Page 1: Package Contents
English 1. Package Contents The package contains the following items. In case there is any missing or damaged item, contact your dealer immediately. Car Recorder Bracket Car adapter Quick start guide USB cable... -
Page 2: Product Overview
English 2. Product Overview Item 1 Car suction cup 2 Memory Card Slot Power Switch (On / off) 4 USB Connector 5 T buckle 6 Speaker 7 Reset Button 8 LCD Panel 9 LED Light 10 HD TV OUT 11 MIC 12 Wide Angle Lens 13 AV out Slot... -
Page 3: Mount To Windshield
English 3. Mount to Windshield 1. Attach the DVR to the T-buckle bracket. Slide the tripod into the DVR, ensure that it is fixed in tightly. 2. Place the device in an appropriate place on the windshield, so it does not obstruct the driver’s view. -
Page 4: Power On/Off
English 4. Remove the Car Recorder 1. To remove the bracket, just pull on the side pump. 2. Peel the suction cup off at one of the sides. 5. Power On/Off 1. Insert the car charger cable into the car lighter. 2. -
Page 5: How To Record
English 7. How to record After the car is turned on, the DVR will auto power on and start recording. 8. Playback 1. Press the Playback key ( ) to enter playback mode. 2. Select file types you want by the Up (▲) or Down (▼) keys. 3. -
Page 6: Possible Recording Time
English 5. If you want to continue to saving the file, you need to free the reserved space. Enter Playback mode to change the file attribute from locked files to normal files. 10. Possible Recording Time In the recording mode, you can set the time for either three or five minutes. When the time is up, a new file will start to be recorded. -
Page 7: Specifications
Each recording file is 3 min / 5 min, and will Cycle time overwrite when out of SD card memory. Video Resolution 1080P 30fps / 720P 60fps / 720P 30fps Voice Recording On / off voice recording. On / off... - Page 8 English Date Stamp On / Off Enable time and date on/off. Clock Set date and time. Language Supports multi-languages. TV System NTSC / PAL Set TV system compatibility to NTSC / PAL. Flicker 50HZ / 60HZ Set flicker frequency to 50HZ or 60HZ. Format Card Yes / No Format the SD card.
