LevelOne WBR-6601 User Manual

150mbps n wireless adsl2 + modem router
Hide thumbs Also See for WBR-6601:
Table of Contents

Advertisement

Quick Links

LevelOne
WBR-6601
150Mbps N Wireless ADSL2 + Modem Router

User Manual

V1.0.0

Advertisement

Table of Contents
loading

Related Manuals for LevelOne WBR-6601

Summary of Contents for LevelOne WBR-6601

  • Page 1: User Manual

    LevelOne WBR-6601 150Mbps N Wireless ADSL2 + Modem Router User Manual V1.0.0...

  • Page 3: Table Of Contents

    Table of Contents CHAPTER 1 INTRODUCTION ....................1 Wireless ADSL Router Features ..................1 Package Contents ......................4 Physical Details ........................5 CHAPTER 2 INSTALLATION ....................7 Requirements ........................7 Procedure ........................... 7 CHAPTER 3 SETUP ......................... 9 Overview ..........................9 Configuration Program ....................
  • Page 4 Routing ..........................86 Upgrade Firmware ......................90 CHAPTER 8 MODEM MODE ....................91 Overview .......................... 91 Management Connections ....................91 Home Screen ........................92 Mode Screen ........................93 Operation ......................... 93 Status Screen ........................94 APPENDIX A TROUBLESHOOTING ................96 Overview ..........................

  • Page 5: Chapter 1 Introduction

    Congratulations on the purchase of your new Wireless ADSL Router. The Wireless ADSL Router is a multi-function device providing the following services:  WBR-6601 Wireless ADSL2 + Modem Router  Shared Broadband Internet Access for all LAN users.

  • Page 6: Advanced Internet Functions

     Auto-detection of Internet Connection Method. In most situations, the Wireless ADSL Router can test your ADSL and Internet connection to determine the connection me- thod used by your ISP.  Fixed or Dynamic IP Address. On the Internet (ADSL port) connection, the Wireless ADSL Router supports both Dynamic IP Address (IP Address is allocated on connection) and Fixed IP Address.

  • Page 7: Lan Features

    Introduction  Wireless MAC Access Control. The Wireless Access Control feature can check the MAC address (hardware address) of Wireless stations to ensure that only trusted Wireless Stations can access your LAN.  WPS Support. WPS (Wi-Fi Protected Setup) can simplify the process of connecting any device to the wireless network by using the push button configuration (PBC) on the Wire- less Access Point, or entering PIN code if there's no button.

  • Page 8: Package Contents

    Package Contents The following items should be included. If any of these items are damaged or missing, please contact your dealer immediately.  The Wireless ADSL Router Unit  1 Ethernet cable  Power Adapter  Quick Installation Guide  CD-ROM containing the on-line manual.

  • Page 9: Physical Details

    Introduction Physical Details Front-mounted LEDs Figure 2: Front Panel Power LED On - Power on. (Orange) Off - No power. LAN (Blue) On - The LAN port is active. Off - No active connection on the LAN (Ethernet) port. Flashing - Data is being transmitted or received via the corresponding LAN port.

  • Page 10: Rear Panel

    Rear Panel Figure 3: Rear Panel Connect this port to your ADSL line. ADSL port 10/100BaseT Use standard LAN cables (RJ45 connectors) to connect your PCs to LAN connections these ports. Note: Any LAN port on the Wireless ADSL Router will automatically function as an "Uplink"...

  • Page 11: Chapter 2 Installation

    Chapter 2 Installation This Chapter covers the physical installation of the Wireless ADSL Router. Requirements  Network cables. Use standard 10/100BaseT network (UTP) cables with RJ45 connectors.  TCP/IP protocol must be installed on all PCs.  For Internet Access, an Internet Access account with an ISP, and a DSL connection. ...

  • Page 12: Check The Leds

    2. Connect LAN Cables Use standard LAN cables to connect PCs to the Switching Hub ports on the Wireless ADSL Router. Both 10BaseT and 100BaseT connections can be used simultaneously. If required, connect any port to a normal port on another Hub, using a standard LAN cable. 3.

