AirLive IGR-1500 User Manual

Four-wan internet gateway
Hide thumbs Also See for IGR-1500:

Advertisement

Quick Links

IGR-1500
Four-WAN Internet Gateway
User's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IGR-1500 and is the answer not in the manual?

Questions and answers

Summary of Contents for AirLive IGR-1500

  • Page 1 IGR-1500 Four-WAN Internet Gateway User’s Manual...
  • Page 2: Declaration Of Conformity

    OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan Rd., Hsin-Tien City, Taipei County, Taiwan Declare that the product Four-WAN Internet Gateway IGR-1500 is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description EN 55022:1998/A1 Limits and methods of measurement of radio disturbance ■...
  • Page 3 Directiva 1999/5/CE. disposiciones aplicables o exigibles de la Directiva 1999/5/CE. ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ OvisLink Corp. ΔΗΛΩΝΕΙ OvisLink Corp izjavlja, da je ta AirLive IGR-1500 v Ελληνική [Greek] ΟΤΙ AirLive IGR-1500 ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ Slovensko skladu z bistvenimi zahtevami in ostalimi relevantnimi ΤΙΣ...
  • Page 4: Ce Declaration Of Conformity

    FCC Interference Statement The IGR-1500 has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against radio interference in a commercial environment.
  • Page 5: Table Of Contents

    Table of Contents Chapter 1 Introduction......................... 4 1.1 Functions and Features ........................4 1.2 Front Panel and Rear Panel ....................... 5 1.3 Packing List............................6 Chapter 2 Deployment ......................... 7 Chapter 3 Configure Router ......................8 3.1 How to start out to configure router ....................8 3.2 Work Mode............................11 3.3 System Status ...........................
  • Page 6 3.11.5 IP Binding ..........................48 3.11.6 DDNS (Gateway mode and Basic NAT mode only) ............50 3.11.7 Proxy (Gateway mode and Basic NAT mode only) ............. 51 3.11.8 Mail Alert (Gateway mode and Basic NAT mode only)............52 3.11.9 Time (Gateway mode and Basic NAT mode only)............... 53 3.11.10 System Log (Gateway mode and Basic NAT mode only) ..........
  • Page 7: Chapter 1 Introduction

    IGR-1500 features with 4 10/100 Mbps Ethernet ports (WAN port) and one 10/100 Mbps Ethernet port (LAN port). WAN port is using to connect to broadband transmission equipments such as ADSL modem or CABLE modem for user and far end to download or upload data in high speed;...
  • Page 8: Front Panel And Rear Panel

    1.2 Front Panel and Rear Panel Figure 1-1 Front Panel Status Indicator Color Flashing ● Green Power on Power ● Green Linked Data Transmission WAN1~4 ● Collision ● Green Linked Data Transmission Figure 1-2 Rear Panel Ports: FG: Ground connection DC 5V: Connecting to AC adapter WAN1~4 Port: Four RJ-45 type WAN ports connecting to broadband transmission equipment such as ADSL or Cable modem via RJ-45 cable.
  • Page 9: Packing List

    1.3 Packing List IGR-1500 Four-WAN Internet Gateway Installation CD-ROM Quick Installation Guide CAT-5 UTP Fast Ethernet cable AC Adapter When you open your package, make sure all of the above items are included and not damaged. If you see that any components are damaged, please notify your dealer immediately.
  • Page 10: Chapter 2 Deployment

    IGR-1500 provides one LAN port connecting to your network devices such as PC, HUB and SWITCH via RJ45 cable. Using a HUB/SWITCH will allow more PC connecting to IGR-1500. WAN ports are using to connect your ADSL or CABLE Modem to the broadband ISP.
  • Page 11: Chapter 3 Configure Router

    3.1 How to start out to configure router Connect the MIS engineer’s PC and IGR-1500’s LAN port to the same Hub / Switch, and launch Step1. the browser (IE or Netscape) to link the IGR-1500 appliance. The default IP address is http: //192.168.1.1...
  • Page 12 (2) The purpose for this mode is to have high through-put and NAT function both (3) Simple NAT function available (4) Act like a multi-LAN port router When you reset device as default setting, IGR-1500 will be reset as Gateway mode.
  • Page 13 Configure each WAN port separately, and the other function you would like to use, such as Load Step4. Balance, Bandwidth Management, or else. (Figure 3-3) Figure 3-3 Configure WAN port setting You can refer to the manual for more understanding of else router’s feature.
  • Page 14: Work Mode

