- Page 1 LCD Monitor User Manual Products: LCD17-5, LCD19-5 Please read this manual before using your monitor, and always follow instructions for proper use. Please save this manual for future reference. LCD17-19_DM...
- Page 2 WARNING RISK OF ELECTRIC SHOCK. DO NOT OPEN. To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer servicing to qualified service personnel. This monitor is equipped with a power plug with ground. Use only with a grounded electrical outlet.
-
Page 3: Legal Notice
LEGAL NOTICE Supercircuits products are designed to meet safety and performance standards with the use of specific Supercircuits authorized accessories. Supercircuits disclaims liability associated with the use of non- Supercircuits authorized accessories. The recording, transmission, or broadcast of any person’s voice without their consent or a court order is strictly prohibited by law. -
Page 4: Table Of Contents
TABLE OF CONTENTS Table of Contents Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 SECTION 1 1 .1. -
Page 5: Introduction
SECTION 1: INTRODUCTION SECTION 1 Introduction This video monitor has a rugged metal construction and displays sharp and brilliant video by utilizing an active TFT LCD matrix. The high contrast ratio generates sharp, crisp lines and images. Also, the fast response time gives superior clarity for moving images, eliminating “ghosting”. Key features include: Built-in BNC, RCA, DVI, S-Video and VGA inputs •... -
Page 6: Installation.and.setup
SECTION 2: INSTALLATION AND SETUP SECTION 2 Installation and Setup To install the monitor: Remove the components from the packaging and inspect them for damage. If the monitor is damaged in any way, return it to your supplier for replacement. Find the monitor assembly and base. Use the screw provided to attach the base to the monitor support bracket. - Page 7 SECTION 2: INSTALLATION AND SETUP Inputs on the lower back side of monitor BNC connectors are located on the back left side of the monitor underneath the back cover. Remove the cover by carefully pulling the lower edge of the cover away from the monitor. Back cover Pull here to...
- Page 8 SECTION 2: INSTALLATION AND SETUP Inputs on the back left side of the monitor If necessary, configure the DVR to enable video (and audio) to the video output you are using. Refer to the documentation provided with the video sourcing device. Connect the audio output from the video source to the audio connector(s) associated with the monitor video input port you are using.
- Page 9 SECTION 2: INSTALLATION AND SETUP SOURCE Move up in menu Move down in menu Move right in menu or volume up Move left in menu or volume down MENU (open/close) Power Audio output Control panel 10. Press the SOURCE button on the monitor control and use the p and q buttons to highlight the video interface you are using.
-
Page 10: Basic.operation
SECTION 3: BASIC OPERATION SECTION 3 Basic Operation 3.1 Using the remote control Monitor functions that can be performed on the control panel can also be done with the remote control. The buttons on the remote control are described below. Power Mute Smart S Numeric Program list buttons... -
Page 11: Power
SECTION 3: BASIC OPERATION Button Function Numeric buttons Enter number buttons (0 – 9) Program list Scan or set program list Select F1 function Cursor Up or down cursor button: function select; left or right cursor button: add or reduce Confirm selection – Add or delete channel number –... -
Page 12: Select.input.source
SECTION 3: BASIC OPERATION The monitor will change to standby mode if it is powered on and there is no signal input for 5 NOTE minutes, or when the preset time to turn off is reached. 3.3 Selecting an input source Press SOURCE on either the remote control or the monitor to open the INPUT SOURCE pop-up window. Then press the up, p, or down, q, cursor keys on remote control or on the monitor to select the video input interface. - Page 13 SECTION 3: BASIC OPERATION PICTURE menu Press the left, t, or right, u, cursor keys on the remote control, or the + or – buttons on the monitor control panel to select one of four menu screens: PICTURE, SOUND, ADVANCED, or SYSTEM. Press the down, q, cursor keys on the remote control or the – button on the monitor control panel to change settings on the menu screen you selected, press MENU again to close the menu screen.
- Page 14 SECTION 3: BASIC OPERATION STANDARD, DYNAMIC, or SOFT. As you step through the preset menus, the picture changes to reflect the attribute set by the mode selected. Choose the picture mode that best satisfies your needs. If you select STANDARD, DYNAMIC, or SOFT, you can change only the COLOR TONE option. —...
- Page 15 SECTION 3: BASIC OPERATION 3.4.2 SOUND menu Use the SOUND menu to adjust the audio bass, treble, and balance. One of four sound modes can be selected: PERSONAL, which allows you to set bass, treble, and balance, and STANDARD, NEWS, and MUSIC modes that have fixed levels for bass and treble, but allow you to set the balance. Volume is not adjusted within a menu.
- Page 16 SECTION 3: BASIC OPERATION Press up, p, or down, q, cursor keys or the remote control or the monitor control panel to select a sound attribute you want to adjust. After selecting the attribute, use the left, t, or right, u, cursor keys on the remote control or the + or – buttons on the monitor control panel to change the setting of the attribute.
- Page 17 SECTION 3: BASIC OPERATION To adjust the ADVANCE parameters, do the following: Press MENU on the remote control or on the monitor control panel. The monitor will display the PICTURE menu screen. Press the right, u, cursor key on the remote control or the + button on the remote control twice to open the ADVANCE menu.
- Page 18 SECTION 3: BASIC OPERATION SYSTEM menu To adjust the SYSTEM parameters, do the following: Press MENU on the remote control or on the monitor. The monitor will display the PICTURE menu screen. Press the left, t, cursor key on the remote control or the – button on the monitor control panel to open the SYSTEM menu.
- Page 19 SECTION 3: BASIC OPERATION Table 5. SYSTEM menu option summary Option Function Description Select menu language – English, French, Chinese, Turkish, OSD LANGUAGE Select menu language etc. Adjust horizontal position of menu Increasing value, menu moves right; decreasing value, menu H-POSITION display moves left (0-100) Increasing value, menu move down;...
-
Page 20: Specifications
SECTION 4: SPECIFICATIONS SECTION 4 Specifications Table 6. Video interface specifications* Interface Specification Video signal: 1080p, 1080i, 720p, 576p, 576i, 480p, 480i Audio LPCM 88.2KHz, 48KHz, HDMI (optional) 44.1KHz, 32KHz, 24Bit, 20Bit, 16Bit DB-15, 75 Ω, 0.5 ~ 0.7 Vp-p, H.V: TTL level (support mode, refer to VGA Input Mode) S-Video Input Y: 75 Ω, 1 Vp-p, C: 75 Ω... - Page 21 SECTION 4: SPECIFICATIONS Table 8. General specifications* LCD 17-5 LCD 19-5 Resolution (maximum) 1280 1024 Pixel pitch 0.264 mm 0.264 mm 0.294 mm 0.294 mm 13.30 in 10.64 in 14.82 in 11.85 in Active area (337.920 mm 270.336 mm) (376.320 mm 301.056 mm)
-
Page 22: Troubleshooting
SECTION 5: TROUBLESHOOTING SECTION 5 Troubleshooting My monitor has no image or sound. How can I fix this problem? It may be that the power source is bad, or the power connections are loose. Check the power cord to make sure it is connected. Also, try to power on the monitor using both the button on the monitor and the button on the remote control. - Page 23 SECTION 5:TROUBLESHOOTING The image on my monitor is poor and unstable. What causes this to happen? Room lighting, static electricity and other external factors can disturb the image or cause it to be unstable. Try shutting off the monitor and disconnecting it from its power source for two minutes. Then reconnect it and power it on again.
