Motion Computing CL900 FWS-001 Quick Manual

Log on

1. Press the power button.
2. Tap to display the on-screen keyboard then tap your
user name and password.
The first time you start the tablet, Windows Setup appears.
Follow the instructions to set up your user account.
T
: Press the Security button
ip
whenever you want to lock or unlock your tablet;
it's just like using Ctrl + Alt + Delete.

Use touch and pen (sold separately)

With the CL900 touch-screen display, you can use your
finger or a pen (sold separately) to select and enter text.
Just as you click and double-click a mouse, you tap and
double-tap your finger or pen. To right-click, you tap and
hold or press the pen's function button.
Pen tip
function (right-click) button

Enter text with the Input Panel

Without a keyboard, you enter text using an on-screen
keyboard or writing pad. If you have a pen (which is sold
separately), the writing pad comes in handy to fill out forms
or jot down notes. You use the Tablet PC Input Panel to
enter text with either the keyboard or writing pad. Here's
the Input Panel open to the writing pad.
writing pad keyboard
icon icon
Tablet PC Input Panel
To open the Input Panel either
•
Tap where you want to enter text, such
as in a text box, and the Input Panel icon
appears. Tap the icon to begin to write
or type.
•
Tap the tab on the left edge of the display to expand
the Input Panel.
The Input Panel opens to whatever tool you used last, the
keyboard or the writing pad.
To switch between the writing pad and keyboard
•
Tap the appropriate icon.
Motion Computing and Motion are registered trademarks of Motion Computing, Inc. in the United States and other countries. All other trademarks are
properties of their respective owners. Copyright © 2011 Motion Computing, Inc. All rights reserved. PN 024-02-0253 Rev. A01
Getting Started with the Motion® CL900
Model FWS-001

Adjust settings with Motion Dashboard

CL900 comes with Motion Dashboard which puts many
common tablet-related settings in one convenient place.
To open the Motion Dashboard either
•
•
Among the tasks you can do from the Motion Dashboard:
Tap...
Display
Pen & Tablet Set input mode to touch, pen or both
Audio
Wireless
Power
From Windows Start menu, select
>
Motion Computing Motion Dashboard
From the notification area, tap the Motion icon
Motion Dashboard
To...
Rotate the screen
Change the screen resolution
Dim the display after a period of time
Set up an external display
Adjust touch for left-handedness
Adjust sensitivity of flicks and gestures
Enable swiping, dragging, and two-finger
pinching
Personalize your handwriting so that it can
be recognized more accurately
Adjust speaker and microphone volume
Suppress background noise
Enable and disable Wi-Fi, Bluetooth® and
Mobile Broadband (if installed)
Choose to have wireless enabled or disabled
when the system starts up
Dim the display to save power
Change power switch behavior to sleep,
hibernate, or shut down
Change the power plan to Power Saver
>
All Programs