    3.2 Work Mode In order to meet different application usage, you can configure this router into 3 different working modes. Gateway mode Router mode Basic NAT mode Each working mode includes different features: Function DMZ, DoS, LAN to WAN PPPoE Mode Virtual Server, IP Domain...
  • Page 15 Time Zone System Log Mac Address Clone Configure Proxy Routing protocol DOD (PPPoE) Bandwidth Usage Control...
  • Page 16: System Status

    3.3 System Status 3.3.1 Link Status You can get the following information in Link Status window: (Figure 3-4) LAN Status WAN Status Firmware Version DHCP Table Figure 3-4 Link Status LAN Status: Shows the information of MAC Address, IP Address, Subnet Mask and DHCP Status (Enable/Disable).
  • Page 17: Data Monitor

    3.3.2 Data Monitor Differ with Link Status window, Data Monitor window provides detail packet transfer status. It includes 2 kinds of real time data per each WAN port. (Figure 3-5) Figure 3-5 Data Monitor Current Session: TCP Session: UDP Session: ICMP Session: Total Session: Current Bandwidth:...
  • Page 18 NAT Table: list current user detail NAT data. (Figure 3-6) Refresh: update data monitor table to display newest data Clear Counter: reset Data Counter data to 0, and restart to accumulate the packets. Figure 3-6 NAT Table The packets start to accumulate from: Router powers on Clear counter Counter reaches upper the limitation (4294967K), and then the counter will reset to 0...
  • Page 19: Wan Configure

    3.4 WAN Configure There are several WAN function can be made in this display, you can configure functions to each WAN port separately. Connect to: Internet: WAN port is connected to Internet through ADSL/Cable modem Intranet: WAN port is connected to another router LAN port, work together with “Static Route” function, can restrict specific IP packet to a dedicate route path.
  • Page 20: Wan Type - Dynamic Ip

    100Mbps Full Duplex 3.4.1 WAN Type – Dynamic IP Usually it's used to connect CABLE modem. You won't need to assign IP address, and the IGR-1500 will get the IP address for ISP automatically. (Figure 3-8) Figure 3-8 Dynamic IP Gateway / Basic Mode: When you choose Dynamic IP, you only need to save this selection, and reboot router when you finish configuring all parameter.
  • Page 21: Wan Type - Pppoe

    3.4.2 WAN Type – PPPoE Connect to ISP via dial-up connecting, ISP will assign a legal IP to you after the user Id and password had been passed. (The user Id and password here are provided by your ISP.) (Figure 3-9) Figure 3-9 PPPoE Account: The user name provided by ISP, the character can be entered up to 60.
  • Page 22: Wan Type - Static Ip

    About “Always-on” function, normally you need to combine "Healthy Check" function together, then "Always-on" can work more perfectly because there is an ADSL modem between router & ISP equipment. In physical layer, if ADSL line fails but ADSL modem is still alive, and router can not detect the line status unless ISP sends a disconnected packet to router.
  • Page 23: Bandwidth Usage

    3.5 Bandwidth Usage This is a very useful function, it can let you to control WAN port bandwidth usage by each protocol. Like FTP, when someone uses FTP to transfer file, it will occupy heavy loading by using this function, so you can limit the dedicated application bandwidth as you want to.
  • Page 24 The totally amount of protocol usage percentage can not exceed 100% for each WAN port. Router provides another 4 self-defined port number, user just needs to fill in port number for each protocol.
  • Page 25: Configure Lan & Dhcp

    3.6 Configure LAN & DHCP This function configures the LAN ports IP address, Subnet Mask, and DHCP server. You can choose using DHCP server or disable it, the Dynamic Host Configuration Protocol (DHCP) allows the Broadband Router to dynamically assign IP addresses to network devices. Dynamic IP assignment alleviates the need for the network administrator to maintain and monitor IP address assignments and simplifies IP use because the IP addresses are automatically and dynamically assigned when a station powers-on.
  • Page 26 Figure 3-13 Add Reserved IP Address When enable DHCP Server in “From”, ”TO” field, you can reserve up to 253 IP address to DHCP server. Fill in local DNS Server IP address in “DNS Address” field, the DNS IP information will also assign to DHCP client.
  • Page 27: Routing Table

