Summary of Contents for Edimax WP-S1300
- Page 2 Edimax Technology Co., Ltd. reserves the right to revise this publication and to make changes from time to time in the contents hereof without the obligation to notify any person of such revision or changes.
- Page 3 Č Českého průvodce rychlou instalací naleznete na Č ý ý přiloženém CD s ovladači. Auf der beiliegend Treiber CD finden Sie deutsche Anleitung zur Schnellinstallation. ñ Incluido en el CD el G.R.I. en Español. ñ Veuillez trouver l’français G.I.R ci-joint dans le CD. ç...
-
Page 4: Packaging List
Thank you for purchasing this wireless projector server! This wireless projector server supports both Windows and Mac OS. If your projector server does not work with Mac OS, please download the latest firmware at www.edimax.com. Before you start using this product, please check if there is anything missing in... - Page 5 Front Name Description Switches this projector server on and off WPS (Wi-Fi Protected Setup) activation button Remote control IR signal receiver (for the remote control) receiver PWR LED Indicates whether this wireless projector server is on LAN LED Indicates whether a LAN device is connected WLAN LED Indicates whether there is wireless LAN activity USB AF port...
- Page 6 Back Name Description 12VDC Connects to the supplied power adapter Reset Press and hold this button for 5 seconds to reset the projector server to factory defaults Antennas For wireless signal transmission (left and right) Connects to any VGA-compatible display Audio Output Connects to speakers or an audio amplifier 10/100/1000Mbps Ethernet port...
-
Page 7: Remote Control
Remote Control Battery cover Name Description Black out Press this button to black out the contents on the external display; press this button again to resume Menu Switches between a computer‟s display content and the configuration menu Equivalent to the “Left” key on a computer‟s keyboard Page down Equivalent to the “Right”... - Page 8 Projector Server Setup If you plan on putting the projector server on a desk or other horizontal surfaces, stick the foot pads on the 4 locations as indicated is the picture. Skip this step if you plan on hanging the projector server on the wall. Connect the Ethernet cable to the LAN port (this port is labeled as “LAN”...
- Page 9 Connect the projector server to a video display via the VGA connector. Adjust the antennas so they are perpendicular to the ground. Connect the power adapter to an electrical outlet...
- Page 10 Insert the power connector into the “12V” socket at the back of the projector server. Press the “Power” button located at the front of the projector server. Check the “Power” LED. If it is not on, refer to the “Troubleshooting” section in the user manual.
- Page 11 Using the Projector Server Press the “Power” button at the front of the projector server. You should be able to see this image on the screen. Please wait for about 60 seconds for the projector server to start up. Projector server will acquire an IP address from the DHCP server on your LAN automatically, and the IP address will be displayed at the...
- Page 12 192.168.100.10) Connecting to the projector server via Ethernet: If you wish to connect to the WP-S1300 via an Ethernet cable, please refer to chapter 2-3 of the manual to set up an IP address for the computer first. (Wired IP address: 192.168.2.10)
- Page 13 When you are prompted to download the software, click “Run”. Click “Run” to start software installation. If you see this message, click „Unblock‟. (You must click „Unblock‟ or client utility will become unusable).
- Page 14 When the installation is complete, an icon named “WPS” will appear on your computer‟s desktop: The client software will search for the projector server connected to your local area network, and the projector server‟s SSID will be displayed in the “Projector SSID”...
- Page 15 To stop presentation, click „ ‟ button. Note: Please refer to the user manual in the CD-ROM for more detailed information on Internet connection type and other settings.
-
Page 16: Declaration Of Conformity
Declaration of Conformity We, Edimax Technology Co., LTD., declare under our sole responsibility, that the equipment described below complies with the requirements of the European R&TTE directive (2006/95/EC). Equipment Wireless 802.11b/g/n Projector Server Model No. WP-S1300 The following European standards for essential requirements have been followed: Spectrum ETSI EN 300 328 V1.7.1(2006-10) - Page 17 Portugal, Spain, Sweden, and the United Kingdom. The ETSI version of this device is also authorized for use in EFTA member states: Iceland, Liechtenstein, Norway, and Switzerland. EU Countries not intended for use None A declaration of conformity is available on www.edimax.com...