  • Page 13: Chapter 3 Setup

    Chapter 3 Setup This Chapter provides Setup details of the Wireless ADSL Router. Overview This chapter describes the setup procedure for:  Internet Access  LAN configuration  Wireless setup  Assigning a Password to protect the configuration data. PCs on your local LAN may also require configuration. For details, see Chapter 4 - PC Confi- guration.
  • Page 14 Use any of the following Administration Configuration Chapter 7 settings or features: Advanced Administration  PC Database  Config File  Logging  E-mail  Diagnostics  Remote Admin  Routing  Upgrade Firmware...

  • Page 15: Configuration Program

    Setup Configuration Program The Wireless ADSL Router contains an HTTP server. This enables you to connect to it, and configure it, using your Web Browser. Your Browser must support JavaScript. The configuration program has been tested on the following browsers: ...

  • Page 16: Setup Wizard

    If you can't connect If the Wireless ADSL Router does not respond, check the following:  The Wireless ADSL Router is properly installed, LAN connection is OK, and it is powered ON. You can test the connection by using the "Ping" command: ...
  • Page 17 Setup If Manual Selection is selected, you will see the VC 1 screen shown below. Enter the VPI and VCI values provided by your ISP, then click "Next". Figure 6: Setup Wizard - VC 1 Figure 7: Setup Wizard - Internet Access On the Internet Access Screen, shown above, select the correct connection type, as used by your ISP.
  • Page 18 Connection Type Details ISP Data required Dynamic Your IP Address is allocated Often, none. IP Address automatically, when you connect Some ISP's may require you to to you ISP. use a particular Hostname or Domain name, or MAC (physical) address. Static (Fixed) Your ISP allocates a permanent IP Address allocated to you, and...

  • Page 19: Home Screen

    Setup Home Screen After finishing the Setup Wizard, you will see the Home screen. When you connect in future, you will see this screen when you connect. An example screen is shown below. Figure 8: Home Screen Main Menu The main menu, on the left, contains links to the most-commonly used screen. To see the links to the other available screens, click "Advanced"...

  • Page 20: Lan Screen

    LAN Screen Use the LAN link on the main menu to reach the LAN screen. An example screen is shown below. Figure 9: LAN Screen Data - LAN Screen TCP/IP IP Address IP address for the Wireless ADSL Router, as seen from the local LAN. Use the default value unless the address is already in use or your LAN is using a different IP address range.

  • Page 21: What Dhcp Does

    Setup DHCP What DHCP Does A DHCP (Dynamic Host Configuration Protocol) Server allocates a valid IP address to a DHCP Client (PC or device) upon request.  The client request is made when the client device starts up (boots).  The DHCP Server provides the Gateway and DNS addresses to the client, as well as allocating an IP Address.

  • Page 22: Wireless Screen

    Wireless Screen The Wireless ADSL Router's settings must match the other Wireless stations. Note that the Wireless ADSL Router will automatically accept both 802.11b and 802.11g connections, and no configuration is required for this feature. To change the Wireless ADSL Router's default settings for the Wireless Access Point feature, use the Wireless link on the main menu to reach the Wireless screen.
  • Page 23 Setup SSID 1/2 This is also called the "Network Name".  If using an ESS (Extended Service Set, with multiple access points) this ID is called an ESSID (Extended Service Set Identifi- er).  To communicate, all Wireless stations should use the same SSID/ESSID.
  • Page 24 MAC Address Filter Use this feature to determine which Wireless stations can use the Allow access by … Access Point. The options are:  All Wireless Stations - All wireless stations can use the access point, provided they have the correct SSID and security settings. ...

