- Page 1 Lavadoras automáticas Washing machines Instrucciones Instructions LC 400 Lea y conserve este manual de instrucciones Read and keep this instructions book 35.292.738/0...
-
Page 2: Dear Customer
Dear customer, Please read these operating instructions carefully and pay particular attention to the safety notes indicated in the first pages. We recommend that you keep this instruction booklet for future reference and pass it on to any future owners. Transport damages When unpacking the appliance, check that it is not damaged. -
Page 3: Table Of Contents
Contents Warnings 24-25 Maintenance Bodywork Disposal Detergent dispenser drawer Cleaning of the drainage area Tips for environmental protection 25 Water inlet filter Frost precautions Technical specifications Emergency emptying out Installation 27-28 Something not working? 40-41 Unpacking Hydraulic connection Levelling Electrical connection Your new washing machine Description of the appliance Detergent dispenser drawer... -
Page 4: Warnings
Warnings The following warnings are provided in the interests of overall safety. You must read them carefully before installing or using the appliance. Installation • Leave the porthole door slightly ajar when the appliance is not in use. This preserves the door •... -
Page 5: Child Safety
Child safety • Keep all detergents in a safe place out of children’s reach. • Children are often not aware of how dangerous • Make sure that children or pets do not climb into electrical appliances can be. When the machine is the drum. -
Page 6: Technical Specifications
Technical specifications DIMENSIONS Height 85 cm Width 60 cm Depth 60 cm MAXIMUM LOAD Cotton 4,5 kg Synthetics 2 kg Delicates 2 kg Woollens 1 kg SPIN SPEED 400 rpm max. POWER SUPPLY VOLTAGE/FREQUENCY 220-230 V/50 Hz TOTAL POWER ABSORBED 2100 W MINIMUM FUSE PROTECTION 10 A... -
Page 7: Installation
Installation Transit security bars Hydraulic connection Before starting the machine up, the transport There should be a COLD WATER tap near the security bars must be removed as follows: washing machine with a screwing on connection You are advised to keep all the transport security pipe of 3/4 gas for the water supply, a sink, a wash bars in case the appliance has to be transported basin or a drainage system in the wall. -
Page 8: Levelling
1,5 m. Max. IMPORTANT: The distance from the floor to the Electrical connections highest part of the hose should be between 60 to Before plugging the appliance make sure that: 90 cm. (It is advised to be between 60 and 70 cm). 1º. -
Page 9: Your New Washing Machine
Your new washing machine This new machine meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Description of the appliance 1 Detergent dispenser drawer 2 Control panel 3 Door handle 4 Drainage area door 5 Adjustable feet Detergent dispenser drawer Prewash... -
Page 10: Use
Control panel 1 2 3 4. Program selector Button Pressing this button when starting Blanco muy To select the required programme turn the control sucio con prelav. or Blanco sucio sin prelav. clockwise to the required program. If at any chance programmes, the temperature will be increased from you pass by the required programme NEVER TURN 60°C to 90°C. -
Page 11: Washing Hints
Laundry weights Washing hints The following weights are indicative: Sorting the laundry bathrobe 1200 g napkin 100 g Follow the wash code symbols on each garment quilt cover 700 g label and the manufacturer’s washing instructions. Sort the laundry as follows: sheet 500 g whites, coloureds, synthetics, delicates, woollens. -
Page 12: Detergents And Additives
Ink: depending on the type of ink, moisten the fabric Quantity of detergent to be used first with acetone (*), then with acetic acid; treat any The type and quantity of detergent will depend on residual marks on white fabrics with bleach and then the type of fabric, load size, degree of soiling and rinse thoroughly. -
Page 13: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 14: Operating Sequence
4. Select the option push button/s. Operating sequence Before washing your first load of laundry, we 5. Select the programme and start recommend that you run a cotton cycle at 60°C, with the machine the machine empty, in order to remove any manufacturing residue from the drum and tub. - Page 15 6. At the end of the programme The machine stops automatically. The mains on light goes out. If you have selected a programme which ends with the water of the last rinse left in the tub, drain the water before opening the door. Select programme (drain) or (spin).
-
Page 16: Programme Table
Programme table Washing programmes for cotton and linen Load: 4,5 kg Additional DESCRIPTION Programme Temp. Fabrics functions Blanco muy 60° WHITES WITH PREWASH, for Prewash sucio example work garments, sheets, Wash at 60°C con prelav. household linen, underwear, towels 4 rinses Spin Blanco sucio 60°... - Page 17 Programme table Washing programmes for synthetics, mixed fabrics, delicates and wool Load: 2 kg, wool 1 kg Additional DESCRIPTION Programme Temp. Fabrics functions Muy sucio 60° SYNTHETICS WITH PREWASH, for Prewash + prelav. example underwear, coloured items, Wash at 60°C shirts, blouses 3 rinses Stop with water in the drum...
-
Page 18: Maintenance
Maintenance 1. Bodywork 3. Cleaning of the drainage area Clean the outside of the machine with warm water The drainage area must be cleaned if the pump has and a neutral, non-abrasive household detergent. been blocked with objects such as buttons, safety Rinse with clean water and dry with a soft cloth. -
Page 19: Water Inlet Filter
4. The water inlet hose filter 6. Frost precautions If the machine is installed in a place where the If it takes longer to fill up the washing machine it is temperature could drop below 0°C, proceed as time to check the water inlet hose filter it may be follows: clogged. -
Page 20: Something Not Working
Something not working? Problems which you can resolve yourself. Problem Possible cause • The machine does not start up: • The door is not firmly closed. • The machine is not plugged in or there is no power at the socket. •... - Page 21 If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, serial number and purchase date of your machine: the Service Centre will require this information.
- Page 22 EHPOESL/Z - 11/2001...
