INTRODUCTION

The BOSSCOM Powerlink Switch Airplay is a converter and an automatic source
switch with 8 pin DIN, SPDIF/TOSLINK and DIN-8/RCA inputs and is 100% B&O
compatible. This device provides you a solution for many problems in audio and video
installations, such as feed-in of any audio/video sources to B&O
®
connection of B&O
IMPORTANT:
The following functions of the BOSSCOM Powerlink Switch Airplay are universally
valid and will no longer be described separately when shown in the application
examples on the following pages:
1. Which sources can be connected?
Any stereo audio sources can be connected to INPUT 1 (DIN-8/RCA), INPUT 2
(DIN-8) and SPDIF/TOSLINK INPUT which has a volume controlled output (e.g.
®
Apple Airport Express, SONOS
DVB receivers, etc.). The BOSSCOM Powerlink Switch Airplay is NOT suitable for
converting 5.1 data stream via SPDIF.
2. 100% standard compliant B&O
®
B&O sources connected to Powerlink signal will simply be looped through. All
other audio signals - whether digital or analog - will be converted into 100%
standard compliant B&O
®
for the B&O speakers.
3. Automatic source management with priority circuit.
The BOSSCOM Powerlink Switch Airplay is not only a Powerlink converter but
also automatic source management. The connected sources have different
priorities which can be chosen by using the DIP switches on the bottom side of
the Powerlink Switch Airplay. Please follow the instructions on the page 9
speakers to audio/video devices of other manufacturers etc.
®
ZP90, Loewe, Samsung, Panasonic televisions,
®
®
Powerlink signal including the circuit voltage required
Powerlink signal.
®
®
systems,
