- Page 1 ADT-TP3340DJ Three-axis Dispenser User Manual Adtech (Shenzhen) CNC Technology Co., Ltd. Add: 5/F, 27-29/Bldg, Tianxia IC Industry Park, Yiyuan Rd, Nanshan District, Shenzhen Postal code: 518052 Tel: 0755-26722719 Fax: 0755-26722718 Email: tech@adtechcn.com http://www.adtechcn.com...
- Page 2 This manual doesn’t contain any assurance, stance or implication in any form. Adtech and the employees are not responsible for any direct or indirect data disclosure, profits loss or cause termination caused by this manual or any information about mentioned products in this manual.
- Page 3 ADT-TP3340DJ Three-axis Dispenser Version History Date of Modification Item No. Version No. Description 20070426 2009/9/29 version Remark: The three digits in the version No. have the following meanings: Main version number of library Secondary version number of library Reserved Note: The version history in the table above is only the update of the manual.
-
Page 4: Table Of Contents
ADT-TP3340DJ Three-axis Dispenser Contents Chapter I. System Introduction ......- 4 - Chapter II. Operation Instructions......- 4 - I. Main Interface ........- 4 - VII. Operation method of double-station processing..- 23 - VIII. General operating flow ......- 23 - Chapter III. -
Page 5: Chapter I. System Introduction
ADT-TP3340DJ Three-axis Dispenser Chapter I. System Introduction This system is suitable for the three-dimensional dispenser motion control system with four or less axes. It supports single point and continuous dispensing; integrates linear, arc and elliptical interpolation function in any space; copies a simple graph in matrix mode; integrates delay, output, designated glue gun, waiting input and other instructions, facilitating customers to realize own special processes;... - Page 6 ADT-TP3340DJ Three-axis Dispenser (Single station worktable) (Double-station worktable) This system supports two processing modes: single station and double stations. The information of the processing file appears in workstation info display area. Prompt: In “Manufacturer parameter settings” -> “System configuration”, you can select single station or double-station for “Station number”.
- Page 7 ADT-TP3340DJ Three-axis Dispenser Please enter parameter setting password: Parameter settings Hardware test File management Edit file Password management 密码管理 用户参数设置 User parameter settings Manufacturer settings 厂商设置 文件参数设置 File parameter settings Relationship among passwords of different levels: 厂商设置密码 Manufacturer setting password 文件参数设置密码...
- Page 8 ADT-TP3340DJ Three-axis Dispenser the value is 50-100 times of the pulse equivalent of X-axis or Y-axis. Reset test before running: If the option is set to 0, the program won’t perform reset test before running and processes directly; if the option is set to other values, the program checks whether the system has been reset before running and won’t allow processing if the system hasn’t...
- Page 9 ADT-TP3340DJ Three-axis Dispenser Pulse equivalent setting wizard Pulse equivalent setting wizard Please make sure that you have read the user manual of this system and connect the wires according to the wiring diagram. If the motor uses step drive, you need to set the freewheeling and drive current of the drive.
- Page 10 ADT-TP3340DJ Three-axis Dispenser Pulse equivalent setting wizard Please measure the distance between the above two positions, and enter the result in the following edit box (unit: mm). Actual moving distance of Y-axis: 100.0000mm Previous Exit (Step V) Save as default/restore default To save the manufacturer settings for future use, you can save the current settings in a hidden file, and then you can press the “Restore default”...
- Page 11 ADT-TP3340DJ Three-axis Dispenser start speed”. Space shift speed: The fast positioning speed of motor during processing is called as space shift speed. 0% corresponds to the “Minimum speed” of the axis, while 100% corresponds to the “Maximum speed”. Space shift acceleration: The higher the space shift acceleration is, the shorter the time from “Space shift start speed”...
- Page 12 ADT-TP3340DJ Three-axis Dispenser Glue gun/pen correspondence settings First gun Fifth gun Corresponding pen Corresponding pen Second gun Sixth gun Corresponding pen Corresponding pen Third gun Fourth gun Corresponding pen Corresponding pen Fourth gun Eighth gun Corresponding pen Corresponding pen Page: 01/01...
