Mud Buddy
HD Models
Owner's Manual
Update June 28, 2007
Thank you for purchasing the most advanced
mud motor in the world.
Assembly - Read the quick-start guide and the instructions
inside before installing and operating your motor. Check the crate
and engine for damage. Call Mud Buddy and the shipping
company immediately if you find any damage or missing items.
Notice: Your engine is shipped without oil. Fill before starting.
Check the oil with the engine in a level position. Some oil may be
left in the engine when shipped. Check while filling. Do not overfill.
Use a good grade of SAE 10W-30 oil. You can also use a synthetic oil.
For Engines
Vanguard 29, 31, and 35 takes up to 80 oz.
14 -29 horse take up to 2 qt.
Mini HD Lite Notice
Your engine is equipped with a mercury safety switch which prevents the engine from being started
unless the propeller is raised out of the water.
Kawasaki Notice
Kawasaki 29 EFI Notice: Fuel injection system. When new or when in storage for an extended
period, bleed the fuel line of air. Remove the fuel line above the fuel filter, turn the key on and
pump out 1/4 cup of fuel into a suitable container. Reassemble. The fuel filter may have a little air
inside, this is okay. If you run out of fuel, the above procedure must be repeated.
Advertisement
Table of Contents
Related Manuals for Mud Buddy HD series
Summary of Contents for Mud Buddy HD series
- Page 1 Assembly - Read the quick-start guide and the instructions inside before installing and operating your motor. Check the crate and engine for damage. Call Mud Buddy and the shipping company immediately if you find any damage or missing items. Notice: Your engine is shipped without oil. Fill before starting.
- Page 2 Propellers Modified Engine Warranty: This applies to the Engine Warranty Mud Buddy Level 2, 3, 4, 5 & 6 engines. HD 4000, Vanguard 14, 18, 23,29, 31 & 35 HD 4500 and HD 6000 engines. Mud Buddy Kohler 25 & 27 provided a six month warranty on the engine and Kawasaki 27 &...
- Page 3 Start off slowly and soon you will learn new ways of using the off to the side of the boat. This is true of any outboard motor. Mud Buddy to propel your boat in and out of places you never The boat can lurch forward, or spin and expel the operator and dreamed possible.
- Page 4 Every 100 hours - Grease the drive assembly and swivel points. engine failure. Do not add a fuel tank quick disconnect, which The drive tube is filled with grease from the factory. In addition can restrict fuel and cause poor top end performance. You may to the above lubrication schedule, every two years or 200 hours, add a primer bulb, but turn the ignition switch on before pumping remove the propeller and lower bearing cap.
-
Page 5: Belt Tension/Replacement
Now tension the belt lightly which will A belt tension kit can be purchased from Mud Buddy. It contains cause the propeller outdrive to rise to the top of the bolt holes. - Page 6 Extended Warranty Plan We provide a one year warranty on the frame and outdrive. An additional year can be purchased from Mud Buddy within 30 days of purchase. HD4000, HD4500 and HD6000 - $385 Sport, Lite, and Hunter - $295 HD Mini Lite and Longtails - $245 Call Mud Buddy, 801.352.8011 for more information.
