WL-5400CAM
54Mbps Wireless Internet IP Camera
User's Manual

Advertisement

Table of Contents
loading

Summary of Contents for Ovislink AirLive WL-5400CAM

  • Page 1 WL-5400CAM 54Mbps Wireless Internet IP Camera User’s Manual...
  • Page 2: Table Of Contents

    XTRA NFORMATION ……………………………………….42 OW TO DJUST THE ROPERTY ETTING ……………………………………………….45 DJUST THE ECORDING ETTING 7. APPENDIX……………………………………………………………………46 ……………………………………………..46 REQUENTLY SKED UESTIONS B PING Y IP A ………………………………………….…………..47 DDRESS …………………………………………….…………….47 ROUBLE HOOTING …………………………………………………………….49 ABLE ………………………………………………50 PLUG ONTROL NSTALLATION AirLive WL-5400CAM User’s Manual...
  • Page 3 …………………………………………….52 DJUST NTERNET AMERA OCUS ………………………………………………………………….53 PECIFICATION …………………………………………………………..55 LOSSARY OF ERMS AirLive WL-5400CAM User’s Manual...
  • Page 4: About This Guide

    Please note that the illustrations or setting values in this manual are FOR YOUR REFERENCE ONLY. The actual settings and values depend on your system and network. If you are not sure about the respective information, please ask your network administrator or MIS staff for help. AirLive WL-5400CAM User’s Manual...
  • Page 5: Declaration Of Conformity

    OvisLink Corp. 5F., NO.6, Lane 130, Min-Chuan RD., Hsin-Tien City, Taipei County, Taiwan Declare that the product 802.11g Wireless IP Camera WL-5400CAM is in conformity with In accordance with 89/336 EEC-EMC Directive and 1999/5 EC-R & TTE Directive Clause Description Electromagnetic compatibility and Radio spectrum Matters (ERM);...
  • Page 6 1999/5/CE. ehtojen mukainen Ar šo OvisLink Corp. deklarē, ka WL-5400CAM Hér með lýsir OvisLink Corp yfir því að WL-5400CAM atbilst Direktīvas 1999/5/EK būtiskajām prasībām Íslenska [Icelandic] er í samræmi við grunnkröfur og aðrar kröfur, sem Latviski [Latvian] un citiem ar to saistītajiem noteikumiem.
  • Page 7: Introduction

    The powerful IPView SE application assigns the administrator with a pre-defined user ID and password, allowing the administrator to modify the AirLive WL-5400CAM Wireless Internet Camera settings from the remote site via Intranet or Internet. When new firmware is available, you can also upgrade remotely over the network for added convenience.
  • Page 8: Unpacking The Package

    AirLive WL-5400CAM Wireless Internet Camera anywhere and any time in the world. Apply the AirLive WL-5400CAM Wireless Internet Camera to monitor various objects and places such as homes, offices, banks, hospitals, child-care centers, amusement parks and other varieties of industrial and public monitoring.
  • Page 9: Physical Description

    AirLive WL-5400CAM Wireless Internet Camera is powered on. 2. Link LED The Link LED is positioned on the right side of the AirLive WL-5400CAM Wireless Internet Camera’s lens while facing the AirLive WL-5400CAM Wireless Internet Camera. It is located right of the Power LED...
  • Page 10: Rear Panel

    Camera is changing to factory reset. When factory reset is completed, the Wireless Internet Camera will be set to default on channel 11 and SSID is set as “AirLive” (This default setting will let the Wireless Internet Camera connect to ANY access point on the infrastructure network). The IP address will also return to the default setting as 192.168.0.20.
  • Page 11: Screw Hole

    Located on the top/bottom panel of the camera, the screw hole is used to connect the camera stand onto the camera by attaching the screw head on the camera stand into the screw hole of the camera. AirLive WL-5400CAM User’s Manual...
  • Page 12: Hardware Installation

    Camera’s rear panel, and then attach it to the network. Attaching the Power Supply Attach external power supply to the DC power input connector located on Wireless Internet Camera’s rear panel, and then connect it to your local power supply. AirLive WL-5400CAM User’s Manual...
  • Page 13 TIP: You can confirm power source is supplied from the LED indicators label Power on the AirLive WL-5400CAM Wireless Internet Camera is illuminated. AirLive WL-5400CAM User’s Manual...
  • Page 14: Security