  • Page 25: Wireless Security

    Setup Wireless Security This screen is accessed by clicking the "Configure SSID" button on the Wireless screen. There are 6 options for Wireless security:  Disabled - no data encryption is used.  WEP - data is encrypted using the WEP standard. ...
  • Page 26  64 Bit - data is encrypted, using the default key, before being transmitted. You must enter at least the default key. For 64 Bit En- cryption, the key size is 10 chars in HEX (0~9 and A~F).  128 Bit - data is encrypted, using the default key, before being transmitted.
  • Page 27 Setup Security Settings - WPA2-PSK This is a further development of WPA-PSK, and offers even greater security, using the AES (Advanced Encryption Standard) method of encryption. Figure 13: WPA2-PSK Wireless Security Screen Data - WPA2-PSK Screen WPA2-PSK Enter the key value. Data is encrypted using a 256Bit key derived from this key.
  • Page 28 Security Settings - Mixed WPA-PSK/WPA2-PSK This method, sometimes called "Mixed Mode", allows clients to use EITHER WPA-PSK OR WPA2-PSK. Figure 14: Mixed WPA-PSK WPA2-PSK Wireless Security Screen Data - WPA2-PSK Screen WPA2-PSK Enter the key value. Data is encrypted using a 256Bit key derived from this key.
  • Page 29 Setup Security Settings - 802.1x This uses the 802.1x standard for client authentication, and WEP for data encryption. If this option is selected:  This Access Point must have a "client login" on the Radius Server.  Each user must have a "user login" on the Radius Server. Normally, a Certificate is used to authenticate each user.

  • Page 30: Trusted Wireless Stations

    Trusted Wireless Stations This feature can be used to prevent unknown Wireless stations from using the Access Point. This list has no effect unless the setting Allow access by trusted stations only is enabled. To change the list of trusted wireless stations, use the Modify List button on the Access Control screen.
  • Page 31 Setup Edit Use this to change an existing entry in the "Trusted Stations" list: Select the Station in the Trusted Station list. Click the Edit button. The address will be copied to the "Ad- dress" field, and the Add button will change to Update. Edit the address (MAC or physical address) as required.

  • Page 32: Password Screen

    Password Screen The password screen allows you to assign a password to the Wireless ADSL Router. Figure 17: Password Screen Enter the existing password in this field. Old Password New password Enter the new password here. Verify password Re-enter the new password here. You will be prompted for the password when you connect, as shown below.

  • Page 33: Mode Screen

    Setup Mode Screen Use this screen to change the mode between Router mode and Modem (Bridge) mode. Figure 19: Mode Screen Select the desired option, and click "Save". Router Both the ADSL Modem and the Router features are operational. In this mode, this device can provide shared Internet Access to all your LAN users.

  • Page 34: Chapter 4 Pc Configuration

    Chapter 4 PC Configuration This Chapter details the PC Configuration required on the local ("Internal") LAN. Overview For each PC, the following may need to be configured:  TCP/IP network settings  Internet Access configuration  Wireless configuration Windows Clients This section describes how to configure Windows clients for Internet access via the Wireless ADSL Router.

  • Page 35: Using Dhcp

    PC Configuration Checking TCP/IP Settings - Windows 9x/ME: Select Control Panel - Network. You should see a screen like the following: Figure 20: Network Configuration Select the TCP/IP protocol for your network card. Click on the Properties button. You should then see a screen like the following. Figure 21: IP Address (Win 95) Ensure your TCP/IP settings are correct, as follows: Using DHCP...
  • Page 36  On the Gateway tab, enter the Wireless ADSL Router's IP address in the New Gateway field and click Add, as shown below. Your LAN administrator can advise you of the IP Address they assigned to the Wireless ADSL Router. Figure 22: Gateway Tab (Win 95/98) ...
  • Page 37 PC Configuration Checking TCP/IP Settings - Windows NT4.0 Select Control Panel - Network, and, on the Protocols tab, select the TCP/IP protocol, as shown below. Figure 24: Windows NT4.0 - TCP/IP Click the Properties button to see a screen like the one below.

  • Page 38: Specify An Ip Address

    Figure 25: Windows NT4.0 - IP Address Select the network card for your LAN. Select the appropriate radio button - Obtain an IP address from a DHCP Server or Specify an IP Address, as explained below. Obtain an IP address from a DHCP Server This is the default Windows setting.
  • Page 39 PC Configuration Figure 26 - Windows NT4.0 - Add Gateway The DNS should be set to the address provided by your ISP, as follows:  Click the DNS tab.  On the DNS screen, shown below, click the Add button (under DNS Service Search Order), and enter the DNS provided by your ISP.

