- Page 1 Siluro FX Series 3D Graphics Accelerator User’s Manual Available Models: FX5900 OTES 128MB, FX5600 Ultra OTES, FX5600 OTES, FX5200 OTES, FX5700 Ultra, FX5700, FX5700-E, FX5700-L, FX5600 Ultra DT, FX5600 DT, FX5600XT, FX5200 DT 4200-0386-13 Rev. 1.50...
- Page 2 Copyright and Warranty Notice The information in this document is subject to change without notice and does not represent a commitment on part of the vendor, who assumes no liability or responsibility for any errors that may appear in this manual. No warranty or representation, either expressed or implied, is made with respect to the quality, accuracy or fitness for any particular part of this document.
-
Page 3: Table Of Contents
Siluro FX Series 3D Graphics Accelerator Index Schnellinstallationsanleitung..............2 Guide d’Installation Rapide ..............4 Guida all’installazione rapida ..............6 Краткое руководство по установке ............. 8 快速安裝指引 ..................10 快速安装指南 ..................12 クイックインストールガイド.............. 14 빠른 설치 설명서 .................. 16 CHAPTER 1. - Page 4 ................5-9 RAPHIC 5-5. IQ (F FX5600/FX5200 OTES ) ... 5-11 ILURO ILURO ONLY 5-6..............5-17 ISPLAY Display Modes Table................5-18 5-7. BIOS F ............5-19 LASHING TILITY APPENDIX A. HOW TO GET TECHNICAL SUPPORT ..A-1 Siluro FX Series...
- Page 5 User’s Manual...
-
Page 6: Schnellinstallationsanleitung
Schnellinstallationsanleitung Schnellinstallationsanleitung Installation der Karte Neue Systeme: Siluro FX Series... - Page 7 Schnellinstallationsanleitung Systeme mit vorhandener VGA-Karte: Treiberinstallation User’s Manual...
-
Page 8: Guide D'installation Rapide
Guide d’Installation Rapide Guide d’Installation Rapide Installation de la Carte Nouveaux Systèmes: Le schéma de la carte VGA peut varier en fonction des modèles Siluro FX Series... -
Page 9: Installation Du Pilote
Guide d’Installation Rapide Systèmes avec déjà une carte VGA: Installation du Pilote User’s Manual... -
Page 10: Guida All'installazione Rapida
Guida all’installazione rapida Guida all’installazione rapida Installazione della scheda Sistemi nuovi: La disposizione della scheda VGA può variare secondo i modelli Siluro FX Series... -
Page 11: Installazione Del Driver
Guida all’installazione rapida Sistemi con una scheda VGA esistente: Installazione del driver User’s Manual... -
Page 12: Краткое Руководство По Установке
Краткое руководство по установке Краткое руководство по установке Установка Платы Новые Системы: Схема расположения элементов на плате VGA может изменяться в зависимости от модели Siluro FX Series... - Page 13 Краткое руководство по установке Системы с установленной VGA Платой: Установка Драйвера User’s Manual...
-
Page 14: 快速安裝指引
快速安裝指引 快速安裝指引 卡片安裝 全新系統： 現有顯示卡之系統： Siluro FX Series... - Page 15 快速安裝指引 安裝驅動程式 User’s Manual...
-
Page 16: 快速安装指南
快速安装指南 快速安装指南 板卡安装 新系统： VGA 卡的设计可根据模型变化。 已配有 VGA 卡的系统： Siluro FX Series... - Page 17 快速安装指南 驱动程序安装 User’s Manual...
-
Page 18: クイックインストールガイド
クイックインストールガイド クイックインストールガイド カードの取り付け 新しいシステム： VGA カードの配置は型式によって異なります Siluro FX Series... - Page 19 クイックインストールガイド 既存の VGA カードを搭載するシステム： ドライバのインストール User’s Manual...
-
Page 20: 빠른 설치 설명서
빠른 설치 설명서 빠른 설치 설명서 카드 설치 새 시스템: VGA 카드 레이아웃은 모델에 따라 다릅니다. Siluro FX Series... - Page 21 빠른 설치 설명서 기존 VGA 카드를 가진 시스템: 드라이버 설치 User’s Manual...
- Page 22 18 18 Siluro FX Series Siluro FX Series...
