Contents

    GENERAL INFORMATION Main Features For your Safety Unpacking General Operation INSTALLATION Front Panel Rear Panel Connecting to TV using RCA support Connecting to Digital Amplifier MENU INFORMATION Main Menu 1. Channel List 1.1 TV Channel List 1.2 Radio Channel List 1.3 Delete All 2.
  • Page 4 4. Tools 4.1 Information 4.2 Factory Setting 4.3 Upgrade by USB 4.4 Conditional Access 4.5 USB Network Local Setting 4.7 Upgrade by Network 5. Game 6. REC 6.1 Record Mangager 6.2 PVR Setting 6.3 HDD Information 7. Hot key 7.1 Info 7.2 EPG 7.3 Find 7.4 Numer...

  • Page 5: General Information

    A Digital Satellite Receiver is a convenient product that allows you to view a variety of programs provided through satellite. This user's guide covers the installation of the DSR and the necessary steps to implement various features. This also explains special features available only in this DSR in detail, which will allow you to make full use of these features.

  • Page 6: For Your Safety

    For Your Safety To avoid electric-shock hazards, do not Keep the receiver away from flower vases, open the cabinet, refer servicing to qualified tubs, sinks, etc., in order to avoid damaging personnel only. the equipment. Do not expose the receiver un-der the Do not block ventilation holes of the sunlight.

  • Page 7: Unpacking

    Remote Control Guide AV cable General Operation Throughout this manual you will notice that the everyday operation of the receiver is based on a series of user friendly on screen display and menus. These menus will help you get the most from your receiver, guiding you through installation, channel organizing, viewing and many other functions.

  • Page 8: Rcu

    Function Turns power ON/OFF of the DSR When watching a channel, mute the sound Enter number of the required menu item or select a channel number to watch TV/RADIO Switches between TV and Radio mode Switches back to previous channel Displays the favorite group list Timeshift function key SHIFT...

  • Page 9: Installation

    Rear Panel Front Panel Rear Panel Rear Panel CONNECT TO TV SET OR VIDEO PROJECTOR YPbPr OR COMPONENT INPUTS RF : CONNECT TO TV ANT INPUT CONNECT TO A PC FOR S/W UPGRADE POWER ON/OFF CONNECT TO A DIGITAL AMPLIFIER CONNECT VIDEO TO TV USING RCA JACK CONNECT TO AUDIO R/L TO TV OR AUDIO TUNER LNB IN: CONNECT TO SATELLITE ANTENNA...

  • Page 10: Connecting To Tv Using Rca Support

    Connecting to TV using RCA support Satellite VIDEO AUDIO Dish Connecting to Digital Amplifier Satellite Dish DIGITAL AUDIO CONVERTOR OR AMPLIFIER DIGITAL AUDIO SPEAKER...

  • Page 11: Menu Information

    Main Menu Make sure that you have properly installed and connected the cables of the receiver well. If the receiver is the factory status or there is no program list, when power on, the Main Menu window will be displayed on the screen. During the normal TV/Radio mode, press MENU key on the RCU to enter into the Main Menu window.

  • Page 12: Channel List

    1. Edit Channel 1. Press OK key or key to pop up the "Input Password" dialogue, you can not enter into the menu unless the correct password is inputted. The default password is "0000". 2. Press PR+, PR- keys to move the cursor up or down.
  • Page 13 6. Press yellow colour key to move the Move button upward. Select the program and press OK key to mark this program with the move mark. Press PR+, PR- keys to move the cursor to the position where you want to locate and press OK key to confirm.

  • Page 14: Radio Channel List

    Numeric keys Press numeric key repeatedly, display in circle .,*?!@1 ABC2 DEF3 GHI4 JKL5 MNO6 PQRS7 TUV8 WXYZ9 [space]_-0 If the name is empty, system will pop up a dialogue informing "Name" once yellow colour key is pressed. Press OK key to close this dialogue. iii.

  • Page 15: Antenna Connection

    2. Press PR+, PR- keys to move the cursor up or down. 3. Press EXIT key or key to move the focus to the left menu. 2.1 Antenna Connection Press keys to select between Motor Antenna and Fixed Antenna. 2.2 Satellite List 1.

  • Page 16: Antenna Setup

    2.3 Antenna Setup Part A: Fixed Suppose that you have selected Fixed Antenna in the Antenna Connection window. 1. Satellite: All selected satellites in the satellite list are displayed in this item. Press keys to select the satellite in circle. Or press OK key to pop up the drop-down list, then select the desired satellite in the list and press OK key to confirm.