    Static Routing - Gateway Mode: There have one pc with two interfaces in this area, one interface is connected to IGR-1500 (domain A), and the other connected to another Server (domain B). Users need to set the static routing path in IGR-1500 in order to recognize another domain in this area.
  • Page 28 Static Routing – Basic NAT Mode Similar to Gateway mode, the difference is that Basic NAT mode only has Basic NAT function. Once you select Basic NAT mode, all the additional function such as DoD (Dial on Demand), IP Filter, DoS and so on will be disabled.
  • Page 29: Current Table

    3.7.2 Current Table This display shows the valid routing paths in IGR-1500. Users can view the information about current routing paths. (Figure 3-16) Figure 3-16 Current Table...
  • Page 30: Access Control

    3.8 Access Control 3.8.1 Local IP Filtering (Gateway Mode only) AirLive IGR-1500 allows you to define the accessed restriction about to block or allow outgoing IP packets per protocol (port number). You may restrict specific IP to perform limited protocols or allow them to execute partial protocols. And the first thing you have to know is the port numbers and their usages.
  • Page 31 Figure 3-17 Local IP Filtering Example Setting Protocol Port Number List Protocol Service Port no. Protocol Service Port no. LADP HTTPS TELNET SMTP RLOGIN SYSLOG TFTP TALK 517,518 GOTHER FINGER AFPOWERTCP HTTP Net-Meeting 1503,1702 POP3 L2TP 1701 PPTP 1723 NNTP 5190~5194 PC Anywhere 5631~5632...
  • Page 32: Remote Ip Filtering (Gateway Mode Only)

    3.8.2 Remote IP Filtering (Gateway Mode only) AirLive IGR-1500 features to define accessed restriction for remote users. You may restrict some destination IP addresses that are not allowed to reach IGR-1500. IP Address: destination IP address that prohibits users to reach...
  • Page 33: Intrusion Security (Gateway Mode Only)

    3.8.3 Intrusion Security (Gateway Mode only) AirLive IGR-1500 features Intrusion Security, to allow user setting as “BLOCK” or “PASS” function following by the table content. The restricted user can be defined with its IP and MAC address. (Figure 3-19) Figure 3-19 Intrusion Security...
  • Page 34: Dos Defense (Gateway Mode Only)

    3.8.4 DoS Defense (Gateway Mode only) AirLive IGR-1500 also provides DoS (Denial of Service Defense) function to protect your network servers, hosts, routers and other devices from the attacking of villain using mass data transmission. (Figure 3-20) The default value in the display is the optimize parameter for Router. (Figure 3-21)
  • Page 35 Some virus are using “PING” command to attack network, AirLive IGR-1500 can be defined as accept or reject “PING” command from WAN or LAN. (Figure 3-22) Figure 3-22 Disable Ping respond Function Description Checking the IP fragments. When it finds someone from WAN side tries...
  • Page 36: Url Filtering (Gateway Mode Only)

    3.8.5 URL Filtering (Gateway Mode only) Besides restrict users by local/destination IP, AirLive IGR-1500 provides you to do accessed restriction for user by URL as well. You may restrict some URL address that are not allowed to reach Enable URL Filter On Http Port: You can define the port number for URL Filtering, and select to enable the rule.
  • Page 37: Qos

    3.9 QoS With QoS function, you can set up user bandwidth with Maximum & Minimum bandwidth value. Configure WAN Speed: The WAN speeds must be configured for the QoS configuration to take effect. IP MAX/MIN Limit: Allocate bandwidth to users: IP: IP address of specified user MAX: Bandwidth limitation to this user MIN: Minimal Bandwidth keeps for this user before allocating any bandwidth from this user to...
  • Page 38: Load Balance

