CADET 6' X 36"
WHIRLPOOL
MODEL NUMBER
2773.018
DISCHARGE
TEE
PUMP
DISCHARGE
COUPLING
1" RIGID
PVC TUBING
PUMP
SUCTION
COUPLING
1-1/2" RIGID
PVC TUBING
Pump Suction Coupling
O-Ring
Pump Discharge Coupling
Air Control Valve
Air Control Valve Housing and Nut
Jet Nozzle Assembly
Escutcheon Assembly
Jet Body Assembly
Suction Guard
Suction Fitting
Suction Fitting Elbow
Discharge Tee
Pump w/Air Switch (1 HP)
Air Switch (See Section J)
Air Actuator Cap and Body
Air Actuator Tubing
NOTE: Schedule 40 Rigid PVC Piping available through local plumbing supply outlets.
See Section "J" for Additional Parts and Accessories.
Removal/installation requires tool part no. 047530-0070A.
Removal/installation requires tool part no. 047605-0070A.
H-102
O-RING
O-RING
SUCTION
GUARD
SUCTION FITTING
ELBOW
DESCRIPTION
AIR ACTUATOR
CAP AND BODY
AIR
ACTUATOR
TUBING
AIR SWITCH
(SEE SECTION J)
P/O MOTOR
PUMP
SYSTEM I
AIR CONTROL
VALVE
AIR CONTROL
VALVE
HOUSING
AND NUT
SUCTION
FITTING
PART NUMBER
047186-0070A
047187-0070A
047186-0070A
751677-XXX0A
068917-XXX0A
047587-XXX0A
047588-0070A
047627-00700A
047463-XXX0A
047550-XXX0A
751186-0070A
047438-0070A
752444-0070A
752388-0070A
752439-XXX0A
047602-0070A