  • Page 40: Checking Tcp/Ip Settings - Windows

    Checking TCP/IP Settings - Windows 2000: Select Control Panel - Network and Dial-up Connection. Right - click the Local Area Connection icon and select Properties. You should see a screen like the following: Figure 28: Network Configuration (Win 2000) Select the TCP/IP protocol for your network card. Click on the Properties button.
  • Page 41 PC Configuration Ensure your TCP/IP settings are correct, as described below. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the Wireless ADSL Router will act as a DHCP Server.

  • Page 42: Checking Tcp/Ip Settings - Windows Xp

    Checking TCP/IP Settings - Windows XP Select Control Panel - Network Connection. Right click the Local Area Connection and choose Properties. You should see a screen like the following: Figure 30: Network Configuration (Windows XP) Select the TCP/IP protocol for your network card. Click on the Properties button.
  • Page 43 PC Configuration Figure 31: TCP/IP Properties (Windows XP) Ensure your TCP/IP settings are correct. Using DHCP To use DHCP, select the radio button Obtain an IP Address automatically. This is the default Windows setting. Using this is recommended. By default, the Wireless ADSL Router will act as a DHCP Server.

  • Page 44: For Windows Xp

    Internet Access To configure your PCs to use the Wireless ADSL Router for Internet access:  Ensure that the DSL modem, Cable modem, or other permanent connection is functional.  Use the following procedure to configure your Browser to access the Internet via the LAN, rather than by a Dial-up connection.

  • Page 45: Macintosh Clients

    PC Configuration Macintosh Clients From your Macintosh, you can access the Internet via the Wireless ADSL Router. The proce- dure is as follows. Open the TCP/IP Control Panel. Select Ethernet from the Connect via pop-up menu. Select Using DHCP Server from the Configure pop-up menu. The DHCP Client ID field can be left blank.

  • Page 46: Wireless Station Configuration

    Wireless Station Configuration This section applies to all Wireless stations wishing to use the Wireless ADSL Router's Access Point, regardless of the operating system which is used on the client. To use the Wireless Access Point in the Wireless ADSL Router, each Wireless Station must have compatible settings, as follows: Mode The mode must be set to Infrastructure (rather than Ad-hoc)
  • Page 47 PC Configuration Figure 33 Wireless Networks (Windows XP) If the "Broadcast SSID" setting on the Wireless ADSL Router has been disabled, its SSID will NOT be listed. See the following section "If the SSID is not listed" for details of dealing with this situation. The next step depends on whether or not Wireless security has been enabled on the Wire- less ADSL Router.
  • Page 48 To connect:  Check the checkbox Allow me to connect to the selected wireless network, even though it is not secure.  The Connect button will then be available. Click the Connect button, and wait a few seconds for the connection to be established. If using WEP Data Encryption If WEP data encryption has been enabled on the Wireless ADSL Router, Windows will detect this, and show a screen like the following.
  • Page 49 PC Configuration Figure 36: Advanced - Wireless Networks Select the SSID for the Wireless ADSL Router, and click Configure, to see a screen like the following: Figure 37: Wireless Network Properties - WEP Configure this screen as follows:  Set Network Authentication to match the Wireless ADSL Router. (If the setting on the Wireless ADSL Router is "Auto", then either Open or Shared can be used.) ...
  • Page 50  For the Network key and Confirm network key, enter the default key value used on the Wireless ADSL Router. (Windows will determine if 64bit or 128bit encryption is used.)  The Key index must match the default key index on the Wireless ADSL Router. The default value is 1.
  • Page 51 PC Configuration If using WPA-PSK Data Encryption If WPA-PSK data encryption has been enabled on the Wireless ADSL Router, it does not matter which network is selected on the screen below. Just click the Advanced button. Figure 39: Wireless Networks (Windows XP) You will then see a screen like the example below.
  • Page 52 Figure 41: Wireless Network Properties- WPA-PSK Configure this screen as follows:  Set Network Authentication to WPA-PSK.  For Data Encryption, select TKIP.  For the Network key and Confirm network key, enter the network key (PSK) used on the Wireless ADSL Router.
  • Page 53 PC Configuration Figure 42: Preferred Networks Click OK to establish a connection to the Wireless ADSL Router. If the SSID is not listed If the "Broadcast SSID" setting on the Wireless ADSL Router has been disabled, its SSID will NOT be listed on the screen below. Figure 43: Wireless Networks (Windows XP) In this situation, you need to obtain the SSID from your network administrator, then follow this procedure:...
  • Page 54 Click the Advanced button to see a screen like the example below. Figure 44: Unlisted Wireless Network Click the Add button. You will see a screen like the example below. Figure 45: Add Wireless Network Configure this screen as follows: ...
  • Page 55 PC Configuration  If using data encryption (WEP or WPA-PSK), enter the key used on the Wireless ADSL Router. See the preceding sections for details of WEP and WPA-PSK.  Uncheck the options The key is provided for me automatically and This is a computer- to-computer (ad hoc) network.

