Acesonic UHF-1208X User Manual

Dual diversity 100 channels uhf wireless microphone system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
The Leader in Professional Equipment
UHF-1208X
DUAL DIVERSITY 100 CHANNELS
UHF WIRELESS MICROPHONE SYSTEM
USER'S MANUAL
www.acesonic.com
NOTE:
To ensure this component will work safely and to
its fullest potential, please read this user's manual
carefully before operation and keep for future
reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UHF-1208X and is the answer not in the manual?

Questions and answers

Related Manuals for Acesonic UHF-1208X

Summary of Contents for Acesonic UHF-1208X

  • Page 1 The Leader in Professional Equipment UHF-1208X DUAL DIVERSITY 100 CHANNELS UHF WIRELESS MICROPHONE SYSTEM USER’S MANUAL NOTE: To ensure this component will work safely and to its fullest potential, please read this user’s manual carefully before operation and keep for future reference.

  • Page 2: Warnings And Caution

    Warnings, Cautions and Others Mises en garde, precautions et indications diverses For Canada/Pour le Canada CAUTION CAUTION: TO PREVENT ELECTRIC SHOCK, RISK OF ELECTRIC SHOCK DO NOT OPEN MATCH WIDE BLADE OF PLUG TO WIDE SLOT,AND FULLY INSERT. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK).

  • Page 3: Safety Instructions

    Important Safety instructions 18. Overloading Do not overload wall outlets, extension cords, or integral 1. Read These Instructions. convenience receptacles as this can result in a risk of fire or electric shock. 2. Keep These Instructions. 3. Heed All Warnings. 19.

  • Page 4: Table Of Contents

    Acesonic UHF-1208X Thank you for purchasing Acesonic's UHF-1208X. Acesonic takes pride in providing our custmers with only the most advanced and highest quality karaoke products on the market. Please read trough this USER’S MANUAL before operation to ensure proper usage, and keep for future Table of Contents Warnings and Caution..................2...

  • Page 5: Receiver/Display Panel Descriptions

    Receiver Descriptions 1) Power switch -Turns the UHF-1208X on and off. 2) RF & AF indicator- RF indicator shows radio frequence signal level which receiver is getting. AF indicator shows the audio frequence signal level from the microphone. If receiver catches microphone’s signal, the RF & AF indicator will show the signal level...

  • Page 6: Microphone Descriptions/Operation/Channel Switching

    Microphone Descriptions Green=Working Yellow=Mute No light= Indicate power off Light Operation button 1)Cartridge module- This is where you would sing into. 2)Microphone body- The main frame of the microphone. 3)Operating indicator and 4)Switch button- Hold the switch button for 1 second to turn on the power. Light will turns green means microphone is now in working condition.

  • Page 7: Installation & Ir Syncing(Channel Switching)

    Mic. Input Mic. Input Power Outlet AC Power adapter cable 1) Connect the AC POWER ADAPTER to the UHF-1208X receiver’s AC INPUT 110V, then plug the other end of AC POWER ADAPTER into the WALL OUTLET. ¼" ¼" 2)Connect one end of a...

  • Page 8: Troubleshooting

    Troubleshooting If you are having problems operating the UHF-1208X, or suspect something is wrong with the unit, please check the troubleshoot list below to see if the issue is a result of incorrect operation rather than equipment malfunction. If you are still unable to resolve the problem, please contact our Acesonic service center at 626-820-0670.

  • Page 9: Features & Specifications

    Features and Specifications Features: Professional Heavy duty rack mountable receiver, UHF diversity wireless system Almost zero noise output when on standby, high signal/noise ratio, super low distortion. 1000 switchable channels, with auto channel selection function. Dual channel information LCD display and individual microphone volume control. Perfect operative status signals, fluorescence display, with digital microphone.

  • Page 10: Manufacturer Information

    Manufacturer Information Contact Info: 1 Year Manufacturer Warranty Lifetime Tech. Support (626)820-0670 Design in U.S.A (626)820-0670 Tech. Support: Address: 161 S. 8th Avenue City of Industry, CA 91746-3208, USA Website: www.acekaraoke.com Note:...
