Icom BC-144N Instructions page 2

AD-99 SPACER COMBINATIONS
• For IC-F30G Series
Spacer A
• For IC-F3G Series
Check orientation
and
Spacer A
Spacer B/C
• For IC-F11 Series
Check orientation
and
Spacer A
Spacer B/C
When removing the spacer (Spacer B/C)
Remove the spacer (Spacer B/C)
from the adapter.
Push the notch
carefully.
The adapter (Spacer A) only is required.
Attach the spacer (Spacer B/C) to the
adapter (Spacer A) with the orientation as
illustrated in the diagram at left.
• Attach the spacer (Spacer B/C) to the
adapter with the orientation of the stamp
" " pointing up.
Attach the spacer (Spacer B/C) to the
adapter (Spacer A) with the orientation as
illustrated in the diagram at left.
• Attach the spacer (Spacer B/C) to the
adapter with the orientation of the stamp
" " pointing up.
Push the notch carefully with your finger to
remove the spacer (Spacer B/C) from the
adapter (Spacer A).
R CAUTION!
DO NOT push or force the notch using a
screw driver, etc., to remove it.
DO NOT bend the notch when the
adapter and spacer are not joined
together. This will cause weakening of
the notch plastic.
Both cases may break the notch and it
may not be able to be reattached.