  • Page 56: Chapter 5 Operation And Status

    Chapter 5 Operation and Status This Chapter details the operation of the Wireless ADSL Router and the status screens. For Details of operation in Bridge (Modem) mode, see Chapter 8 - Modem Mode. Operation - Router Mode Once both the Wireless ADSL Router and the PCs are configured, operation is automatic. However, there are some situations where additional Internet configuration may be required.
  • Page 57 Operation and Status  Active - Connection exists  Idle - No current connection, but no error has been detected. This condition normally arises when an idle connection is au- tomatically terminated.  Failed - The connection was terminated abnormally. This could be caused by Modem failure, or the loss of the connec- tion to the ISP's server.
  • Page 58 description of the current connection. Attached Devices This will open a sub-window, showing all LAN and Wireless devices currently on the network. Refresh Screen Update the data displayed on screen.

  • Page 59: Connection Status - Pppoe & Pppoa

    Operation and Status Connection Status - PPPoE & PPPoA If using PPPoE (PPP over Ethernet) or PPPoA (PPP over ATM), a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 48: PPPoE Status Screen Data - PPPoE/PPPoA Screen Connection Time This indicates how long the current connection has been estab-...

  • Page 60: Connection Details - Dynamic Ip Address

    Connection Details - Dynamic IP Address If your access method is "Direct" (no login), with a Dynamic IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 49: Connection Details - Fixed/Dynamic IP Address Data - Dynamic IP address Internet The current IP Address of this device, as seen by Internet users.

  • Page 61: Connection Details - Fixed Ip Address

    Operation and Status Connection Details - Fixed IP Address If your access method is "Direct" (no login), with a fixed IP address, a screen like the following example will be displayed when the "Connection Details" button is clicked. Figure 50: Connection Details - Fixed/Dynamic IP Address Data - Fixed IP address Screen Internet IP Address...

  • Page 62: Chapter 6 Advanced Features

    Chapter 6 Advanced Features This Chapter explains when and how to use the Wireless ADSL Router's "Ad- vanced" Features. Overview The following advanced features are provided:  Internet:   URL filter  Access Control  Dynamic DNS  Options ...

  • Page 63: Url Filter

    Advanced Features The "DMZ PC" is effectively outside the Firewall, mak- ing it more vulnerable to attacks. For this reason, you should only enable the DMZ feature when required. URL Filter If you want to limit access to certain sites on the Internet, you can use this feature. The URL filter will check each Web site access.
  • Page 64 Add Filter String To add to the current list, type the word or domain name you want to block into the field provided, then click the Add button. Filter strings should be as specific as possible. Otherwise, you may block access to many more sites than intended. Trusted PC Allow this PC..

  • Page 65: Access Control

    Advanced Features Access Control This feature is accessed by the Access Control link on the Advanced menu. Overview The Access Control feature allows administrators to restrict the level of Internet Access availa- ble to PCs on your LAN. With the default settings, everyone has unrestricted Internet access. Restrictions are imposed by blocking "Services", or types of connections.
  • Page 66 Blocked Services This lists all defined Services. Select the Services you wish to block. To select multiple services, hold the CTRL key while select- ing. (On the Macintosh, hold the SHIFT key rather than CTRL.) Schedule If Internet access is being blocked, you can choose to apply the blocking only during scheduled times.

