USER'S MANUAL
1.
System power on by PS/2 Mouse: First, enable this function
in CMOS Setup, then you can power on the system by
double clicking the right or left button of your PS/2 Mouse.
2.
System power on by Keyboard: If your ATX power supply
supports larger than 300 mA 5V Stand-By current, you can
power on your system by entering password from the
Keyboard after setting the "Keyboard power on" jumper
(JP1) and password in CMOS Setup.
3.
Support Modem Ring-On. (Include internal Modem and
external modem on COM A and COM B)
4.
Wake-up on LAN supports(on J11): Your ATX power supply
must support larger than 720 mA 5V Stand-By current.
5.
Support 3 steps ACPI LED.
6.
Support LDCM
For Intel Pentium
6BA
II / III / Celeron Processor MAINBOARD
REV. 3.0 First Edition
R-30-01-090526
Advertisement
Related Manuals for Creative Pentium II Processor 6BA
Summary of Contents for Creative Pentium II Processor 6BA
- Page 1 USER'S MANUAL System power on by PS/2 Mouse: First, enable this function in CMOS Setup, then you can power on the system by double clicking the right or left button of your PS/2 Mouse. System power on by Keyboard: If your ATX power supply supports larger than 300 mA 5V Stand-By current, you can power on your system by entering password from the Keyboard after setting the “Keyboard power on”...
- Page 3 The author assumes no responsibility for any errors or omissions which may appear in this document nor does it make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners. Sound Blaster is a registered trademark of Creative Technology Ltd in the United States and certain other countries.
-
Page 4: Cpu Speed Setup
I. Quick Installation Guide : CPU SPEED SETUP The system bus speed can be selectable between 66.6MHz and 100MHz. The user can select the system bus speed (JP8) and change the DIP SWITCH selection to set up the CPU speed for 233 - 633MHz processor. The CPU speed must match with the frequency RATIO. - Page 5 MJP8 (Select the system speed between 66.6MHz and 100MHz) 1-2 Close Set system speed to 66MHz always run at 66MHz FSB (Front Side Bus). 2-3 Close Set system speed to Auto speed detect automatically (66/ 100MHz FSB). 1-2-3 Open Set system speed to 100MHz always run at 100MHz FSB (Front Side Bus).
- Page 6 2. Pentium II / Celeron 266 / 66 MHz FSB 3. Pentium II / Celeron 300MHz / Celeron 300A MHz/66MHz FSB 4. Pentium II / Celeron 333 / 66 MHz FSB 5. Pentium II / Celeron 366 / 66 MHz FSB 6.
- Page 7 7. Pentium II / Celeron 433 MHz / 66MHz FSB 8. Pentium II 350 / 100 MHz FSB 9. Pentium II 400 / 100 MHz FSB 10. Pentium III 450 / 100 MHz FSB 11. Pentium III 500 / 100 MHz FSB...
- Page 8 12. Pentium III 550MHz / 100MHz FSB 13. Pentium III 600MHz / 100MHz FSB 14. Pentium III 650MHz / 100MHz FSB Quick Installation Guide...
- Page 9 II. Jumper setting : IR : Infrared Connector (Optional) BIOS Function IR Data Output IR Data Input POWER (+) PWR : Power LED / Key-Lock Connector BIOS Function LED anode (+) LED cathode ( ) LED cathode ( ) Key Lock PIIX4 82443LX 82443BX...
- Page 10 SPK : Speaker Connector BIOS Function Data TD : Turbo LED Connector BIOS Function LED anode (+) LED cathode ( ) Quick Installation Guide PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
-
Page 11: Normal Operation
TB : Turbo Switch Connector BIOS Function Reserved RST : Reset Switch BIOS Open : Normal operation Close : Reset system PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX... - Page 12 GD : Green Function LED BIOS Function LED anode (+) LED cathode ( ) GN : Green Function Switch BIOS Open : Normal operation Close: Entering Green Mode Quick Installation Guide PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 13 HD : IDE Hard Disk Active LED BIOS Function LED anode (+) LED cathode ( ) Soft PWR : Soft Power Connector BIOS Function CTRL-Signal PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 14 POWER : P8&P9 Power Connector BIOS Function Power Good 2,10,11,12 +12V - 12V 5,6,7,8 - 5V ATX POWER : ATX POWER Connector BIOS 3,5,7,13, 15-17 1,2,11 4,6,19,20 Quick Installation Guide PIIX4 82443LX 82443BX Function PIIX4 3.3V VCC (+5V) +12V Power Good 5V SB (Stand by +5V) PS-ON (Soft ON/OFF) 8 2 4 4 3 L X...
- Page 15 CPU FAN : CPU Cooling Fan Power Connector BIOS SYSTEM FAN : SYSTEM Fan Power Connector BIOS PIIX4 Function +12V Signal 8 2 4 4 3 L X 82443BX PIIX4 Function +12V Signal 82443LX 82443BX...
- Page 16 POWER FAN : POWER Fan Connector BIOS IDE1: Primary IDE port BIOS RED LINE Quick Installation Guide PIIX4 Function +12V Signal 8 2 4 4 3 L X 82443BX PIIX4 82443LX 82443BX...
- Page 17 IDE2: Secondary IDE port BIOS RED LINE FLOPPY : FLOPPY PORT BIOS RED LINE PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 18 LPT : LPT PORT BIOS RED LINE COMB : COM B PORT BIOS RED LINE Quick Installation Guide PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 19 COMA : COM A PORT BIOS RED LINE JP1 : Keyboard Power On (for ATX Power Supply only) BIOS 1-2 Close : Enable Keyboard Power On 2-3 Close : Disable Keyboard Power On PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 20 K.B : Keyboard Connector BIOS Function Key Clock Key Data VCC (+5V) J4 : PS/2 MOUSE BIOS RED LINE Quick Installation Guide PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 21 USB : USB Port BIOS Function USB D0 USB D0+ USB D1 USB D1+ J11 : Wake on Lan (for ATX Power Supply only) BIOS Function +5V SB Signal PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
-
Page 22: Jp9 : Clear Cmos
JP9 : CLEAR CMOS BIOS 1-2 Short :Clear CMOS 2-3 Short : Normal JP10 : CASE OPEN (Optional) BIOS Function Signal Quick Installation Guide PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX... - Page 23 J19 : Internal Modem Card Ring PWR On BIOS Function Signal SB-LINK : For PCI Audio / Sound Card use only (Creative PCI Sound Card Support) BIOS Function Signal Signal Signal PIIX4 82443LX 82443BX PIIX4 82443LX 82443BX...
- Page 24 JP11 & JP12 (This function is support in PCB version 3.0 and above) BIOS BAT1 : For Battery BIOS – M Danger of explosion if battery is incorrectly replaced. M Replace only with the same or equivalent type recommended by the manufacturer. M Dispose of used batteries according to the manufacturer’...
- Page 25 III. Top Performance Test Setting: The following performance data list is the testing results of some popular benchmark testing programs. Users have to modify the value for each item in chipset features as follow for top performance setting.
- Page 26 These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium II processor DRAM (32x4)MB SDRAM (LGS GM72V661641CT7J) CACHE SIZE 512 KB included in CPU DISPLAY...