    ECURITY To ensure the highest security and prevent unauthorized usage of the AirLive WL-5400CAM Wireless Internet Camera the Administrator has the exclusive privilege to access the System Administration for settings and control requirements to allow users the level of entry and authorize the privileges for all users. The Wireless Internet Camera supports multi-level password protection and access to the Wireless Internet Camera is strictly restricted to defined the user who has a “User Name”...
  • Page 15: Application Of The Camera

    PPLICATION AMERA The AirLive WL-5400CAM Wireless Internet Camera can be applied in wide variety of applications. With the built-in CPU, it can work as a standalone system that provides a web-based solution transmitting high quality video images and sounds for monitoring purposes.
  • Page 16: Application Diagrams Of The Camera

    Application Diagrams of the Camera Home Applications SOHO Internet Camera SOHO Wireless Internet Camera AirLive WL-5400CAM User’s Manual...
  • Page 17: Soho Applications

    SOHO Applications SOHO AirLive WL-5400CAM User’s Manual...
  • Page 18: Using The Camera

    The AirLive WL-5400CAM Wireless Internet Camera must be configured through its built-in Web-based Configuration. (Extensive knowledge of LAN will be helpful in setting up the AirLive WL-5400CAM Wireless Internet Camera.) From the web browser, enter the default IP address to access the Welcome screen of the AirLive WL-5400CAM AirLive Wireless Internet Camera.
  • Page 19: System Administration

    - Ethernet Status: You can monitor the networking status in this field, including the Link (network connection), Speed, and the Duplex mode. Video Click the Video item in the left column to display the video configuration of your camera. AirLive WL-5400CAM User’s Manual...
  • Page 20 Secondary HTTP Port, and UPnP. User Click the User item in the left column to display the user(s) information. - Active Users: The items in this field display the user(s) information, including the user(s) IP address, Name, and DateTime. AirLive WL-5400CAM User’s Manual...
  • Page 21 It is highly recommended to set the Admin ID and Admin Password as soon as possible to enable security option for the AirLive WL-5400CAM Wireless Internet Camera to function. • LED Control: This option allows user to setup the LED illumination as desired. This feature provides the flexibility when surveillance activity is ON.
  • Page 22 SSID: The SSID (Service Set Identifier) is the name assigned to the wireless network. It will auto- detect and display the SSID of wireless network connected in this box (it displays airlive initially). This default setting will let the camera connect to ANY access point under the infrastructure network mode.
  • Page 23 ASCII input ‘1234567890123’. These character counts result in bit counts of 40 and 104, respectively; the AirLive WL-5400CAM Wireless Internet Camera will automatically pad your input to a bit count of 64 or 128. • Encrypt Data Transmissions Using: Use this pull-down menu to decide to use Key 1, 2, 3 or 4 for encryption).
  • Page 24 PCs of all form factors. Check the Enable option to enable the function of your camera. User Click the User item in the left column to add, edit and delete users for your camera. - User Access Control: AirLive WL-5400CAM User’s Manual...
  • Page 25 • Set Manually: Select this option to set the time manually. The system administrator must enter the date and time in the respective field manually. Upload Click the Upload item in the left column to setup configuration for FTP server, time schedule and manual operation. AirLive WL-5400CAM User’s Manual...
  • Page 26 - Manual Operation: When you click the Upload Video button in view video screen, it will start to upload the image. The setting refers to Base File Name and File information above. E-mail Click the E-mail item in the left column to setup configuration for E-mail account, time schedule and manual operation settings. AirLive WL-5400CAM User’s Manual...
  • Page 27 The Interval option is to define time interval between two images sent. System Administration Tools The Tools window contains commands for restarting the camera. Click Tools in the top menu bar and the Tools window will appear as below: AirLive WL-5400CAM User’s Manual...
  • Page 28 When new firmware is available, you can upgrade it through this window. Click the Browse… button to point to the firmware file, and then click Update to start upgrading. Backup Click the Backup item in the left column to backup the current configuration. AirLive WL-5400CAM User’s Manual...
  • Page 29 System Administration Help The Help window provides the basic information of the camera. Click Help in the top menu bar and the Help window will appear as below: About Displays the camera’s model name and version. AirLive WL-5400CAM User’s Manual...
  • Page 30: View Video - Activex Mode

    In the View Video – ActiveX Mode, you are allowed to use the Upload Video and E-mail Video options. Simply click the desired selection ON or OFF to utilize the options for each of the functions. AirLive WL-5400CAM User’s Manual...
  • Page 31: View Image - Java Mode