    3.10 Load Balance 3.10.1 Outbound Load Balance AirLive IGR-1500 provides three kinds of work mode for Outbound Load Balance, and Ultra Smart Sharing feature to offer intelligent connection solution for banking system and Internet on-line game server. Session: All the enabled WAN ports have the same bandwidth rate (1:1) Weight round robin: Configure the WAN port bandwidth rate manually.
  • Page 39 Figure 3-26 Outbound Load Balance – Weight round robin Dynamic Traffic: Router will find the lowest loading WAN port to transmit and receive data automatically. You need to enter correct ADSL/CABLE WAN speed in here. (Figure 3-27) Figure 3-27 Outbound Load Balance – Dynamic Traffic...
  • Page 40: Inbound Load Balance

    Ultra Smart Sharing: When user enables this function, IGR-1500 will lock user packet at dedicated WAN port, the dedicated WAN port will be selected base on 1st user packet (This feature is suitable for Game, VoIP, banking system …etc). (Figure 3-28) Time out Timer: Default is 60 second, range from 30 ~255.
  • Page 41: Special Application

    Some Internet WEB server do not allow access with multi WAN address, also these WEB server was using dynamic IP address, in this case, AirLive IGR-1500 can let you just define dedicated port number allocated with dedicated WAN port, and the dedicated port was used to access these special WEB Server. (Figure 3-30) Figure 3-30 Special Application 3.10.4 Special IP Assignment...
  • Page 42: Tos

    3.10.5 TOS TOS function can let you setting the priority for dedicated packet. (Figure 3-32) User can specify the Source IP, Destination IP, Protocol type, Source port number, Destination port number and Priority for TOS feature. (Figure 3-33) Figure 3-32 TOS Figure 3-33 TOS Configuration...
  • Page 43: Advance

    Remote port is 80 (default is 80, can be different port number) Remote IP is blank. ROUTER WAN port IP is 110.111.112.1 When the user of remote side wants to access IGR-1500 web configure, the remote user only needs to enter http:// 110.111.112.1 Figure 3-34 Remote Configure...
  • Page 44: Virtual Server

    3.11.2 Virtual Server AirLive IGR-1500 ALG Options to allow IPSec, PPTP and VoIP pass-through, user can also define the port number for ALG Options. You may have FTP, MAIL, VPN or other server on your LAN. If you would like to allow the global users access some servers providing special services on your LAN.
  • Page 45 Figure 3-36 Virtual Server For example: (Figure 3-37) Suppose you want to install servers dedicated with specific WAN port as following: 1. Internet user can access FTP server from WAN1 2. Internet user can access VNC from WAN 2. 3. Internet user can ERP server from all the WAN port. Environment: WAN1 IP address: Static IP address 60.250.158.64 WAN2 IP address: Static IP address 230.74.69.15...
  • Page 46 Figure 3-37 Example Topology Example 1: Define Virtual server to allow FTP service (TCP 21) packets from Internet to LAN FTP server via WAN1. (Figure 3-38) Figure 3-38 Example1 setting...
  • Page 47 Example 2: Define Virtual server to allow VNC service (TCP 5800, TCP 5900) packets from Internet to LAN VNC client via WAN2. (Figure 3-39) Figure 3-39 Example2 setting Example 3: Define Virtual server to allow packets TCP 1394 ~ 1400 from Internet to ERP server via all the WAN interfaces.
  • Page 48: Dmz Host

    If you would like to grant remote users the right to access one of your computers on LAN to perform some actions such as Internet games, you must enable the function of DMZ. When remote users access your legal IP(s), IGR-1500 will transmit these packets to the corresponding virtual IP(s). (Figure 3-41) Figure 3-41 Dynamic IP DMZ...
  • Page 49 DMZ host disregarding the exact WAN IP address. Tick the WAN port option and fill in the IP address of the DMZ host inside the network, the IGR-1500 will map the corresponding WAN IP to the internal DMZ host automatically. When a remote computer wants to access the internal LAN through this WAN, if the accessed port number is not specified by Virtual Server Host, it will be mapped into this internal DMZ host.
  • Page 50: Multi-Nat

    Multi-NAT function allows you to configure multiple LAN IP domain to each WAN port (total 10 LAN IP can be defined), after configure multiple NAT function it will act like virtual router, all traffic between each LAN IP domain will be accessed through IGR-1500. It will provide following benefit: .* restrict broadcast storm in single IP domain.
  • Page 51: Ip Binding

