- Page 1 ..................... EWF 147310 W EN WASHING MACHINE USER MANUAL...
-
Page 2: Table Of Contents
2 electrolux Electrolux. Thinking of you. Share more of our thinking at www.electrolux.com CONTENTS Safety information Helpful hints and tips Safety instructions Washing programmes Product description Consumption values Special accessories for installation Care and cleaning Control panel What to do if… Table of symbols Technical data First use... -
Page 3: Safety Instructions
electrolux 3 • Do not change the specification of this appliance. • Obey the maximum load volume of 8 kg (refer to the “Pro- gramme chart” chapter). • If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. -
Page 4: Product Description
4 electrolux • The appliance is to be connected to the tact the Service to ensure which acces- water mains using the new supplied sories can be used. hose-sets. Old hose sets must not be CARE AND CLEANING reused. • Before you connect the appliance to new Warning! Risk of injury or damage to pipes or pipes not used for a long time, the appliance. -
Page 5: Special Accessories For Installation
electrolux 5 Drain pump Adjustable feet DETERGENT DISPENSER DRAWER Compartment for detergent used for prewash and soak phase or for stain re- mover used during the stain action phase (if available). The prewash and soak detergent is added at the beginning of the wash pro- gramme. -
Page 6: Control Panel
6 electrolux CONTROL PANEL Henceforth the programme selector dial, the buttons and the display will be indicated with the numbers given in this table. Programme selector dial Extra Spoelen button Spin reduction button Display Opties button Start/Pauze button – Voorwas Startuitstel button –... - Page 7 electrolux 7 wash phase. The washing time will be pro- After having pressed the button 6, the longed. This option is recommended for WASHING pilot light (8.1) illuminates. When heavily soiled laundry. the pilot light 8.1 illuminates this means that the machine is operating.
-
Page 8: First Use
8 electrolux DISPLAY 5.1: a few seconds. The delay time value de- • Duration of selected programme creases by one unit every hour. When After selecting a programme, the duration only 1 hour remains, the time decreases is displayed in hours and minutes (for ex- every minute. -
Page 9: Personalisation
electrolux 9 move any manufacturing residue wash compartment and start the from the drum and tub. Pour 1/2 a machine. measure of detergent into the main PERSONALISATION ACOUSTIC SIGNALS dren might be injured by or cause damage to the appliance. This function remains ena- The machine is provided with an acoustic bled also when the washing machine is not device, which sounds in the following ca-... - Page 10 10 electrolux poses the maximum spin speed provided for that programme. Press button 2 repeatedly to change the spin speed, if you want your laundry to be spun at a speed different from the one pro- posed by the washing machine. The rele- vant light will light up.
- Page 11 electrolux 11 3. Press button 6 again to start the pro- OPENING THE DOOR gramme. After the programme has started (or during the delay time) the door is locked. If you Important! The selected delay can be need to open the door, press first the but- changed only after selecting the washing ton 6 to set the machine to PAUSE.
-
Page 12: Helpful Hints And Tips
12 electrolux open to prevent the formation of mildew and unpleasant smells. Stand by : once the programme has finish- the display is reduced. By pressing any but- ed after a few minutes the energy saving ton the appliance will come out of the ener- system will be enabled. -
Page 13: Washing Programmes
electrolux 13 The detergent and any additives must be Follow the product manufacturers’ instruc- placed in the appropriate compartments of tions on quantities to use. the dispenser drawer before starting the Use less detergent if: wash programme. • you are washing a small load If using liquid detergents, a programme •... - Page 14 14 electrolux Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry Katoen Eco 40° Main wash - Rinses Centrifugeren Maximum spin speed 1400 rpm Night cycle Max. load 7 kg Rinse hold For coloured cotton Voorwas...
- Page 15 electrolux 15 Programme Maximum and Minimum Temperature Cycle Description Detergent Options Maximum Spin Speed Compartment Maximum Fabrics Load Type of Laundry Spoelen Rinse - Long spin Centrifugeren Maximum spin speed 1400 rpm Night cycle Max. load 7 kg Rinse hold With this programme it is possible to rinse and spin cotton Extra spoelen garments which have been washed by hand.
-
Page 16: Consumption Values
16 electrolux In UK, Eire, Hong Kong and India the Wool- mark symbol is a certification trademark. CONSUMPTION VALUES The data of this table are approximate. Different causes can change the data: the quantity and type of laundry, the water and ambient temperature. Programmes Load Energy con-... - Page 17 electrolux 17 EXTERNAL CLEANING Clean the exterior cabinet of the appliance with soap and water only, and then dry thoroughly. Important! Do not use methylated spirits, solvents or similar products to clean the cabinet. CLEANING THE DISPENSER DRAWER WASHING DRUM The detergent dispenser drawer should be Rust deposits in the drum may occur due cleaned regularly.
- Page 18 18 electrolux Warning! 6. Unscrew the filter and remove it. 1. Disconnect the mains plug from the mains socket. 2. Do not remove the filter while the appliance operates. Do not clean the drain pump if the water in the appliance is hot.
- Page 19 electrolux 19 11. Close the drain pump door. 6. Clean the filter in the valve with a stiff brush or with the piece of cloth. Warning! 7. Screw the hose back to the machine and make sure the connection is tight. Never remove the pump cover during a 8.
-
Page 20: What To Do If
20 electrolux 2. close the water tap Warning! 3. unscrew the water inlet hose from the tap; Make sure that the temperature is more 4. put the two ends of the inlet hose in a than 0 °C before you use the appliance container and let the water flow out of again. - Page 21 electrolux 21 Problem Possible cause/Solution The drain hose is squashed or kinked. • Check the drain hose connection. The drain filter is clogged. • Clean the drain filter. The machine does not An option or a programme that ends with the water still in the tub empty and/or does not or a that eliminates all the spinning phases has been selected.
-
Page 22: Technical Data
22 electrolux If you are unable to identify or solve the problem, contact our service centre. Before telephoning, make a note of the model, se- Mod..rial number and purchase date of your ma- Prod. No..Ser. - Page 23 electrolux 23 3. Unscrew the three bolts. POSITIONING Install the machine on a flat hard floor. Make sure that air circulation around the machine is not impeded by carpets, rugs etc. Check that the machine does not touch the wall or other kitchen units. Level the washing machine by raising or lowering the feet.
- Page 24 24 electrolux 1. Open the porthole and extract the inlet hose. This fault is shown by a red sector in hose. the window «A». Should this occur, turn the 2. Connect the hose with the angled con- water tap off and refer to your Service Cen- nection to the machine.
-
Page 25: Environment Concerns
electrolux 25 The drain hose may be extended to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Centre. ENVIRONMENT CONCERNS >PP<=polypropylene The symbol on the product or on its This means that they can be recycled by packaging indicates that this product may disposing of them properly in appropriate not be treated as household waste. - Page 26 26 electrolux...
- Page 27 electrolux 27...
- Page 28 www.electrolux.com/shop 132940171-A-032013...