  • Page 67: Dynamic Dns (Domain Name Server)

    Advanced Features Dynamic DNS (Domain Name Server) This free service is very useful when combined with the Virtual Server feature. It allows Inter- net users to connect to your Virtual Servers using a URL, rather than an IP Address. This also solves the problem of having a dynamic IP address. With a dynamic IP address, your IP address may change whenever you connect, which makes it difficult to connect to you.
  • Page 68 DDNS Data Host Name Enter the domain name allocated to you by the DDNS Service. If you have more than one name, enter the name you wish to use. Enter your Username for the DDNS Service. (TZO.com uses your E- User Name mail address.) Password...

  • Page 69: Options

    Advanced Features Options This screen allows advanced users to enter or change a number of settings. For normal opera- tion, there is no need to use this screen or change any settings. An example Options screen is shown below. Figure 56: Options Screen Data - Options Screen Internet ...

  • Page 70: Schedule

    Schedule This Schedule can be used for the Firewall Rules and the URL filter. Figure 57: Schedule Screen Data - Schedule Screen Schedule Each day of the week can scheduled independently. Two (2) separate sessions or periods can be defined. Session 2 can Session 1 Session 2 be left blank if not required.

  • Page 71: Port Trigger

    Advanced Features Port Trigger If you use Internet applications which use non-standard connections or port numbers, you may find that they do not function correctly because they are blocked by the Wireless ADSL Rou- ter's firewall. In this case, you can define the application as a "Port Trigger". The Port Trigger screen can be reached by clicking the Port Trigger on the screen.
  • Page 72  Type - Select the protocol (TCP or UDP) used when you Incoming receive data from the special application or service. (Note: Ports Some applications use different protocols for outgoing and in- coming data).  Start - Enter the beginning of the range of port numbers used by the application server, for data you receive.

  • Page 73: Port Forward

    Advanced Features Port Forward This feature allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to access a server on your LAN because:  Your Server does not have a valid external IP Address. ...

  • Page 74: Port Range Forward

    Port Range Forward This feature allows you to make Servers on your LAN accessible to Internet users. Normally, Internet users would not be able to access a server on your LAN because: Figure 60: Port Range Forwarding Screen Data - Port Range Forwarding Screen Port Range Forwarding Enter the desired application type.

  • Page 75: Qos

    Advanced Features The QoS (Quality of Service) feature allows you specify priorities for different traffic. Lower priority traffic will be slowed down to allow greater throughput or less delay for high priority traffic. An example QoS screen is shown below. Figure 61: QoS Screen Data - QoS Screen QoS Setting...
  • Page 76  Normal-Applications: Category  Add a New Application (Once selected, please complete the following setups.)  Ip/Net: Enter the IP addresses.  Outbound Rate: Enter the desired rate value.  Inbound Rate: Enter the desired rate value.  Priority: Select the desired option (High, Normal, Low) ...

  • Page 77: Chapter 7 Advanced Administration

    Chapter 7 Advanced Administration This Chapter explains the settings available via the "Administration" section of the menu. Overview Normally, it is not necessary to use these screens, or change any settings. These screens and settings are provided to deal with non-standard situations, or to provide additional options for advanced users.

  • Page 78: Pc Database

    PC Database The PC Database is used whenever you need to select a PC (e.g. for the "DMZ" PC).  It eliminates the need to enter IP addresses.  Also, you do not need to use fixed IP addresses on your LAN. However, if you do use a fixed IP address on some devices on your LAN, you should enter details of each such device into the PC database, using the PC Database screen.
  • Page 79 Advanced Administration Data - PC Database Screen This lists all current entries. Data displayed is name (IP Address) type. Known PCs The "type" indicates whether the PC is connected to the LAN. Buttons Refresh Update the data on screen. Advanced View the Advanced version of the PC database screen - PC Database Administration (Admin).
  • Page 80 PC Database - Advanced This screen is displayed if the "Advanced Administration" button on the PC Database is clicked. It provides more control than the standard PC Database screen. Figure 63: PC Database (Admin) Data - Advanced PC Database Known PCs This lists all current entries.
  • Page 81 Advanced Administration MAC Address Select the appropriate option  Automatic discovery - Select this to have the Wireless ADSL Router contact the PC and find its MAC address. This is only poss- ible if the PC is connected to the LAN and powered On. ...