    2. The administrator has the authority to set the upload video function through the setting in the Upload option under Configuration. 2. The administrator has the authority to set the e-mail video function through the setting in the E-mail option under Configuration. AirLive WL-5400CAM User’s Manual...
  • Page 32 AirLive WL-5400CAM User’s Manual...
  • Page 33: Ipview Se

    This chapter describes the IPView SE, which is a powerful software application designed with a user-friendly interface for ease of control and navigation requirements. Installation Insert the CD-ROM into the CD-ROM drive to initiate the auto-run program. Once completed, a menu screen will appear as below: AirLive WL-5400CAM User’s Manual...
  • Page 34 To install the IPView SE application, click the "IPView SE" button to activate the installation procedure for the application program. Once executed, you will be asked to select the desired language. Select the language you want and click “OK” to continue. AirLive WL-5400CAM User’s Manual...
  • Page 35 The Welcome screen will appear as below. Click the Next button. The License Agreement window will appear as below. Read the details carefully and click the Yes button. AirLive WL-5400CAM User’s Manual...
  • Page 36 In the following window, you may click Next to accept the recommended destination location or click Browse to select another location. After specifying the desired destination location, click Next. The following window allows you to select the folder where the IPView SE application will be located, click Next to continue. AirLive WL-5400CAM User’s Manual...
  • Page 37 If the system has to restart, select “Yes, I want to restart my computer now” and click the Finish button to complete the installation procedure. Otherwise, you may simply click the Finish button to complete the installation procedure. AirLive WL-5400CAM User’s Manual...
  • Page 38: Getting Started

    After successfully installing the IPView SE, the application program for the AirLive WL-5400CAM Wireless Internet Camera is automatically installed to \Programs\Files directory. To start running the IPView SE, click Start > Programs > IPView SE > IPView SE. Once login, the IPView SE application is executed and the interface of IPView SE will appear in the default List...
  • Page 39: How To Add A Camera

    To display the information of IPView SE. How to Add a Camera Add Camera Add Camera To add a new camera, click the Add Camera button. An Add Camera dialog box will appear as illustrated below. AirLive WL-5400CAM User’s Manual...
  • Page 40 If you are unsure of the IP Address of the camera, you can click the Browse button, the Browse Camera dialog box will appear with a blank screen as illustrated below. You must select the camera and click the Add button to add a new camera. AirLive WL-5400CAM User’s Manual...
  • Page 41 When the user adds the camera, four icons will appear, including: “Assign IP to Camera”, “Connect/Disconnect”, “Erase”, “Extra Information”. Motion record Camera Config Assign IP to Camera Schedule record Connect / Disconnect Manual record Erase Extra Information AirLive WL-5400CAM User’s Manual...
  • Page 42: How To Change Camera

    NOTE: When a new camera is added, it is connected. You can see the image right away. If you click the “Connect/ Disconnect” button, it will be in disconnecting, also, no image showed. Minimize Click to minimize the display screen of the camera. AirLive WL-5400CAM User’s Manual...
  • Page 43: Disconnect The Image

    Click to check the event list of the camera. Snapshot Click to snapshot a picture from the camera. Rotate image Click to rotate the image of the camera. Disconnect the Image Click the “Connect/Disconnect” button, and the camera will be disconnected. AirLive WL-5400CAM User’s Manual...
  • Page 44: How To Delete A Camera

    To delete a camera, you must select the camera to delete from the IPView SE control panel. Then, click the “Erase Camera” button. After deleting the camera, the IPView SE control panel will appear as below. Extra Information Extra Information The screen displays the camera’s information. AirLive WL-5400CAM User’s Manual...
  • Page 45: How To Adjust The Property Setting

    Select this option to enable the Proxy Server support. Camera Scan Delay: It allows you to display for each camera one by one. The time interval for each camera can be from 1 Sec. to 20 Sec. AirLive WL-5400CAM User’s Manual...
  • Page 46: Camera Configure

    Camera Configure Click the “Camera Config” button and it will active the Camera Setting, Motion Setting and Update Firmware buttons. Camera Setting Motion Setting Update Firmware Camera Setting Please refer to the “Web Configuration” section. AirLive WL-5400CAM User’s Manual...
  • Page 47: Motion Setting

    User Name: Enter the user name in this field. Password: Enter the user password in this field to login receiver’s mail server Interval Time: The time interval to send next E-Mail the unit is by second. AirLive WL-5400CAM User’s Manual...
  • Page 48: Adjust The Recording Setting

