Summary of Contents for Chauvet Vue 6.1
-
Page 1: User Manual
Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave Autoswitching Transformer Replaceable Fuse User Serviceable Duty Cycle USER MANUAL 5200 NW 108th Avenue, Sunrise, FL 33351 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ..........................3 ..................................3 HAT IS NCLUDED ................................3 NPACKING NSTRUCTIONS AC P ....................................3 OWER ................................. 3 AFETY NSTRUCTIONS 2. Introduction ............................4 ....................................4 EATURES DMX C ................................4 HANNEL UMMARY ................................... -
Page 3: Before You Begin
Do not link more than 20 @120V and 35@230V. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, contact CHAUVET® at: 954-929-1115. Vue™ 6.1 User Manual Rev. 2... -
Page 4: Introduction
2. I NTRODUCTION Features • 6-channel DMX-512 rotating LED moonflower • Blackout/static/strobe • Individual control of red, green, and blue LEDs within each cluster • Built-in automated programs via master/slave or DMX • Built-in sound activated programs via master/slave or DMX Additional Features •... -
Page 5: Product Overview
Product Overview Bracket Adjustment Knob Hanging Bracket Digital Display Microphone AC Power Input & Fuse Sound Sensitivity Knob Power Output Connector DMX Input Connector Output Connector Vue™ 6.1 User Manual Rev. 2... -
Page 6: Setup
3. S ETUP Disconnect the power cord before replacing a fuse and always replace with the same type fuse. Fuse Replacement With a flat-head screwdriver wedge the fuse holder out of its housing. Remove the damaged The fuse is located fuse from its holder and replace with exact inside this same type fuse. -
Page 7: Operating Instructions
4. O PERATING NSTRUCTIONS Menu Functions UNCTION ELECTION NSTRUCTION SET.d d:001-d:512 Sets the DMX starting address SET.S S:001-S:100 Sets the speed of the current program SET.f F:000-F:100 Sets the flash rate of the current program SET.A A:000-A:035 Selects the current program in standalone Indicates the fixture is operating in sound SUND activation mode... -
Page 8: Dmx Channel Values
DMX Mode This mode allows the unit to be controlled by any universal DMX controller. If you are unfamiliar with DMX, please read the DMX Primer section in the appendix. The fixture will automatically switch to DMX mode when it sees the signal from a DMX controller. Note: In the absence of DMX signal, the fixture will automatically revert to standalone mode. -
Page 9: Setting The Starting Address
Setting the Starting Address This DMX mode enables the use of a universal DMX controller device. Each fixture requires a start address from 1 to 512. Choose start addresses so that the channels used do not overlap, and note the start address selected for future reference. -
Page 10: Troubleshooting Guide
DMX related. If the motor still does not rotate, send the product for service If you still have a problem after trying these solutions, contact CHAUVET® Technical Support at the location on the next page. -
Page 11: Appendix
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET® and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Technical Specifications
DMX Channels ............................6 ORDERING INFORMATION Vue™ 6.1 ............................VUE6.1 WARRANTY INFORMATION Warranty........................2-year limited warranty Contact Us General Information Chauvet Lighting 5200 NW 108th Avenue, Sunrise, FL 33351 (U.S.A.) voice: (954) 929-1115 fax: (954) 929-5560 toll free: 800-762-1084 Technical Support Address: Service Dept.