-
Page 23: Chapter 1. Introduction
Introduction Chapter 1. Introduction 1-1. Features ® User’s Manual... -
Page 24: Specification
Chapter 1 1-2. Specification Siluro FX5900 OTES 128MB: ® ® ® ® ® ® ® Siluro FX Series... -
Page 25: Siluro Fx5700 Ultra
Introduction Siluro FX5700 Ultra: ® ® ® ® ® ® ® User’s Manual... -
Page 26: Siluro Fx5700/Fx5700-E/Fx5700-L
Chapter 1 Siluro FX5700/FX5700-E/FX5700-L: ® ® ® ® ® ® ® Siluro FX Series... -
Page 27: Siluro Fx5600 Ultra Otes/Fx5600 Ultra Dt
Introduction Siluro FX5600 Ultra OTES/FX5600 Ultra DT: ® ® ® ® ® ® User’s Manual... -
Page 28: Siluro Fx5600 Otes/Fx5600 Dt
Chapter 1 Siluro FX5600 OTES/FX5600 DT: ® ® ® ® ® ® Siluro FX Series... -
Page 29: Siluro Fx5600Xt
Introduction Siluro FX5600XT: ® ® ® ® ® ® User’s Manual... -
Page 30: Siluro Fx5200 Otes/Fx5200 Dt
Chapter 1 Siluro FX5200 OTES/FX5200 DT: ® ® ® ® ® Siluro FX Series... -
Page 31: System Requirements
Introduction 1-3. System Requirements For Siluro FX5900 OTES 128MB/FX5600 Ultra OTES: For Siluro FX5600 OTES/FX5200 OTES: For Siluro FX5700 Ultra/FX5600 Ultra DT: For Siluro FX5700/FX5700-E/FX5700-L/FX5600 DT/FX5600XT/ FX5200 DT: User’s Manual... - Page 32 1-10 Chapter 1 Siluro FX Series...
-
Page 33: Chapter 2. Hardware Setup
Hardware Setup Chapter 2. Hardware Setup 2-1. Card Installation New Systems: Systems with Existing VGA Card: User’s Manual... -
Page 34: Devices Connection
Chapter 2 2-2. Devices Connection Siluro FX5900 OTES 128MB: Siluro FX Series... -
Page 35: Siluro Fx5600 Ultra Otes
Hardware Setup Siluro FX5600 Ultra OTES: User’s Manual... -
Page 36: Siluro Fx5600 Otes
Chapter 2 Siluro FX5600 OTES: Siluro FX Series... -
Page 37: Siluro Fx5200 Otes
Hardware Setup Siluro FX5200 OTES: User’s Manual... -
Page 38: Siluro Fx5700 Ultra
Chapter 2 Siluro FX5700 Ultra: Siluro FX Series... -
Page 39: Siluro Fx5700/Fx5700-E/Fx5700-L
Hardware Setup Siluro FX5700/FX5700-E/FX5700-L: User’s Manual... -
Page 40: Siluro Fx5600 Ultra Dt
Chapter 2 Siluro FX5600 Ultra DT: Siluro FX Series... -
Page 41: Siluro Fx5600 Dt/Fx5200 Dt
Hardware Setup Siluro FX5600 DT/FX5200 DT: User’s Manual... -
Page 42: Siluro Fx5600Xt
2-10 Chapter 2 Siluro FX5600XT: Siluro FX Series... -
Page 43: Connecting To Computers Power Supply
Hardware Setup 2-11 2-3. Connecting to computer’s power supply User’s Manual... - Page 44 2-12 2-12 Chapter 2 Chapter 2 Siluro FX Series Siluro FX Series...
-
Page 45: Chapter 3. Driver Installation
Driver Installation Chapter 3. Driver Installation 3-1. Windows 98/ME Auto Setup: User’s Manual... -
Page 46: Windows 2000
Chapter 3 3-2. Windows 2000 Plug and Play Setup: Siluro FX Series... - Page 47 Driver Installation User’s Manual...
-
Page 48: Auto Setup
Chapter 3 Auto Setup: Siluro FX Series... -
Page 49: Windows Xp
Driver Installation 3-3. Windows XP Plug and Play Setup: User’s Manual... -
Page 50: Auto Setup
Chapter 3 Auto Setup: Siluro FX Series... -
Page 51: Chapter 4. Display Properties
Display Properties Chapter 4. Display Properties NOTE: 4-1. Settings Display: Screen resolution: Color quality: Troubleshoot: Advanced: User’s Manual... -
Page 52: General
Chapter 4 4-2. General DPI setting: Other Restart the computer before applying display settings: Apply the new display settings without restarting: Ask me before applying the new display settings: Siluro FX Series... -
Page 53: Adapter
Display Properties 4-3. Adapter Properties: List All Modes: 4-4. Monitor Properties: Screen refresh rate: Display Settings Hide modes that this monitor cannot display: User’s Manual... -
Page 54: Troubleshoot
Chapter 4 4-5. Troubleshoot Hardware acceleration: Full None Enable write combining: 4-6. Color Management Siluro FX Series... -
Page 55: Geforce Fx
Display Properties 4-7. GeForce FX NOTE: Adapter Information: Driver Version Information: Additional Properties button: NVIDIA on the Internet: Performance and Quality Settings: Image settings: Quality: Performance: High performance: User’s Manual... - Page 56 Chapter 4 Antialiasing settings: Antialiasing NOTE: Off: 2xQ: Anisotropic filtering: NOTE: Off: Siluro FX Series...
