 To identify 2-clock and 4-clock DIMM, you may
check if there are traces connected to the golden
finger pins 79 and 163 of the SDRAM. If there are
traces, the SDRAM is probably 4-clock; Otherwise, it
is 2-clock.
I
I
 To identify single-side or double-side DIMM,
check golden finger pin 114 and pin 129. If there are
traces connected to pin 114 and pin 129, the DIMM
is probably double-side; otherwise, it is single-side.
