- Page 1 WASAUTOMAAT WASCHAUTOMAT LAVE-LINGE WASHING MACHINE LAVADORA G E BRA U CHSA N WEI SUN G NOTI CE D'UTI LI SAT IO N GE BR U IKSA A N WIJ ZI N G INSTR U C TI O N B OOK LET M ANU AL DE US O E W 1035 F 124 985 780...
-
Page 2: Your New Washing Machine
YOUR NEW WASHING MACHINE This new washing machine, which is fitted with Hints on how to save energy the Direct Spray system, patented Electrolux, meets all modern needs for effective treatment By following these hints you will obtain of laundry with low water, energy and detergent economical washing without damaging the consumption. -
Page 3: Table Of Contents
CONTENTS Warnings Maintenance Bodywork Description of the appliance Detergent dispenser drawer Detergent dispenser drawer Drain filter Water inlet filter Installation Emergency emptying out Transit devices Frost precautions Positioning Water inlet Something not working? 86-87 Water drainage Electrical connection Technical specifications Control panel Controls Washing hints... -
Page 4: Warnings
WARNINGS It is important that this instruction book be kept with the appliance for future reference. If you sell or give the appliance away, make sure that the book is passed to the new owners so that they can familiarise themselves with its operation and relevant warnings. The following warnings are provided in the interests of overall safety. -
Page 5: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE 01 Detergent dispenser drawer 3 4 5 02 Programme card 03 ON/OFF button 04 Option buttons 05 “Door locked” pilot light 06 Door open button 07 Temperature selector dial 08 Programme selector dial 09 Operating pilot light 10 Filter 11 Adjustable feet Detergent dispenser drawer... -
Page 6: Installation
INSTALLATION Transit devices All transit bolts and packing must be removed before using the appliance. You are advised to keep all transit devices so that they can be refitted if the machine ever has to be transported again. 1. Using a spanner, unscrew and remove the rear right-hand bolt. -
Page 7: Water Inlet
Water inlet Connect the water inlet hose to a tap with a " thread. The other end of the inlet hose which connects to the machine can be turned in any direction. Simply loosen the fitting, rotate the hose and retighten the fitting, making sure there are no water leaks. -
Page 8: Electrical Connection
Electrical connection This machine is designed to operate on a 220- 230 V, single-phase, 50 Hz supply. Check that your domestic electrical installation can take the maximum load required (2.2 kW), also taking into account any other appliances in use. Connect the machine to an earthed socket, in accordance with current wiring regulations. -
Page 9: Use
Control panel 1 2 3 4 5 6 7 8 01 Programme card 02 ON/OFF button 03 “Spin reduction” button 04 “Anti-Crease” button 05 “Extra rinse” button 06 “Economy” button 07 Door open button 08 “Door locked” pilot light 09 Temperature selector dial 10 Programme selector dial 11 Operating pilot light... -
Page 10: Controls
1 Programme card A programme card in English is supplied with the instruction booklet. It can be inserted in the detergent dispenser drawer. C0057 2 ON/OFF button Press this button to start the machine, press it again to stop a programme or to switch off the machine. -
Page 11: Washing Hints
Washing a maximum load makes the most Washing hints efficient use of water and energy. For heavily soiled laundry, reduce the load size. Sorting the laundry Follow the wash code symbols on each garment Laundry weights label and the manufacturer’s washing instructions. The following weights are indicative: Sort the laundry as follows: whites, coloureds, synthetics, delicates, woollens. -
Page 12: Detergents And Additives
Red wine: soak in water and detergent, rinse Follow the product manufacturer’s and treat with acetic or citric acid, then rinse. recommendations on quantities to use and do Treat any residual marks with bleach. not exceed the «MAX» mark in the detergent dispenser drawer. -
Page 13: International Wash Code Symbols
International wash code symbols These symbols appear on fabric labels, in order to help you choose the best way to treat your laundry. Energetic wash Max. wash Max. wash Max. wash Max. wash temperature temperature temperature temperature 95°C 60°C 40°C 30°C Hand wash Do not... -
Page 14: Operating Sequence
Operating sequence Before washing your first load of laundry, we recommend that you run a cotton cycle at 60°C, with the machine empty, in order to remove any manufacturing residue from the drum and tub. Pour half a measure of detergent into the main wash compartment and start up the machine. -
Page 15: At The End Of The Programme
5. Select the required temperature Turn the temperature selector dial until the temperature coincides with the marker. P0880 6. Select the programme and start the machine Turn the programme selector dial to the desired position. Depress the ON/OFF button: the operating pilot light and door locked light illuminate and the machine starts working. -
Page 16: Washing Programmes
Energetic programmes for cotton and linen Maximum load: 5 kg Possible Progr. Temp. Type of laundry Cycle description options Extra prewash Prewash at 30°-40°C 30°-40° (heavy soiled laundry) Short spin Wash at 60°-95°C Whites 60°-95° 3 rinses (normally soiled) Long spin Wash at 40°-60°C Whites economy 40°-60°... - Page 17 Gentle programmes for synthetics, mixed fibres, delicates and woollens Maximum load: 2 kg, woollens: 1 kg Possible Progr. Temp. Type of laundry Cycle description options Extra prewash for heavy Prewash at 30°-40°C 30°-40° soiled synthetics Short spin Wash at 40°-60°C Synthetics 40°-60°...
-
Page 18: Maintenance
MAINTENANCE 1. Bodywork Clean the outside of the machine with warm water and a neutral, non-abrasive household detergent. Rinse with clean water and dry with a soft cloth. Important: do not use methylated spirits, solvents or similar products to clean the bodywork. -
Page 19: Water Inlet Filter
4. Water inlet filter If you notice that the machine is taking longer to fill, check that the filter in the water inlet hose is not blocked. Turn off the water tap. Unscrew the hose from the tap. Clean the filter with a stiff brush. Screw the hose back onto the tap. -
Page 20: Something Not Working
SOMETHING NOT WORKING? Problems which you can resolve yourself Problem Possible cause The machine does not start up: Check that the door is firmly closed. Check that the machine is plugged in and that there is power at the socket. Check that the main fuse has not blown. -
Page 21: The Door Will Not Open
The machine vibrates or is noisy: Check that all the transit bolts and packing have been removed. Check that the machine is not resting against anything. Check that the support feet are resting firmly on the ground and that the lock nuts are securely tightened.
