- Page 1 MANUAL DE INSTRUCCIONES - INSTRUCTION BOOKLET L L a a v v a a d d o o r r a a W W a a s s h h i i n n g g m m a a c c h h i i n n e e L L I I 8 8 6 6 0 0 / / 1 1 132994870...
-
Page 2: Table Of Contents
Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Contents Warnings Washing hints... -
Page 3: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • Leave the porthole door slightly ajar when the appliance is not in use. This preserves the door •... -
Page 4: Disposal
Disposal Packaging materials Machine The materials marked with the symbol Use authorised disposal sites for your old appliance. recyclable. Help to keep your country tidy! >PE<=polyethylene >PS<=polystyrene >PP<=polypropylene This means that they can be recycled by disposing of them properly in appropriate collection containers. Tips for environmental protection To save water, energy and to help protect the •... -
Page 5: Installation
Installation Unpacking 6. Set the machine upright and remove the two remaining bolts from the back. 7. Pull out the three plastic spacers from the holes All transit bolts and packing must be removed into which the bolts were fitted. before using the appliance. -
Page 6: Water Inlet
Water inlet The drain hose must not be kinked. Run it along the floor; only the part near the drainage point must be Connect the water inlet hose supplied with the raised. machine to a tap with a 3/4" thread . Do not use already employed hoses. -
Page 7: Building-In
Building-in b) Hinges To mount the hinges it is necessary to drill two holes This appliance has been designed to be built into the (dia. 35 mm, depth 14 mm) on the inner side of the kitchen furniture. door. The distance between the holes must be The recess should have the dimensions shown in 416 mm. - Page 8 d) Counter-magnet (6) The appliance is pre-arranged for a magnetic closure of the door. To enable a correct operation of this device, it is necessary to screw the counter-magnet (6) (steel disk + rubber ring) into the inner side of the door.
-
Page 9: Your New Washing Machine
Your new washing machine This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. • The temperature selector dial will allow you to choose the most suitable temperature for your laundry. •... -
Page 10: Use
Control panel 1 Operating pilot light 4 Spin speed reduction button This light is on whilst the machine is operating and By depressing this button the spin speed is reduced goes out at the end of the programme. as follows: - from 800 rpm to 400 rpm for cotton and linen 2 START/STOP button (MARCHA/PARADA) - from 750 rpm to 400 rpm in programme Q (short... -
Page 11: Controls
Laundry weights Washing hints The following weights are indicative: bathrobe 1200 g Sorting the laundry napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. sheet 500 g Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. -
Page 12: Detergents And Additives
Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly. -
Page 13: Operating Sequence
4. Select the temperature Operating sequence Turn the dial to the required setting. Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. Pour half a measure of detergent into the main wash compartment and start up the machine. -
Page 14: International Wash Code Symbols
7. At the end of the programme Remove the laundry. The machine stops automatically. The operating pilot light goes out. Turn the drum by hand to make sure it is completely empty, so as to avoid any forgotten items being If you have selected a programme which ends with damaged in a subsequent wash (e.g. -
Page 15: Washing Programmes
Programme table Washing programmes for cotton and linen Max. load: 4.5 kg Consumptions* Addi-tional Programme Temp. Fabrics func- Energy Water Duration tions min. 60°-90° WHITES HEAVY SOILED, WITH ECO-AHORRO PREWASH, for example work garments, sheets, household linen, underwear, towels 60°-90° WHITES NORMALLY SOILED, ECO-AHORRO WITHOUT PREWASH, for example... -
Page 16: Washing Programmes
Programme table Washing programmes for synthetics, mixed fabrics, delicates and wool Max. load: 2 kg, wool 1 kg Addi- Consumptions* tional Programme Temp. Fabrics func- Energy Water Duration tions min. 30°-60° SYNTHETICS HEAVY SOILED, WITH PREWASH, underwear, coloured items, shirts, blouses SYNTHETICS NORMALLY SOILED, 30°-60°... -
Page 17: Maintenance
Maintenance 1. Bodywork 3. Drain filter Clean the outside of the machine with warm water The drain filter collects threads and small objects and a neutral, non-abrasive household detergent. inadvertently left in the laundry. Check regularly that Rinse with clean water and dry with a soft cloth. the filter is clean. -
Page 18: Emergency Emptying Out
5. Emergency emptying out If the water is not discharged (outlet pump is blocked, filter or drain hose are clogged), proceed as follows to empty out the machine: • pull out the plug from the power socket; • close the water tap; •... -
Page 19: Something Not Working
Something not working? Problems which you can resolve yourself. Problem Possible cause • The machine does not start up: • The door is not firmly closed. • The machine is not plugged in or there is no power at the socket. •... - Page 20 Problem Possible cause • Spinning starts late or the machine • The electronic unbalance detection device has cut in because the laundry is not evenly distributed in does not spin: the drum. The laundry is redistributed by reverse rotation of the drum. This may happen several times before the unbalance disappears and normal spinning can resume.
- Page 21 From the Electrolux Group. The world’s No. 1 choice The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of approx. USD 14 billion in more than 150 countries around the world.