  • Page 82: Config File

    Config File This feature allows you to download the current settings from the Wireless ADSL Router, and save them to a file on your PC. You can restore a previously-downloaded configuration file to the Wireless ADSL Router, by uploading it to the Wireless ADSL Router. This screen also allows you to set the Wireless ADSL Router back to its factory default confi- guration.

  • Page 83: Logs

    Advanced Administration Logs The Logs record various types of activity on the Wireless ADSL Router. This data is useful for troubleshooting, but enabling all logs will generate a large amount of data and adversely affect performance. Since only a limited amount of log data can be stored in the Wireless ADSL Router, log data can also be E-mailed to your PC.
  • Page 84 Logs Include (Checkboxes) Use these checkboxes to determine which events are included in the log. Checking all options will increase the size of the log, so it is good practice to disable any events which are not really re- quired. ...

  • Page 85: E-Mail

    Advanced Administration E-mail This screen allows you to E-mail Logs and Alerts. A sample screen is shown below. Figure 66: E-mail Screen Data - E-mail Screen E-Mail Notification Check this box to enable this feature. If enabled, the E-mail address Turn E-mail Notification on information (below) must be provided.
  • Page 86 E-mail Alerts You can choose to have alerts E-mailed to you, by checking the Send E-mail alerts immediately desired checkboxes. The Broadband ADSL Router can send an immediate alert when it detects a significant security incident such as  A known hacker attack is directed at your IP address ...

  • Page 87: Diagnostics

    Advanced Administration Diagnostics This screen allows you to perform a "Ping" or a "DNS lookup". These activities can be useful in solving network problems. An example Network Diagnostics screen is shown below. Figure 67: Network Diagnostics Screen Data - Network Diagnostics Screen Ping IP Address Enter the IP address you wish to ping.

  • Page 88: Remote Administration

    Remote Administration If enabled, this feature allows you to manage the Wireless ADSL Router via the Internet. Figure 68: Remote Administration Screen Data - Remote Administration Screen Remote Administration Check to allow administration/management via the Internet. (To Enable Remote Management connect, see below).
  • Page 89 Advanced Administration Address, enter ":" followed by the port number.) e.g. HTTP://123.123.123.123:8080 This example assumes the WAN IP Address is 123.123.123.123, and the port number is 8080. You will then be prompted for the login name and password for this device.

  • Page 90: Routing

    Routing Overview  If you don't have other Routers or Gateways on your LAN, you can ignore the "Routing" page completely.  If the Wireless ADSL Router is only acting as a Gateway for the local LAN segment, ignore the "Routing" page even if your LAN has other Routers. ...

  • Page 91: Configuring Other Routers On Your Lan

    Advanced Administration Figure 69: Routing Screen Data - Routing Screen RIP Direction Select the desired RIP Direction. RIP Version Choose the RIP Version for the Server. Static Routing This list shows all entries in the Routing Table. Static Routing Table Entries ...
  • Page 92 Network Mask Normally 0.0.0.0, but check your router documentation. Gateway IP Address The IP Address of the Wireless ADSL Router. Metric Other Routers on the Local LAN Other routers on the local LAN must use the Wireless ADSL Router's Local Router as the Default Route.
  • Page 93 Advanced Administration Gateway IP Address 192.168.0.100 Metric For Router A's Default Route Destination IP Address 0.0.0.0 Network Mask 0.0.0.0 Gateway IP Address 192.168.0.1 (Wireless ADSL Router's IP Address) For Router B's Default Route Destination IP Address 0.0.0.0 Network Mask 0.0.0.0 Gateway IP Address 192.168.1.80 (Wireless ADSL Router's local router)

  • Page 94: Upgrade Firmware

    Upgrade Firmware The firmware (software) in the Wireless ADSL Router can be upgraded using your Web Browser. You must first download the upgrade file, then select Upgrade Firmware on the Administration menu. You will see a screen like the following. Figure 71: Router Upgrade Screen To perform the Firmware Upgrade: Click the Browse button and navigate to the location of the upgrade file.

