  • Page 1 WP-S1000 Wireless Projector Server User Manual Version: 1.0 (November, 2007)

  • Page 2: Table Of Contents

    Reset to Default... 41 5.10 Firmware Upgrade... 42 5.11 Reboot System ... 43 APPENDIX ... 44 6.1 Troubleshooting... 44 6.2 Reset The Projector Server To Factory Default Setting ... 46 6.3 Set Up The Wireless Projector Server (WPS) To The Internet... 47 Index...

  • Page 3: Product Introduction

    1. PRODUCT INTRODUCTION 1.1. Product Introduction and Features Thank you for purchasing this wireless projector server - WP-S1000! This projector server is an user-friendly presentation video server, you can connect this server to video projector or any CRT / LCD monitor with 15-pin D-sub video connector and support XGA resolution (1024 x 768 pixels), and share the projector or CRT / LCD monitor with every computer equipped with wired or wireless network connection.
  • Page 4 / her computer immediately, without downloading and installation! Security All users who wish to access the controlling interface of WP-S1000 projector server must be verified - A random 4-digit login code will be displayed on the projector or CRT / LCD monitor which WP-S1000 is connected to, and the code is required to control the presentation.

  • Page 5: Safety Information

    LPGL Web sites to view the terms of each license. The GPL Code and LGPL Code used in Edimax products is distributed without any warranty and is subject to the copyrights of their authors. For detail of the GPL Code and LGPL Code used in Edimax products, please refer to Edimax website http://www.edimax.com...

  • Page 6: Package Contents

    Before you unpack the package and continue with installation, please check the contents inside the package. If any item is missing, please return the package to the dealer of purchase. Wireless Projector Server (1 pc) Power Adapter (1 pc) Software USB Flash Disk (2 pcs)

  • Page 7: Familiar With Wp-S1000

    1.4. Familiar With WP-S1000 Front View These 3 LEDs indicate the system status of WP-S1000 projector server: STATUS POWER WLAN FLASHING FLASHING DESCRIPTION WP-S1000 projector server is powered on WP-S1000 projector server is powered off Wireless LAN function is activated...
  • Page 8 Back View PWR: Push this button to switch on the WP-S1000 projector server (the ‘POWER’ led at the front panel will lit), push this button again to switch off the projector server. 5V DC: Connects to the power connector of power adapter. WARNING: Only use the...

  • Page 9: Install Your Wireless Projector Server (Wps)

    Flash disks, refer Chapter 4: Make a New USB Flash Disk with Client Software (PnS Token). 2.1 Hardware Installation Use the mounting bracket and screws to mount the Wireless Project Server (WPS) on the wall. (Skip this step if this is not required.).
  • Page 10 Please switch on the projector, and you should be able to see the welcome screen of this projector server on projector or CRT / LCD monitor. A 4-digit login code and the IP address of projector server will be displayed, please remember them or write them down, you’ll need these information when you need to connect the computer to this projector...
  • Page 11 The current configuration of this projector server will be displayed at the lower-left corner, they are: SSID: The Service Set Identifier of the wireless interface of this projector server. Server IP: The IP address of this projector server. Channel: The radio channel this projector server is using.

  • Page 12: Make Software Usb Flash (Pns Token) By Yourself

    2.2 ) Make software USB Flash (PnS Token) by yourself **Note: The Software USB flash disk is an option item. We recommend you to build the USB PnS Token from WP-S1000 with your USB flash disk/ pen drive by yourself.
  • Page 13 3. Setup wizard will copy all necessary files to the USB flash disk, please be patient, and do not remove the USB flash disk in this process. When you see this message, the wizard is completed successfully and the USB flash disk is ready to use. Click ‘Finish’ to exit and remove the USB flash disk.