-
Page 57: Direct3D Settings
Display Properties Direct3D Settings: Mipmap detail level: Maximum system memory for mode textures: NOTE: Enable fog table emulation: Custom Direct3D settings: User’s Manual... -
Page 58: More Direct3D
Chapter 4 More Direct3D: Vertical sync mode: Render no more than…: NOTE: Siluro FX Series... -
Page 59: Opengl Settings
Display Properties OpenGL Settings: Disable support for enhanced CPU instruction sets: Enable conformant OpenGL texture clamp behavior: Multi-display Hardware Acceleration: NOTE: Single-Display Mode: nView Clone/Span Mode: Multi-Device Compatibility Mode: User’s Manual... - Page 60 Multi-Device Performance Mode: NOTE: Default color depth [for textures]: Use desktop color depth The Always use 16 bpp and Always use 32 bpp Buffer-flipping mode: Auto-select Vertical sync: Always off Off by default On by default Custom OpenGL settings: Siluro FX Series...
-
Page 61: Overlay Controls
Display Properties 4-11 Overlay Controls: Select screen region to zoom: Zoom control: Video Mirror Video Overlay Both Out-In: Adjust Colors: Color Correction Hue, Saturation: User’s Manual... -
Page 62: Clock Frequencies
4-12 Chapter 4 Clock Frequencies: Settings: Core clock frequency: Memory clock frequency: Apply settings startup: Test settings: Auto-detect: Restore defaults: Apply: Siluro FX Series... -
Page 63: Troubleshooting
Display Properties 4-13 Troubleshooting: Display the NVIDIA Settings icon in the taskbar: NVRotate: Landscape: Portrait: Inverted landscape: Inverted portrait: User’s Manual... -
Page 64: Refresh Rate Overrides
4-14 Chapter 4 Refresh Rate Overrides: Applications control refresh rate: Override refresh rates: Change Resolutions: Screen resolution: Color quality: Screen refresh rate: Siluro FX Series... -
Page 65: Desktop Management
Display Properties 4-15 Show only physical panning resolutions: Hide modes that this monitor cannot support: NOTE: Add: Desktop Management: Enable nView Desktop Manager: Wizard: User’s Manual... -
Page 66: Screen Menus
4-16 Chapter 4 Screen Menus: Enable screen menu editing: Screen Menu Editing Siluro FX Series... -
Page 67: Nview Display Mode
Display Properties 4-17 nView Display Mode: Single display: Clone: User’s Manual... - Page 68 4-18 Chapter 4 Horizontal Span: Vertical Span: Current display: Siluro FX Series...
- Page 69 Display Properties 4-19 Display: Make this the primary display: Disable auto-panning on secondary device (viewport lock): Detect displays: Device settings: User’s Manual...
-
Page 70: Device Settings
4-20 Chapter 4 4-8. Device Settings TV Settings: Signal format: Connection: Auto-select NOTE: TV Output: Settings Device Adjustments TV Output Screen Positioning: NOTE: Siluro FX Series... -
Page 71: Color Correction
Display Properties 4-21 Brightness, Contrast, Override, Flicker: Color Correction: Digital Vibrance: Brightness, Contrast, Gamma: Image sharpening: Color profile: User’s Manual... -
Page 72: Screen Adjustment
4-22 Chapter 4 Screen Adjustment: Display Timing: Auto-Detect: General Timing Formula (GTF): Discrete Monitor Timings (DMT): Coordinated Video Timings (CVT) Standard: Fixed Aspect Ratio timing: Siluro FX Series... -
Page 73: Chapter 5. Utility Setup
Utility Setup Chapter 5. Utility Setup 5-1. nView Desktop Manager Setup Wizard NOTE: User’s Manual... - Page 74 Chapter 5 Siluro FX Series...
-
Page 75: Silurodvd
Utility Setup 5-2. SiluroDVD User’s Manual... - Page 76 Chapter 5 Siluro FX Series...
- Page 77 Utility Setup User’s Manual...