  • Page 17: Single Satellite Search

    5. Limit Setup: Press OK key to pop up the Limit Setup window. Limit Setup: Press keys to switch among Disable Limit, East Limit and West Limit. Limit Setup: Move cursor to the Limit Setup button. You can press key to turn west , or press to turn east.

  • Page 18: Multi Satellite Search

    4. Network Search: Select between No and Yes. This item turns grey when Auto Scan is selected in the following Scan mode item. 5. Scan Mode: Press keys to select between Auto Scan and Preset Scan. Auto Scan is Blind scan, while Preset Scan is to search the preset frequencies.

  • Page 19: System Setup

    3. Press green colour key to pop up the Add TP window. Since the same operation as the above Edit TP window, here we don't explain any more. 4. Press yellow colour key to pop up dialogue " Are you sure to delete?". Press OK key at the Yes button to delete the selected TP, or press EXIT key to cancel the operation.

  • Page 20: Local Time Setting

    3.2 TV System Press PR+, PR- key to move the cursor up or down, while press keys to change the setting and the setting will take effect immediately. 1. Display Mode: Select among PAL-M, PAL-N, NTSC. 2. Video Output: Select between RGB and CVBS. 3.RF System: Select among NTSC, PAL-BG, PAL-I and PAL-DK.

  • Page 21: Parental Control

    2. Timer Service: Select between Channel and Record. If Channel is selected, the Wakeup Channel is displayed in the following item. If Record is selected, the Wakeup Record is displayed in the following item. 3. Wakeup Date, On Time: Use numeric keys to input the valid date.

  • Page 22: Favorite

    3.7 Favorite There are 32 favorites group listed in this window. Press PR+, PR- keys to select one and press OK key to the Rename window. Since the same operation as the above the Add Satellite window, here we don't explain any more. 3.8 Other 1.

  • Page 23: Upgrade By Usb

    Upgrade Mode File feature All code : File named as "*.abs" Main Code: File named as *.bin Radio back: File named as "*.m2v", the picture will be used as both radio back and menu back Default db: File named as "*.bin" Select the upgrade mode and upgrade file, then you can start upgrade by USB.

  • Page 24: Usb

    4.4.4 Maturity Level Input the PIN then Move cursor to Select Maturity level,you can select A- Over18,X-Erotic,G-General audience,PG-Parental Guidance,move cursor to Change Maturity level button and press OK key,and then system will pop up a dialogue informing you the changing result. 4.4.5 Subscription Status Know the detail information of Subscription Status.

  • Page 25: Network Local Setting

    Setup Slide Show Time: Select among 0-9sec. Slide Show Repeat: Select between on and off. Sort Pressing [OK] on Sort button, it will pop up the Sort drop-down list. Name(A-Z): The ascending order, omitting the $ character, the number is ahead, then the capital letter, at last the lowercase.

  • Page 26: Rec

    6. REC 6.1. Record Manager 1. Press PR+, PR- keys to select up or down, 2. Press green color key to lock the channel you selected, the lock symbol will be marked behind the channel. Before you lock the channel you must input the correct password, the default password is 0000.

  • Page 27: Epg

    7.2 EPG Press EPG key to enter into the EPG window. 1. Press PR+, PR-, keys to select up or down, left or right. 2. Press red colour key to pop up the Time Bar window. Press PR+, PR- keys to select up or down, while press keys to select left or right in the time bar.

  • Page 28: Tv/Radio

    7.5 TV/RADIO In normal mode, press TV/RADIO key to switch between TV mode and Radio mode. 7.6 Up/Down (Channel Change) Press PR+, PR- keys to change the channel up or down. If in the all satellites group, you can select channel in all searched channels. If in the specific satellite, only can select channel in the satellite group.

  • Page 29: Recall

    7.12 Recall Press key to switch the current channel to the previous channel. 7.13 FAV 1. Press FAV key to pop up the favourite group window. 2. Press keys to select the favorite group. Press PR+, PR- keys to select the channel up or down..
  • Page 30 Problem Possible causes What to do The display on the front Check that the main cable is plugged into Main cable is not connected. panel does not light up. the power socket. No sound or picture, but the receiver is in standby mode. Press the standby button.

This manual is also suitable for:

S812