    Schedule Record This option allows the camera to trigger recording as schedule defined. The schedule is set by date or weekday. Manual Record This option allows the camera to trigger recording manually. AirLive WL-5400CAM User’s Manual...
  • Page 49: Appendix

    Q: Can the Internet Camera be used out-doors? AirLive A: The WL-5400CAM Wireless Internet Camera is not weatherproof. It needs to be equipped with a weatherproof case to be used outdoors and it is not recommended. AirLive Q: What network cabling is required for the...
  • Page 50: B Ping Your Ip Address

    To correct the possible problem, you need to first disconnect the WL-5400CAM Wireless Internet Camera from the network. Then run the PING utility (follow the instructions in Appendix B - PING Your IP Address).
  • Page 51 Q: Noisy images occur how can I solve the problem? A1: The video images might be noisy if the AirLive WL-5400CAM Wireless Internet Camera is used is a very low light environment. To solve this issue you need more lighting.
  • Page 52: D Time Zone Table

    AirLive A2: The configuration on the WL-5400CAM Wireless Internet Camera image display is incorrect. Through the Web Configuration Image section you need to adjust the image related parameter for improve images such as brightness, contrast, hue and light frequency. Please refer to the Web Configuration section for detail information.
  • Page 53: E Xplug Control Installation

    From the Web Configuration menu select “System” and under the “Loading ActiveX From” input web server location (http://www.web server location.com/). Once the settings are completed, the user now is able to access the Internet Camera from the web browser by selecting the image view – ActiveX mode. AirLive WL-5400CAM User’s Manual...
  • Page 54 Once executed, a prompt will appear requesting the input of the desired language selection. Make the desired selection and click “OK” to continue. The Welcome screen will appear. Click the “Next” button to proceed with the installation. AirLive WL-5400CAM User’s Manual...
  • Page 55: F Adjust Internet Camera Focu

    To adjust the focus of the lens, you need to turn the lens slowly in either clockwise or anti-clockwise direction until the desired image appears. DO NOT over turn the lens in either of the directions, as it will be out of focus. NOTE: You can further adjust the AirLive WL-5400CAM Wireless Internet Camera's image quality through System Administration –...
  • Page 56 HTTP, FTP, TCP/IP, UDP, ARP, ICMP, BOOTP, DHCP, PPPoE, SMTP, DDNS, UPnP CPU: RDC R2880 RAM: Flash ROM: RTOS Power Supply: DC 5V, switching type Power consumption: 5 Watt (1000mA x 5V) LED Indicator: Power LED (Blue) Activity LED (Orange) Software AirLive WL-5400CAM User’s Manual...
  • Page 57 Netscape 6.0 or above Application Software: IPView SE OS supported: Microsoft Windows 98SE/ME/ 2000/XP, Windows NT4.0 Operating environment Operating temperature: C ~ 40 Storage temperature: C ~ 50 Humidity: 5% ~ 95%, non-condensing FCC, CE, VCCI Class B AirLive WL-5400CAM User’s Manual...
  • Page 58: H Glossary Of Term

    IP addresses rather than requiring an administrator to manage the task. This means a new computer can be added to a network without the hassle of manually assigning it a unique IP address. DHCP allows the specification for the service provided by a router, gateway, or other AirLive WL-5400CAM User’s Manual...
  • Page 59 Internet. The only difference is that an Intranet is used for internal usage only. Internet The Internet is a globally linked system of computers that are logically connected based on the Internet Protocol (IP). The Internet provides different ways to access private and public information worldwide. AirLive WL-5400CAM User’s Manual...
  • Page 60 Packet Internet Groper, a utility used to determine whether a specific IP address is accessible. It PING functions by sending a packet to the specified address and waits for a reply. It is primarily used to AirLive WL-5400CAM User’s Manual...
  • Page 61 On a 10BASE-5 network, the transceiver connects the network adapter or other network device to the medium. Transceivers also can be used on 10BASE-2 or 10BASE-T networks to attach devices with AUI ports. AirLive WL-5400CAM User’s Manual...
  • Page 62 Workstations Workstation refers to the intelligent computer on the user’s desktop. This computer may be an Intel-based PC, a Macintosh, or a UNIX-based workstation. The workstation is any intelligent device a user works from. AirLive WL-5400CAM User’s Manual...
