1 WIRING DIAGRAM AND DRAWING Wiring Diagram 1.1. PICTORIAL DIAGRAM 1.2. NOTE: For general servicing, it is necessary to eliminate pinching of any wire during reassembly. After servicing any electrical compo- nent or electrical enclosure, the unit should be reassembled and checked for dielectric breakdown or current leakage.
2 EXPLODED VIEW AND PARTS LIST 2.1. Body 2.1.1. Exploded View...
Page 4
2.1.2. Parts List (Body) Ref. No. Part No. Part Name & Description Quantity Remarks AC88KCUDZV07 Dust Container Machined Includes items 38, 45 and 46 AMC98E-V000U Switch ON/OFF Includes item 38 and 46 AC94EAPNZY02 Power Cord Includes items 38, 44 and 46 AMC-1CTCE23 Wire Nut Shipped 10 per package...
2.3. Packing Material 2.3.1. Exploded View 2.3.2. Parts List Ref. No. Part No. Part Name & Description Quantity Remarks AC61ZCCAZ000 Packaging Assembly Includes 1 and items a-g AC01ZCUDZ000 Operating Instructions...
3. Fasten the lower plate by pushing the two (2) latches out- 3.2.2. Installation ward. 1. Loop new belt (Panasonic Type UB8 only) around motor NOTE: For general servicing, it is necessary to eliminate shaft and agitator pulley; see illustration for correct belt pinching of any wire during reassembly. After servicing routing.
3.3. Agitator Assembly 3.4. Brush Replacement Replacement 1. The agitator brushes should be replaced when the brushes are worn. Brushes should be checked by holding 3.3.1. Removal a card across the lower plate. If the bristles on the agitator assembly do not touch the card you should replace all the 1.
6. Lift up on the nozzle housing, plastic shaft side first. 7. The nozzle housing can now be easily rotated from the motor shaft. 7. Install new brushes by reversing procedure. NOTE: If the motor case cover is removed, DO NOT turn 8.
3.6. Power Cord / On-Off Switch 3.7. Thermal Overload Replacement Replacement 3.6.1. Removal 3.7.1. Removal 1. Remove the dust cover and switch cover to expose the 1. Remove motor, as shown in motor replacement section. electrical connections of the power cord, on-off switch 2.
Page 12
3.8.2. Installation 1. Place the motor back into the dust compartment with motor flange positioned as illustrated. 2. Rewire per the Pictorial Diagram. 3. Replace the motor case and the four (4) screws. 4. Turn the vacuum back over and replace the plastic shaft, nozzle housing, belt, agitator assembly, and lower plate according to the respective installation instructions.
