1. Getting started
1.1 Package contents
– Wireless LAN IP camera PTZ
– 230 V power supply unit
– Wireless LAN antenna
– Tripod
– Assembly material for wall and ceiling attachment
– Confi guration cable
– Installation CD
– Installation instructions
1.2 Connections
1. SMA antenna connection
2. LAN LED
3. WLAN LED
4. Power LED
5. Focus ring
6. Reset button
7. Connection for power supply unit
8. RJ-45 network port
9. Audio output
10. Internal microphone
11. Tripod mount
1.3 LEDs
LAN LED:
WLAN LED:
Power LED:
Off:
On:
Flashing:
Off:
On:
Off:
On:
Network cable is not connected
Network cable is connected
Data transfer via network
No wireless LAN connection
Data transfer via wireless LAN
Camera is not connected to power supply
Camera is in operation
