RSS AR-3000R Specifications

Recording Time
RDAC Grade Sampling Frequency Playback Range
H-LINEAR
S-HIGH 48 kHz 20Hz-22kHz
HIGH 44.1 kHz 20Hz-20kHz
STANDARD 32 kHz 20Hz-15kHz
LONG 1 22.05 kHz 20Hz-10kHz
LONG 2 16 kHz 20Hz-7.5kHz
ANNOUNCE 8 kHz 20Hz-3.7kHz
* Mono Recording time per 1GB Memory Card (x 2 for AR-3000R)
* Recording time is half for stereo recording
* Time specs for continuous recording of 1 phrase
AR-3000R Specifications
Recording Format RDAC (Roland Digital Audio Coding)
Recording Media Compact Flash Memory Card up to 2GB x 2
RDAC Grade H-LINEAR, LINEAR, MODE3, MODE2, MODE1
Stereo, Mono (Audio) or SMF (MIDI)
Phrase Type
Number of Phrases Up to 2,000 phrases
Mic Input : -46dBu/2k ohms/balanced
Audio Input Line Input : 0dBu/20k (stereo) or 10k (mono)
ohms/unbalanced
Line output : +4dBu/500 ohms/balanced,
Mono output : +4dBu/500 ohms/unbalanced,
Audio Output
Phone : 90+90mW Max (30 ohms or more)
AR-200R Specifications
Recording Format RDAC (Roland Digital Audio Coding)
Recording Media Compact Flash Memory Card up to 2GB
H-LINEAR, LINEAR, MODE3, MODE2, MODE1
RDAC Grade
Phrase Type Stereo, Mono (Audio) or SMF (MIDI)
Number of Phrases Up to 1,000 phrases *
Audio Input 0dBu/10k ohms/unbalanced
Line output : +4dBu/-10dBV/600 ohms/balanced
Audio Output
Phone : 1+1 mW Max (30 ohms or more)
S/N Ratio 84 dB
*When saved on AR-3000R
AR-200S Specifications
Recording Format RDAC (Roland Digital Audio Coding)
Recording Media Compact Flash Memory Card up to 2GB
RDAC Grade H-LINEAR, LINEAR, MODE3, MODE2, MODE1
Phrase Type Stereo or Mono
Number of Phrases Up to 1,000 phrases
Audio Input -6dBu/10k ohms/balanced
Audio Output +4dBu/-10dBV/600 ohms/balanced
S/N Ratio
84 dB
AR-3000R Dimension AR-200R Dimension
(mm)
430.1
41.0 3.5
16.2
197.8 231.4
17.4
44.0 45.3
1.3
482.0
www.rolandsystemsgroup.net
RDAC Mode and Recording Time
LINEAR MODE 3 MODE 2
1:58:31 2:57:47 7:54:06 7:54:06
2:08:57 3:13:26 8:53:49 8:53:49
2:57:47 4:26:41 11:51:09 11:51:09
4:17:54 6:26:52 17:31:39 17:31:39
5:55:34 8:53:22 23:42:18 23:42:18
11:51:09 17:46:44 47:24:37 47:24:37
S/N Ratio 90dB
Interfaces RS-232C, MIDI, AR-LINK
Power Supply AC 117, 230, 240V (50/60Hz)
Power Consumption 11W (117V), 12W (230/240V)
Dimensions & Weight 482(W) x 231.4(D) x 44(H) mm, 2.7kg
Rubber Feet, Card Protector (with screws),
Accessories
Owner's Manual, AC Cord
Options
Network Card (AR-NT1R)
Power Supply AC Adaptor or DC9 -24V
1000mA (AC Adaptor) or
Current Draw
1200mA (External DC Power)
Dimensions & Weight 218(W) x 234.7(D) x 44(H) mm, 1.4kg
Rubber Feet, Card Protector (with screws),
Accessories
Owner's Manual, AC adaptor
Options Rack Mount bracket
Power Supply
AC Adaptor or DC9 -24V
1000mA (AC Adaptor) or
Current Draw
1200mA (External DC Power)
Dimensions & Weight 218(W) x 233.3(D) x 44(H) mm, 1.5kg
Rubber Feet, Card Protector (with screws),
Accessories
Euroblock Connector, Owner's Manual, AC adaptor
Options
Rack Mount bracket
AR-200S Dimension
(mm)
217.6 217.6
42 3.3
218
Copyright 2006 Roland Corporation. All rights reserved
All specification and appearances are subject to change without notice
MODE 1
11:51:09
12:53:44
17:46:44
25:47:28
35:33:28
71:06:56
(mm)
42 3.3
218
Aug. 2006 RAM-7002 PR
The AR Series
Audio Recorders
AR-3000R
AR-200R AR-200S
The Industry Standard
for Audio Playback
