ServiceManual
MC-V5203
SPECIFICATIONS
Model
Power Source
Power Consumption
Cord Length
Motor Protector
Height Adjust
Weight
DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA
All rights reserved. Unauthorized copying and distribution is a violation of law.
ORDER NO. MAC060503U
E4
Commercial Vacuum Cleaner
MC-V5203
AC 120V (60 Hz)
10.0 Amps
50 Ft.
Yes
Automatic
17 lbs.
2003 PANASONIC CONSUMER ELECTRONICS COMPANY,

Advertisement

Table of Contents
loading

Related Manuals for Panasonic MC-V5203

Summary of Contents for Panasonic MC-V5203

  • Page 1 Commercial Vacuum Cleaner MC-V5203 MC-V5203 AC 120V (60 Hz) 10.0 Amps 50 Ft. Automatic 17 lbs. 2003 PANASONIC CONSUMER ELECTRONICS COMPANY, DIVISION OF MATSUSHITA ELECTRIC CORPORATION OF AMERICA All rights reserved. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    WARNING This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product. Products powered by electricity should be serviced or repaired only by experienced professional technicians.

  • Page 3: Schematic Diagram

    NOTES - 18 - SCHEMATIC DIAGRAM NOTE: For general servicing, it is necessary to eliminate pinching of any wire during reassembly. After servicing any electrical component or electrical enclosure, the unit should be reassembled and checked for dielectric breakdown or current leakage. WIRING MANAGEMENT DRAWING NOTE: Do not pinch any wires during reassembly.

  • Page 4: Exploded View ( Nozzle Housing)

    EXPLODED VIEW (NOZZLE HOUSING)… A-19 A-24 A-20 A-24 A-10 A-21 A-21 A-18 A-29 A-28 A-28 A-25 A-27 A-16 A-26 A-23 A-17 A-15 A-27 A-22 A-16 A-22 EXPLODED VIEW (AGITATOR ASSEMBLY)... B-31 B-34 B-33 B-32 B-39 B-36 B-38 B-37 - 4 - MOTOR FAN REPLACEMENT BLOCK Removal...

  • Page 5: Parts List ( Nozzle Housing)

    MOTOR REPLACEMENT Removal 1. Remove the dust cover by grasping the top near the ON/OFF switch and pulling sharply out toward you. 2. Remove the lower plate, agitator assembly, belt, the plastic shaft, and the nozzle housing as instructed in the respective removal sections. 3.
  • Page 6 EXPLODED VIEW (BODY, MOTOR HOUSING, AND MOTOR)… C-54 C-50 C-33 C-48 C-49 C-37 Tabs C-38 C-17 C-10 C-43 C-46 C-44 C-45 C-20 C-35 C-51 C-47 C-15 C-13 C-16 C-30 C-14 C-16 C-22 C-23 C-34 C-25 C-15 C-13 C-24 C-21 - 6 - BLOCK Installation 1.
  • Page 7 SWITCH COVER AREA WIRING MANAGEMENT To Plug End Cord Retainer Wire Connectors (Approx. 1 1/8 in./30 mm Beyond the Strain Relief) POWER CORD/ON-OFF SWITCH REPLACEMENT DUST COMPARTMENT COMPONENT LOCATIONS Removal 1. Remove the dust cover and switch cover to expose the electrical connections of the power cord, ON/OFF switch, and wire cord. 2.

  • Page 8: Parts List (Motor Housing, Motor, Handle, And Body)

    EXPLODED VIEW (MOTOR FAN ASSEMBLY) PARTS LIST (MOTOR FAN ASSEMBLY) Ref. No. Part Name & Description Part No. Quantity Fan Case AMC53F-AVØØU AMC33F-ACØØU Washer AMC62F-AVØØU AC98FRFZØØ Washer AC62FRFZØØ Spacer AC6ØFRFZØØ Brush Assembly AC27FRFZØØ Bracket ACØ2DV3ZØU Screws AC4ØDV3ØØU - 8 - Removal 1.

  • Page 9: Exploded View (Motor Fan Assembly)

    BRUSH REPLACEMENT When to replace brushes 1. The agitator brushes should be replaced when they are worn. Brushes should be checked by holding a card across the lower plate, (Fig. 5). If the bristles on the agitator assembly do not touch the card you should replace all the brushes for best cleaning results.

  • Page 10: Lower Plate Removal/Installation

    Removal 1. Place the handle in the upright position. 2. Turn the vacuum cleaner over exposing the underside. Release the lower plate by pressing inward the two (2) latches and depressing the two locking tabs that secure the lower plate, (Fig. 1).