    3.11.5 IP Binding In Internet world, there have some Game Server, SSL protocol user or Personal Server have special request for connection, these special request include: Use special port number to perform specific function Not allow user connect with multiple WAN IP address For Example, if user uses load Balance function provided by router to connect Server, Server might respond with many login requests back to user, because each session comes different WAN port with different IP address, Server treats it like different request...
  • Page 52 Example: IP Address Start port End Port 210.3.1.23 65535 WAN1 All packets go to Internet Host with IP 210.3.1.23 will be restricted to dedicated WAN 1 IP Address Start port End Port 210.3.1.24 WAN2 Packet type belong to protocol 23 that goes to Internet Host with IP 210.3.1.24 will be restricted to dedicated WAN2 IP Address Start port...
  • Page 53: Ddns (Gateway Mode And Basic Nat Mode Only)

    AirLive IGR-1500 will update the WAN IP address to DDNS database once the WAN port was connected to Internet if DDNS function is enabled. And the users in Internet can find out the IGR-1500 via this domain name. (Figure 3-45)
  • Page 54: Proxy (Gateway Mode And Basic Nat Mode Only)

    3.11.7 Proxy (Gateway mode and Basic NAT mode only) This function works together with Mail Alert function, if there have Proxy Server in your local LAN, please fill in necessary Proxy information in this display. (Figure 3-46) Figure 3-46 Proxy...
  • Page 55: Mail Alert (Gateway Mode And Basic Nat Mode Only)

    Sender mail address: The mail address that send out alert mail, you should fill in a legal format address Alert Condition: IGR-1500 provides four condition selections: System will send the mail, once WAN port(s) is connected to Internet. WAN Up System will send the mail, once WAN port(s) is disconnected from Internet.
  • Page 56: Time (Gateway Mode And Basic Nat Mode Only)

    3.11.9 Time (Gateway mode and Basic NAT mode only) AirLive IGR-1500 will obtain the GMT (Greenwich Mean Time) after connected to Internet. You need to indicate the local time so that the system could operate with the correct time. For example, Taiwan’s local time is GMT + 8 hours.
  • Page 57: System Log (Gateway Mode And Basic Nat Mode Only)

    3.11.10 System Log (Gateway mode and Basic NAT mode only) Show all the records after IGR-1500 Power on, such as WAN port up/down, WAN IP address, the obtained time, DDNS current corresponding WAN IP address and so forth. You can also save these data to files.
  • Page 58: Mac Address Clone

    If your ISP blocked the MAC address of a network card, you may use MAC Address Clone to duplicate the MAC address to the Mac address in each WAN port. Remove all Ethernet cable on IGR-1500 LAN port except for the PC you want to clone. Then press Ok when you ready. (Figure 3-50) User Self-Define WAN Port MAC Address: type in a MAC Address to define WAN MAC Address.
  • Page 59: Administrator

    3.12 Administrator 3.12.1 Password Use this function to change the Password that is used for access the web configuration. Type in the Old Password, New Password and Retype Password in their respective fields and then click Ok, the password will be changed to new one after re-boot. (Figure 3-51) Password length can be up to 30 alphanumeric characters with case sensitive.
  • Page 60: Backup & Restore

    3.12.2 Backup & Restore Use Backup & Restore function to save all the settings parameters to PC for safety issue, in order to avoid all parameter lose when system crushes. (Figure 3-52) Figure 3-52 Backup & Restore...
  • Page 61: Load Factory Default

    User can use this function to define the feature of reset button, or load the latest configuration file back to device. Click OK after the selection, the IGR-1500 will restart automatically. (Figure 3-53) Reset Button Option: This option is used to define Default button on the back penal of the router.
  • Page 62: Display

    3.12.4 Display You can use this function to check all the parameter setting in this router, in order to save time to check every display. (Figure 3-54) Figure 3-54 Display...
  • Page 63: Firmware Upgrade