- Page 78 Chapter 5 Siluro FX Series...
-
Page 79: Directx
Utility Setup 5-3. DirectX User’s Manual... - Page 80 Chapter 5 NOTE: Siluro FX Series...
-
Page 81: Graphic Max
Utility Setup 5-4. Graphic Max Important Warning Message: User’s Manual... - Page 82 5-10 Chapter 5 NOTE: Siluro FX Series...
-
Page 83: Siluroiq (For Siluro Fx5600/Fx5200 Otes Only)
Utility Setup 5-11 5-5. SiluroIQ (For Siluro FX5600/FX5200 OTES only) User’s Manual... - Page 84 5-12 Chapter 5 For further settings, click each icon or values shown on SiluroIQ screen to enter each setup menu. Siluro FX Series...
- Page 85 Utility Setup 5-13 SiluroIQ Apply Load setting on startup: Default: WARNING: overclocking may cause damage User’s Manual...
- Page 86 5-14 Chapter 5 Cancel Set Default Beeper Enable: System Shutdown: NOTE: Cancel Set Default Siluro FX Series...
- Page 87 Utility Setup 5-15 FX5200 OTES 1.45-5% 1.45+5% FX5600 OTES 1.30-5% 1.45+5% Set Default NOTE: Set Default User’s Manual...
- Page 88 5-16 Chapter 5 Launch SiluroIQ on Startup Alert by Email Check Log File Clean Log File Save As… Cancel Monitor Resolution Colors Refresh Rate Siluro FX Series...
-
Page 89: Display Tray Icon
Utility Setup 5-17 5-6. Display Tray Icon NOTE: Properties Settings Advanced NOTE: User’s Manual... -
Page 90: Display Modes Table
1280 x 1024 1600 x 900 1600 x 900 1600 x 1200 1600 x 1200 1920 x 1080 1920 x 1080 1920 x 1200 1920 x 1200 1920 x 1440 1920 x 1440 2048 x 1536 2048 x 1536 Siluro FX Series... -
Page 91: Bios Flashing Utility
Utility Setup 5-19 5-7. BIOS Flashing Utility NOTE: ® NVIDIA Flash ROM utility v4.46 Command List: Usage: nvflash [commands] [rom filename] Use a single dash ("-") to use the single letter version of a command (second column below). Use a double dash ("--") to use the longer descriptive version of a command (first column below). - Page 92 EEPROM acceptable for read operations. level=2 unknown NV chip acceptable for read operations. level=3 Combined effect of 1,2 (cannot write to unknown EEPROM or chip). directpci Bypass the PCI BIOS. listver List BIOS versions of all adapters found. Siluro FX Series...
-
Page 93: Appendix A. How To Get Technical Support
ABIT customers: 1. Check the Manual. 2. Download latest BIOS, software or drivers. Also please make sure you have the latest drivers from your peripheral cards makers! 3. Check the ABIT Technical Terms Guide and FAQ on our Website. User’s Manual... - Page 94 Appendix A 4. Internet Newsgroups. 5. Ask your reseller. 6. Contacting ABIT. Siluro FX Series...
- Page 95 U.K. and Ireland: ABIT Computer (U.K.) Corporation Ltd. Germany, Benelux (Belgium, Netherlands, Luxembourg), Denmark, Norway, Sweden, Finland, and Switzerland: AMOR Computer B.V. (ABIT's European Office) Austria, Czech, Romania, Bulgaria, Yugoslavia, Slovakia, Slovenia, Croatia, Bosnia, Serbia, and Macedonia: Asguard Computer Ges.m.b.H...
- Page 96 Appendix A Japan: ABIT Computer (Japan) Co. Ltd. Shanghai: ABIT Computer (Shanghai) Co. Ltd. Russia: ABIT Computer (Russia) Co. Ltd. France, Italy, Spain, Portugal, and Greece: ABIT Computer France SARL All other territories not covered above please contact Taiwan Head Office: ABIT Computer Corporation http://www.abit.com.tw...
- Page 97 How to Get Technical Support 7. RMA Service. 8. Reporting Compatibility Problems to ABIT 9. How to Get Technical Support: Thank you ABIT Computer Corporation http://www.abit.com.tw User’s Manual...
- Page 98 Intel: □PII □PIII □P4 CPU Type AMD: □Socket A Other: _________________________ □Intel □VIA □SiS □ALi Chipset Chipset code name description: _________________________ Hardware name Type Specifications IDE1 IDE2 CD-ROM IDE1 Drive IDE2 System Memory Size (SDRAM) Monitor maker/model Problem Description: Siluro FX Series...