- Page 13 ADT-TP3340DJ Three-axis Dispenser Quick start file setting Back File 1: Graph 1 Select file file File 2: Select file name is null, it File 3: Select file is invalid. File 4 Select file The quick start File 5: Select file...
- Page 14 ADT-TP3340DJ Three-axis Dispenser Station I file parameter settings File parameter setting Glue gun usage setting Station I processing start setting Save as default Restore default Back File parameter setting Start dispensing speed: During processing, the running speed when the glue gun is opened is the dispensing speed, and the speed when the glue gun isn’t opened is the space shift speed (or...
- Page 15 ADT-TP3340DJ Three-axis Dispenser Note: Generally, do not edit the processing points of the file after setting the start point. If it is necessary to edit, please cancel the setting of start point. 4. Password management This function requires admin password. You can modify the user parameter setting password and file parameter setting password.
- Page 16 ADT-TP3340DJ Three-axis Dispenser Copy the PLT file to the controller, and then convert the PLT file to processing file through “PLT conversion”. Back up processing file 5. PLT conversion Convert PLT graph to processing file. Before converting, please make sure that the PLT conversion proportion has been set.
- Page 17 ADT-TP3340DJ Three-axis Dispenser Display the parameters of 加工点各项参数显示 No. Type X coordinates Y coordinates Z coordinates processing point Start point Speed: Single point time: Needle Processing point switch height: 加工点切换按钮 button 电机手动控制按钮 Manual motor control button 手动高低速 Manual high/low speed Low speed 切换按钮...
- Page 18 ADT-TP3340DJ Three-axis Dispenser Insert/ Instruction/ Delete/ Save/ Other Type: X coordinates; Y coordinates; Z coordinates; Speed: More Start point Linear Forward circle End point Line: 0004/0004 Prompt: Gun closed Down Copy Preview Back 1) Preview: Select a point in the graph interface.
- Page 19 ADT-TP3340DJ Three-axis Dispenser 3) Other functions Insert/ Instruction/ Delete/ Save/ Cancel Type: X coordinates Start point Common graphs Go to line Linear Start point setting Forward circle Batch edit End point Batch delete Start point Line:0001/0024 Automatic round Down a. Go to point: Go to specified point and edit.
- Page 20 ADT-TP3340DJ Three-axis Dispenser Magnification:1.35 Zoom in Zoom out Suitable Left Right Down Point No.:0001 Previous point: Next point: Select Back Insert/ Instruction/ Delete Round range: Type: X coordinates Start line: End line: Specify glue gun Start point Rounding End point...
- Page 21 ADT-TP3340DJ Three-axis Dispenser Magnification:1.04 Zoom in Zoom out Suitable Left Right Down Point No.:0001 Previous point: Next point: Select Back Single point matrix Start point Instruction X direction number: Y direction number: Offset setting mode: Specify coordinates Instruction The 0006 th point in X direction X coordinates:...
- Page 22 ADT-TP3340DJ Three-axis Dispenser Magnification:0.87 Zoom in Zoom out Suitable Left Right Down Point No.:0001 Previous point: Next point: Select Back V. Hardware test Test the motor, output point and input point of every axis. Motor test: Select the axis to be moved, and then select high speed or low speed, press the forward or reverse button to select the running direction of motor, and release the button to stop the motor.
- Page 23 ADT-TP3340DJ Three-axis Dispenser Input test: The top four lines display the state of input ports no matter in motor test interface or output control interface. The normal display indicates no input signal, while the highlighted display indicates input signal, e.g. the “Z origin” in above figure is highlighted.
