Internal Function Controls

Internal Function Controls

Overall Gain

Overall Gain
T T
he overall gain of the Model 10 Stereo Power Amplifier can be
adjusted between 26 dB and 32 dB. The setting from the factory is
26 dB, which is adequate for the majority of applications, though in
a small number of situations involving low efficiency systems the
higher gain setting may be necessary. There is no sonic difference
between the two settings.
Because of the potentially dangerous voltages inside of the chassis,
it is recommended that you contact your dealer for information
regarding the overall gain setting adjustments.
attempt to disassemble the chassis of the amplifier and adjust the
gain without explicit instructions from your dealer or Jeff Rowland
Design Group.

DC Protection System

DC Protection System
The Model 10 Stereo Power Amplifier can produce high power levels
that, without well-designed protection circuitry, could damage your
loudspeakers and is equipped with a circuit that protects the
amplifier from DC current emitted by source components.
system also prevents amplification of DC currents that can damage
your loudspeakers.
Do not alter the settings of the DC protection circuit, as this will
disable the ability of the amplifier to protect your loudspeakers!
These settings are for production and testing purposes only.
Note: Note:
Do not
Because of the potentially dangerous voltages inside the chassis, do
not attempt to disassemble the amplifier.
This