  • Page 95: Chapter 8 Modem Mode

    Chapter 8 Modem Mode This Chapter explains configuration and operation when in "Modem" or "Bridge" mode.. Overview There are two modes available on the Mode screen.  Router - Both the ADSL Modem and the Router features are operational. In this mode, this device can provide shared Internet Access to all your LAN users.

  • Page 96: Home Screen

    Home Screen If in Modem mode, the home screen will look like the example below. Figure 72: Home Screen - Modem Mode Note that the menu has changed, many of the options in Router mode are not available. The screens available are: ...

  • Page 97: Mode Screen

    Modem Mode Mode Screen This screen is change back to Router mode, if desired. Figure 73: Mode Screen Data - Mode Screen This field displays the current name of this device. Device Name Device Mode Select the desired device mode for the router: ...

  • Page 98: Status Screen

    Status Screen In Modem mode, the Status screen looks like the example below. Figure 74: Status Screen - Bridge Mode Data - Status Screen (Bridge Mode) ADSL Modem Status This indicates the status of the ADSL modem component. Displays the speed for the DownStream Connection. DownStream Connection Speed UpStream Connection...
  • Page 99 Modem Mode Network Mask The Network Mask (Subnet Mask) for the IP Address above. MAC Address This shows the MAC Address for the Wireless ADSL Router, as seen on the LAN interface. Wireless SSID 1 It displays the name of the SSID 1. It displays the MAC address of the SSID 1.

  • Page 100: Appendix A Troubleshooting

    Appendix A Troubleshooting This Appendix covers the most likely problems and their solutions. Overview This chapter covers some common problems that may be encountered while using the Wireless ADSL Router and some possible solutions to them. If you follow the suggested steps and the Wireless ADSL Router still does not function properly, contact your dealer for further advice.

  • Page 101: Wireless Access

    Appendix A - Troubleshooting Problem 2: Some applications do not run properly when using the Wireless ADSL Router. Solution 2: The Wireless ADSL Router processes the data passing through it, so it is not transparent. For incoming connections, you must use the Virtual Server or Firewall Rules to specify the PC which will receive the incoming traffic.
  • Page 102 stations. This will mean high access speed is only possible when close to the Wireless ADSL Router.

  • Page 103: Appendix B About Wireless Lans

    Appendix B About Wireless LANs This Appendix provides some background information about using Wireless LANs (WLANs). Modes Wireless LANs can work in either of two (2) modes:  Ad-hoc  Infrastructure Ad-hoc Mode Ad-hoc mode does not require an Access Point or a wired (Ethernet) LAN. Wireless Sta- tions (e.g.

  • Page 104: Channels

    Channels The Wireless Channel sets the radio frequency used for communication.  Access Points use a fixed Channel. You can select the Channel used. This allows you to choose a Channel which provides the least interference and best performance. In the USA and Canada, 11 channels are available.

  • Page 105: Wpa2-Psk

    Appendix B - About Wireless LANs WPA2-PSK This is a later version of WPA (WPA-PSK). The major change is the use of AES (Advanced Encryption System) for protecting data. AES is very secure, considered to be unbreakable. The PSK (Pre-shared Key) must be entered on each Wireless station. If WPA2-PSK is used, the Wireless Stations and the Access Point must have the same settings for each of the following: Enter the same value on every station and the AP.

  • Page 106: Appendix C Specifications

    Appendix C Specifications Multi-Function Wireless ADSL Router Model WBR-6601 Dimensions 140mm(W) * 140mm(D) * 30mm(H) Operating Temperature 0 C to 40 C Storage Temperature -20 C to 70 C Network Protocol: TCP/IP 4 * 10/100BaseT (RJ45) LAN connection Network Interface:...

  • Page 107: Regulatory Approvals

    Appendix D - Specifications Regulatory Approvals FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference in a residential installation.