-
Page 24: Operation Method Of Double-Station Processing
ADT-TP3340DJ Three-axis Dispenser As shown in the figure above, the second point is “Forward circle” and the fourth point is “Reverse circle”. A full circle is generated if the start points and end points of the forward circle and reverse circle are set to same value. -
Page 25: Chapter Iii. Hardware Connection
Chapter III. Hardware Connection Motor Motor Motor Motor Customer General Item No. Item name TP3340 dispenser Graph name 37-core input board wiring diagram Page Drawn by Tang Gongyi Date 09/9/29 Version Adtech (Shenzhen) CNC Technology Co., Ltd. - 24 -... - Page 26 If the output point is inductive load, it is necessary to install freewheeling diode Customer General Item No. Item name TP3340 dispenser, welder, sprayer Graph name 25-core output board wiring diagram Page Drawn by Tang Gongyi Date 08/6/21 Version Adtech (Shenzhen) CNC Technology Co., Ltd. - 25 -...
- Page 27 ADT-TP3340DJ Three-axis Dispenser Customer General Item No. Item name TP3340 dispenser, welder, sprayer Graph name 25-core extension input board wiring Page diagram Drawn by Tang Gongyi Date 09/9/29 Version Adtech (Shenzhen) CNC Technology Co., Ltd. - 26 -...
-
Page 28: Appendix I. How To Generate Plt Files
ADT-TP3340DJ Three-axis Dispenser Appendix I. How to generate PLT files 1. Generating PLT files with CorelDRAW 12 <1>. Draw a graph <2>. Click menu “File” “Export” to have the following dialog box: <3>. Select “PLT－HPGL Plotter File” in “Save type” and click “Output” to have the following... -
Page 29: Generating Plt Files With Autocad2004
ADT-TP3340DJ Three-axis Dispenser <4>. In “Page” tab, select “Lower left” in “Plotter origin”, select the default values for other items and then click “OK” 2. Generating PLT files with AutoCAD2004 In printer type, please check whether there is printer with the name “Universal SHPGL”; if not, please install in the following procedure: Click menu “File”... - Page 30 ADT-TP3340DJ Three-axis Dispenser Double click the “Add Printer Wizard” icon, and click “Next” to enter the following interface: Click “Next” Select “HP” in Manufacturer and select “Universal SHPGL” in Model, and then click “Next” until the installation completes - 29 -...
- Page 31 ADT-TP3340DJ Three-axis Dispenser After installation, you can output the PLTT files in the following steps: <1>. Draw the graph <2>. Click “File” “Print” to have the following dialog box <3>. Select “Universal SHPGL.PC3” printer in “Printer device”, select “Print to file” checkbox, and set the path and name of output file <4>.
-
Page 32: Tips For Coreldraw12
ADT-TP3340DJ Three-axis Dispenser U;PA0,0;SP;PG1; After generating PLT file, send the PLT file to controller through serial port test software and save it, and then convert it to processing file. After generating the processing file, you also need to perform certain settings, for example, gun feeding/retreating, gun opening/closing operation, scaling, offset, etc. - Page 33 ADT-TP3340DJ Three-axis Dispenser Generate several curves (as in the figure below): (To open the Object manager in the right: click “Tool” “Object manager”) - 32 -...
- Page 34 ADT-TP3340DJ Three-axis Dispenser Select a curve (as in the figure above), name it, and then move it to desired position (as in the figure below): Output the PLT files after sorting. Remember the start position, which is also the start position of...
- Page 35 ADT-TP3340DJ Three-axis Dispenser processing. (3) Adjusting order of internal points of curve As shown in the figure above, you can find that the two endpoints of the curve are different in size. The bigger endpoint is the start and the smaller endpoint is the end. You can change their order in...
- Page 36 ADT-TP3340DJ Three-axis Dispenser - 35 -...
-
Page 37: Appendix Ii. Bootloader Operation Instructions
ADT-TP3340DJ Three-axis Dispenser Appendix II. BootLoader Operation Instructions The BootLoader program is the first program that the controller executes. It is used for the downloading and running of applications, as well as other functions. The description follows: 1. Introducing BootLoader program... -
Page 38: Functions Of Bootloader Program
ADT-TP3340DJ Three-axis Dispenser Now, the BootLoader program is started. Note: 1. Do not hold the “ESC” key for too long time. When the above info appears, press the key once. 2. If the above info doesn’t appear, please check whether the serial port setting is proper and whether the serial port wire connection is proper.