  • Page 14: Software Installation (Using The Usb Flash)

    2.3 Software Installation (Using the USB Flash) Install the software using the USB Flash Disk. (Please Skip Step 1 to 3 if you’re using wired LAN connection). 1. Right-click on wireless network icon located near the clock (usually located at the bottom-right corner of desktop), and select ‘View Available Wireless Networks’...
  • Page 15 3. Click ‘Connect Anyway’ when you see this message to continue. 4. Insert the USB flash into the USB port of your computer. The computer will automatically search and locate the USB flash. You can run the Plug and Show software immediately by clicking on Start Plug and Show.
  • Page 16 WPS. Enter Login Code and click ‘OK’ to connect to the WPS. 7. Once you login successfully to the projector server, you will be connected and the WPS will project your PC screen to the projector automatically. You will find the Presentation Client Software appears in your computer.
  • Page 17 9. To re-connect to the WPS and re-project your PC screen, follow Step 10-13 below. 10. Click on ‘Start’ > ’My Computer’. 11. A removable storage named ‘PnS Token’ will be appeared in your computer’s drive, double-click on it.
  • Page 18 12. Then, double-click on ‘WP-S1000’ icon, and it will start searching for the WPS.
  • Page 19 USB flash disk from your computer, you are unable to re-connect to the WPS once you close the Presentation Client Software. NOTE: Login code WILL CHANGE when: a. Projector server rebooted. b. User logged out and when login again. IP Address of...

  • Page 20: Software Installation (From The Wps)

    2.3 Software Installation (From the WPS) You can install the software from the WPS via wired / wireless LAN connection into your computer. (Please skip Step 1 to 3 if you’re using wired LAN connection): 1. Right-click on wireless network icon located near the clock (usually located at the bottom-right corner of desktop), and select ‘View Available Wireless Networks’...
  • Page 21 3. Click ‘Connect Anyway’ when you see this message to continue. 4. Launch Internet Explorer (or other web browser like FireFox), input ‘192.168.100.10’ in address bar, and then press ‘Enter’ key. 5. Click ‘Download’ to download projector server software.
  • Page 22 6. Click ‘Download’ to begin software download (leave password field blank). 7. Click ‘Run’ to start software installation after the download is completed. 8. When you see this security warning, click ‘Run’ to continue.
  • Page 23 WPS. Enter Login Code and click ‘OK’ to connect to the WPS. You will be connected and the WPS will project your PC screen to the projector automatically. NOTE: Login code WILL CHANGE when: a. Projector server rebooted. b. User logged out and when login again.
  • Page 24 PC screen to the projector. 13. To re-connect to the WPS and re-project your PC screen. Run the Presentation Client Software manually from your computer. 14. To run the Presentation Client Software, click on Start>All Programs>WP-S1000>, then click on WP-S1000. Presentation Client...

  • Page 25: Familiar With Presentation Client Software

    Play / Pause: Click this button to toggle play / pause mode; when in play mode, the display of WP-S1000 projector server is synchronized with the display content of your computer; when in pause mode, the display of WP-S1000 projector server freezes and is not synchronized with the display content of your computer.

  • Page 26: Video Playing Mode

    Close: Click this button to close client software, your computer will be disconnected from WP-S1000 projector server. If you want to reconnect again, you have to launch client software again and input correct login code.

  • Page 27: Menu

    For detailed instructions for web administration menu, please go to Chapter 5. Search Server: Search for WP-S1000 projector server on the local network. Please note that if you’re currently connected to any projector server, you’ll be disconnected first.

  • Page 28: Make A New Usb Flash Disk With Client Software (Pns Token)

    We only provide 2 USB flash disks. If you need more USB flash disks, you can build it using your USB flash disk/pen drive. If you lost the USB flash disk that comes with your projector server, you can rebuild one with your own USB flash disk/pen drive too.
  • Page 29 2. Click ‘Flash Drive’ dropdown menu to select the drive letter that represents your USB flash disk. If you only have one flash disk inserted, setup wizard should be able to identify the USB flash disk automatically. If the USB flash disk is not correctly identified, please insert the USB flash disk once again, and click ‘Next’.

  • Page 30: Using Web Administration Interface

    USING WEB ADMINISTRATION INTERFACE There are 2 Administrator Accounts in the Web Administration Interface> Conference Control and Admin. Conference Control – To control the process of presentation when more than one presenter are connected. Admin – To configure WPS settings, network setup and perform firmware upgrade. 5.1 Open the Web Administration Interface: 1.
  • Page 31 ‘admin’ menu. (Refer Page 17 for downloading software from the WPS). Conference Control: If there are more than one users logged onto projector server, you can arrange the presentation by selecting the active presenter.