    Double click the executable file (the file with exe extension file name) you downloaded. Here we take v105.exe as the example of new version file. Step 1: Click Search to find the IP of router. Step 2: The IP address of IGR-1500 is 192.168.1.1 (default value).
  • Page 64 Step 3: Click Update to update the firmware. Method 2: Step 1: Run a TFTP server program such as TFTPD32. (TFTPD32 is a shareware and you may download it or other TFTP server programs from Internet.)
  • Page 65 Step2: Make a base directory in this server Step 3: Save the image file of firmware to the directory of TFTPD32...
  • Page 66 Step 4: Enter the Server Name and File Name in the new folder fields of Firmware Update window and then click Ok. Step 5: You will see the updating processing. After finishing update procedure, you must reboot IGR-1500 to run new code.
  • Page 67: Save & Reset

    3.14 Save & Reset In order to save the configuration changes that have been made to the IGR-1500, you must save them to the IGR-1500’s Flash memory. If you do not save the changes, the configuration settings will be lost in the event of a power loss or system reboot to the IGR-1500.
  • Page 68: Appendix A In-Bound Load Balance Function

    Authorities DNS is just a fancy term for the official IP address keeper/provider of particular Domain (or Internet) name, such as www.example.com is analogous to a telephone book where a person’s name is associated with his telephone number. Wikipedia, the free encyclopedia has a good general discussion of DNS: http://en.wikipedia.org/wiki/Domain_Name_System.
  • Page 69: Simple Load Balance (2 Wan Lines; Session 1:1)

    A.1 Simple Load Balance (2 WAN lines; Session 1:1) Let us assume that the upload speed of WAN1 and WAN2 are the same; so we will use inbound load-balancing setting: Session with a load-balancing ratio of 1:1. In the IN-BOUND ROUTER configuration Load Balance Inbound: Step 1: Click on Add new item...
  • Page 70 Step 2: Enter host1.example.com two times, once for WAN1 and once for WAN2 with Address Type. This display show the 1st time for WAN1, after clicking Ok. Repeat the previous configuration with the same name for WAN2 at this time. You don’t need to explicitly enter any IP address.
  • Page 71 Step 4: This time we are adding the DNS record with the real name for web server. Select DNS Type with Canonical Name. Name: www.example.com Host: host1.example.com Step 5: The simplest case for the configuration of IN-BOUND ROUTER DNS server is done.
  • Page 72 Now the Inbound Load-balancing DNS Server is configured to redirect the Internet requests of www.example.com to the IP address of either WAN1 or WAN2. But we’ll still need to configure the virtual server. In the IN-BOUND ROUTER configuration: Advance Virtual Server Step 1: The port for www.example.com is 80 and the IP address is:...
  • Page 73: Advanced Load Balancing

    A.2 Advanced Load Balancing We will describe Inbound Load Balancing using “Weighted round robin” algorithm for three Internet servers: 1. Web server, www.example.com, using WAN1 – WAN2, with ratio of 1:2 FTP server, ftp.example.com, using WAN1 –WAN4, with ration of 1:2:3:4 3.
  • Page 74 Define www.example.com in Inbound Option In Load Balance Inbound, select Weight round robin for the inbound load balance mode. Now you can enter the ratio for each WAN port into their respective fields. Add the appropriate entries into the Inbound Option table. The entries are similar to the entries for www.example.com in previous section A.1.
  • Page 75 The mail server requires some additional steps. Define mail.example.com in Inbound Option Step 1: In Load Balance Inbound page, click Add new item, select DNS Type as Address, and configure host name for the Mail server address entry: Enter: Name: mail.example.com rather than Name:...
  • Page 76 Step 3: Load Balance Inbound Add new item Configure Inbound (CName): Select Canonical Name and enter the name as smtp.example.com, select Host with mail.example.com Step 4: Load Balance Inbound Add new item Configure Inbound (CName): Similarly, do the previous step again for pop3.example.com.
  • Page 77 Step 6: Load Balance Inbound: The Mail Server is configured by the last 5 entries of the DNS Name table. Step 7: Advance Virtual Server: Now we finish the IN-BOUND ROUTER DNS server setting, and we still have to link the WAN IP addresses with the Internal &...
  • Page 78 The ratio was specified: WAN1, WAN2, WAN3, WAN4 = 1:2:3:4 www.example.com uses WAN1 and WAN2 with a ratio of 1:2. The IP addresses return to the queries for the Web Server accesses are: WAN1, WAN2, WAN2, WAN1, WAN2, WAN2…, etc. ftp.example.com uses WAN1 –...