  • Page 32: Download

    5.2 Download Click ‘Download’ to enter client software download page, and click ‘Download’ to start download. Password is not required by default; however, you can setup a password for file download in ‘admin’ menu. (Please refer to Page 17)

  • Page 33: Conference Control

    5.3 Conference Control When you have more than one presenter, you can enter this menu and control the process of the presentation by deciding who is controlling the presentation. You can also see the computer’s name of every presenter. Please note that every presenter can change the name by using a different user name when they login.
  • Page 34 2. All connected presenter(s) will be shown. The active presenter has a this presenter from presenting, click the All inactive presenters will have a make another presenter as active presenter, click the will be stopped and replaced by the new presenter. If you want to leave conference control menu, click ‘Logout’.

  • Page 35: Admin

    5.4 Admin 1. You can configure network and other parameters of this projector server, or upgrade system firmware. To enter admin menu, click ‘admin’. Enter password as ‘admin’, and click ‘Login’ button. Default password is ‘admin’.
  • Page 36 2. After logged in, you’ll see the following administration menu: All setup items are listed on the left, and their detailed descriptions will start from next page. If you want to leave administration menu, click ‘Logout’.

  • Page 37: System Status

    5.5 System Status This page provides various information and the status of WP-S1000 projector server, like firmware version, network settings, and connection status. If you need help from online technician or dealer of purchase for help, the information will help.

  • Page 38: Network Setup

    DHCP Server Setup You can choose to enable or disable the built-in DHCP server for client computers. You can choose ‘Auto’ to let WP-S1000 projector server decide by itself, or choose ‘Disable’ if you want to use other DHCP server on the network.
  • Page 39 SSID: You can change the Service Set Identifier (SSID, the name used to identify this projector server from other wireless devices) by input another SSID here. Default SSID is WPS. (No space is allowed) Channel: You can change the channel number of wireless network from dropdown menu here.

  • Page 40: Projection Setup

    Resolution options are XGA (1024x768), SVGA (800x600), and WXGA (1280x768). Please make sure the projector or CRT / LCD monitor connected to the projector server supports the video resolution you selected. Color Depth Select the color depth (the number of displaying colors) from dropdown menu, available options are normal (16-bit color) and high (32-bit color).

  • Page 41: Change Passwords

    5.8 Change Passwords You can use this page to change the passwords for Download, Conference Control, and Administration. Description of every setup items are listed below: Change the password required for client software download. Please Download enter the same password for both ‘Enter New Password’ and ‘Confirm New Password’...

  • Page 42: Reset To Default

    5.9 Reset to Default You can use this Reset to clear all current settings and restore the project server to factory default settings. Click ‘Apply’ to clear all settings and you will not be able to recover any settings, so please think twice before you click ‘Apply’...

  • Page 43: Firmware Upgrade

    If there is new version of firmware (the system software of this projector server) available, you can download it from Edimax’s website, and store the firmware file to your hard disk. Then you can use this page to upload new firmware file to the projector server and replace previous version.

  • Page 44: Reboot System

    You can use this page to reboot the projector server by clicking the ‘Reboot’ button. If the projector server is not working properly, rebooting the projector server may help, and this function is very helpful when the projector server is located at the place where it is unable to reach easily.

  • Page 45: Appendix

    APPENDIX 6.1 Troubleshooting If you encounter any difficult when using this projector server, eg: the server is not responding or response with strange behaviors, please refer to this troubleshooting table before you contact us or the dealer of purchase, you may be able to solve the problem by yourself and save a lot of time.
  • Page 46 4. Contact your projector or CRT/LCD monitor manufacturer for help. The wireless 1. If you’re using this projector server in an extremely big room, you signal reception is may wish to try another antenna with high signal gain for better signal reception.

  • Page 47: Reset The Projector Server To Factory Default Setting

    Please follow the following instructions to perform the reset: 1. Press ‘PWR’ button to make sure the projector server is switched off. 2. Use a pen or pin to press ‘RESET’ button located at the back of projector server and hold still.

  • Page 48: Set Up The Wireless Projector Server (Wps) To The Internet

    6.3 Set Up The Wireless Projector Server (WPS) To The Internet You can setup the WPS to connect to your router/existing network that has internet connection. By doing this, all computers connected to the WPS wirelessly will be able to access to the Internet via your router.
  • Page 49 6) Connect a LAN cable to the WPS’s LAN port and connect it to the LAN port of your router. Application (Example): IP Address, Subnet Mask and Default Gateway of the WPS. IP Address and Subnet Mask of the router. 7) All computers that connected to the WPS wirelessly can access to the Internet freely.
